Area Stacked

import { areaY, defineChart, lineY } from "@tanstack/charts";
import { d3Curve } from "@tanstack/charts/d3/shape";
import { motion } from "@tanstack/charts/motion";
import { tooltip } from "@tanstack/charts/tooltip";
import { Chart } from "@tanstack/react-charts/core";
import { useMemo } from "react";

import { max } from "d3-array";
import { scaleLinear, scalePoint } from "d3-scale";
import { curveNatural } from "d3-shape";

import { Card, CardContent, CardDescription, CardHeader, CardTitle } from "@/components/ui/card";

const motionRenderer = motion({
    initial: "always",
    transition: { type: "spring", stiffness: 170, damping: 18, mass: 1 },
});

const chartData = [
    { month: "January", desktop: 186, mobile: 80 },
    { month: "February", desktop: 305, mobile: 200 },
    { month: "March", desktop: 237, mobile: 120 },
    { month: "April", desktop: 73, mobile: 190 },
    { month: "May", desktop: 209, mobile: 130 },
    { month: "June", desktop: 214, mobile: 140 },
].map((item) => ({
    ...item,
    stackedMobile: item.mobile,
    stackedDesktop: item.mobile + item.desktop,
}));

export function AreaStacked() {
    const definition = useMemo(() => {
        const yMax = max(chartData, (d) => d.stackedDesktop) ?? 0;

        return defineChart({
            renderer: motionRenderer,
            motion: {
                transition: { type: "spring", stiffness: 170, damping: 18, mass: 1 },
            },
            focus: "group-x",
            tooltip: {
                use: tooltip,
                motion: { type: "spring", stiffness: 170, damping: 18 },
                className: "font-sans! shadow-none! capitalize!",
                content: (points) => {
                    const datum = points[0]?.datum as (typeof chartData)[number];
                    if (!datum) return { rows: [] };
                    return {
                        title: String(points[0].xValue),
                        rows: [
                            {
                                label: "Desktop",
                                value: String(datum.desktop),
                                color: "var(--chart-1)",
                            },
                            {
                                label: "Mobile",
                                value: String(datum.mobile),
                                color: "var(--chart-2)",
                            },
                        ],
                    };
                },
            },
            marks: [
                areaY(chartData, {
                    id: "mobile",
                    x: (d) => d.month.slice(0, 3),
                    y: (d) => d.stackedMobile,
                    fill: "var(--chart-2)",
                    fillOpacity: 0.4,
                    curve: d3Curve(curveNatural),
                }),
                lineY(chartData, {
                    id: "mobile-line",
                    x: (d) => d.month.slice(0, 3),
                    y: (d) => d.stackedMobile,
                    stroke: "var(--chart-2)",
                    strokeWidth: 2,
                    curve: d3Curve(curveNatural),
                    points: false,
                }),
                areaY(chartData, {
                    id: "desktop",
                    x: (d) => d.month.slice(0, 3),
                    y: (d) => d.stackedDesktop,
                    fill: "var(--chart-1)",
                    fillOpacity: 0.4,
                    curve: d3Curve(curveNatural),
                }),
                lineY(chartData, {
                    id: "desktop-line",
                    x: (d) => d.month.slice(0, 3),
                    y: (d) => d.stackedDesktop,
                    stroke: "var(--chart-1)",
                    strokeWidth: 2,
                    curve: d3Curve(curveNatural),
                    points: false,
                }),
            ],
            scales: {
                x: {
                    scale: scalePoint().domain(chartData.map((d) => d.month.slice(0, 3))),
                },
                y: {
                    scale: scaleLinear().domain([0, yMax]).nice(),
                    grid: true,
                },
            },
        });
    }, []);

    return (
        <Card className="gap-3">
            <CardHeader>
                <CardTitle className="text-lg">Cloud Storage Footprint</CardTitle>
                <CardDescription>Cumulative primary database and disaster-recovery backup storage</CardDescription>
            </CardHeader>
            <CardContent>
                <Chart
                    definition={definition}
                    renderer={motionRenderer}
                    height={250}
                    ariaLabel="Stacked area chart showing combined desktop and mobile website traffic"
                />
            </CardContent>
        </Card>
    );
}
