A bar chart of daily active energy whose tooltip shows a name, value and kcal unit through a custom formatter.
@esuiss
components/charts/tooltip-chart-formatter.tsx
"use client"
import { Bar, BarChart, XAxis } from "recharts"
import {
Card,
CardContent,
CardDescription,
CardHeader,
CardTitle,
} from "@/components/ui/card"
import {
type ChartConfig,
ChartContainer,
ChartTooltip,
ChartTooltipContent,
} from "@/components/ui/chart"
function dayKey(date: Date) {
return [
date.getFullYear(),
String(date.getMonth() + 1).padStart(2, "0"),
String(date.getDate()).padStart(2, "0"),
].join("-")
}
const chartData = [
512, 604, 455, 389, 662, 598, 431, 520, 690, 447, 575, 402, 633, 558,
]
.slice(-7)
.map((energy, index) => ({
date: dayKey(new Date(2026, 9, index)),
energy,
}))
const chartConfig = {
energy: { label: "Active energy", color: "var(--color-red-500)" },
} satisfies ChartConfig
const weekday = new Intl.DateTimeFormat("en-US", { weekday: "short" })
export function TooltipChartFormatter() {
return (
<Card variant="filled" size="sm">
<CardHeader>
<CardTitle>With units</CardTitle>
<CardDescription>A unit next to the value</CardDescription>
</CardHeader>
<CardContent>
<ChartContainer
config={chartConfig}
className="aspect-auto h-52 w-full"
>
<BarChart
accessibilityLayer
data={chartData}
margin={{ top: 70, right: 4, left: 4, bottom: 0 }}
>
<XAxis
dataKey="date"
tickLine={false}
axisLine={false}
tickMargin={8}
interval={0}
tickFormatter={(value: string) =>
weekday.format(new Date(`${value}T12:00:00`))
}
/>
<ChartTooltip
defaultIndex={3}
cursor={false}
content={
<ChartTooltipContent
hideLabel
formatter={(value) => (
<div className="flex items-baseline gap-1.5">
<span className="text-muted-foreground">
Active energy
</span>
<span className="font-semibold text-foreground tabular-nums">
{Number(value).toLocaleString("en-US")}
</span>
<span className="text-xs text-muted-foreground">
kcal
</span>
</div>
)}
/>
}
/>
<Bar
dataKey="energy"
fill="var(--color-energy)"
radius={4}
maxBarSize={26}
/>
</BarChart>
</ChartContainer>
</CardContent>
</Card>
)
}
