A two-pane mail client shell — a searchable message list and a reading pane with toolbar and inline reply.
@quill
registry/blocks/mail-shell.tsx
import { Badge } from '@/components/ui/badge'
import { Button } from '@/components/ui/button'
import { Input } from '@/components/ui/input'
import { Label } from '@/components/ui/label'
import { Separator } from '@/components/ui/separator'
import { Avatar, AvatarFallback } from '@/components/ui/avatar'
import { Icon } from '@/components/ui/icon'
const messages = [
{
from: 'Ada Lovelace',
initials: 'AL',
subject: 'Scope for the Q3 engagement',
preview: 'Revised deliverables are in the shared folder — see the summary…',
time: '9:12',
unread: true,
tag: 'Client',
},
{
from: 'Nadia Okonjo',
initials: 'NO',
subject: 'Component API revisions',
preview: 'I reworked the variant props so they compose cleanly at three scales…',
time: 'Yesterday',
unread: true,
tag: 'Design',
},
{
from: 'Marcus Reed',
initials: 'MR',
subject: 'Discovery findings, second pass',
preview: 'Interview notes are synthesised — summary tomorrow morning…',
time: 'Tue',
unread: false,
tag: 'Research',
},
] as const
/** A two-pane mail client shell — a searchable message list and a reading pane with toolbar and inline reply. */
export function MailShell() {
return (
<div className="grid h-[560px] w-full grid-cols-[340px_minmax(0,1fr)] bg-background max-lg:grid-cols-1">
{/* Message list */}
<div className="flex min-h-0 flex-col border-r border-border">
<div className="flex items-center justify-between gap-2 px-4 py-3">
<h2 className="font-heading text-base font-medium text-foreground">Inbox</h2>
<Badge variant="secondary">2 unread</Badge>
</div>
<div className="px-4 pb-3">
<Label htmlFor="mail-search" className="sr-only">
Search mail
</Label>
<Input id="mail-search" placeholder="Search mail…" />
</div>
<Separator />
<ul className="min-h-0 flex-1 overflow-auto" aria-label="Messages">
{messages.map((m) => (
<li key={m.subject}>
<button
type="button"
// Each row fills the scrolling list, which would cut off an outline drawn outside it. The theme's forced-colours rule (Windows High Contrast) draws it inside elements marked this way.
data-focus-inset=""
className="flex w-full flex-col gap-1 border-b border-border px-4 py-3 text-left transition-colors hover:bg-accent focus-visible:outline-none focus-visible:-outline-offset-2 focus-visible:outline-ring aria-[current=true]:bg-muted"
aria-current={m.subject === messages[0].subject}
>
<div className="flex items-baseline justify-between gap-2">
<span className={`text-sm ${m.unread ? 'font-semibold text-foreground' : 'font-medium text-muted-foreground'}`}>
{m.from}
</span>
<span className="shrink-0 text-xs text-muted-foreground">{m.time}</span>
</div>
<span className="text-sm font-medium text-foreground">{m.subject}</span>
<span className="line-clamp-1 text-xs text-muted-foreground">{m.preview}</span>
</button>
</li>
))}
</ul>
</div>
{/* Reading pane */}
<div className="flex min-h-0 flex-col max-lg:hidden">
<div className="flex items-center gap-1 border-b border-border px-4 py-2">
<Button variant="ghost" size="icon-sm" aria-label="Archive">
<Icon name="archive" size={18} />
</Button>
<Button variant="ghost" size="icon-sm" aria-label="Delete">
<Icon name="delete" size={18} />
</Button>
<Separator orientation="vertical" className="mx-1 h-4 data-vertical:self-center" />
<Button variant="ghost" size="icon-sm" aria-label="Reply">
<Icon name="reply" size={18} />
</Button>
<Button variant="ghost" size="icon-sm" aria-label="Forward">
<Icon name="forward" size={18} />
</Button>
<span className="ml-auto text-xs text-muted-foreground">1 of 24</span>
</div>
<div className="flex items-start gap-3 px-6 py-4">
<Avatar>
<AvatarFallback>AL</AvatarFallback>
</Avatar>
<div className="flex flex-col gap-0.5">
<span className="text-sm font-medium text-foreground">Ada Lovelace</span>
<span className="text-xs text-muted-foreground">to Client · 9:12</span>
</div>
<Badge variant="outline" className="ml-auto">
Client
</Badge>
</div>
<Separator />
<div className="min-h-0 flex-1 overflow-auto px-6 py-5">
<h3 className="font-heading text-lg text-foreground">Scope for the Q3 engagement</h3>
<div className="mt-3 flex flex-col gap-3 text-sm leading-relaxed text-muted-foreground">
<p>
Revised deliverables are in the shared folder — the component inventory held up
even at the smallest breakpoint, and the dark variants read exactly as we hoped.
</p>
<p>
I’ve queued the remaining two flows for tomorrow. If review lands on time we
should have the full set ready by Thursday.
</p>
<p>— A.</p>
</div>
</div>
<Separator />
<div className="flex items-center gap-2 px-6 py-3">
<Label htmlFor="mail-reply" className="sr-only">
Reply
</Label>
<Input id="mail-reply" placeholder="Reply to Ada…" className="flex-1" />
{/* Default size, so Send matches the 32px field beside it. */}
<Button>
Send <Icon name="send" size={14} />
</Button>
</div>
</div>
</div>
)
}
A two-pane mail client shell — a searchable message list and a reading pane with toolbar and inline reply. Do: Hide the reading pane on narrow viewports so the message list gets the full width instead of squeezing both panes. Don't: Force the two-pane layout at phone widths where neither pane has room to be usable. Use list-detail when you need the simpler read-and-select pattern with no search, toolbar, or reply composer. Use chat when the messaging is a live conversational thread, not discrete emails with subjects.
