Full-page not-found screen with a pure-SVG Sad Mac, hex error codes and a Restart link home. Dark and light variants.
@nostalgia-ui
registry/new-york/blocks/sad-mac-404.tsx
import * as React from "react"
import { cn } from "@/lib/utils"
import { RetroButton } from "@/registry/new-york/ui/retro-button"
// Spread rather than a literal `asChild` attribute: the shadcn CLI rewrites
// literal `asChild` to Base UI's `render` prop in base-* projects, which
// breaks these Radix-based components.
const AS_CHILD = { asChild: true } as const
/* ------------------------------------------------------------------ */
/* Sad Mac artwork — pixel-grid SVG, no image assets */
/* ------------------------------------------------------------------ */
function SadMacArt({ className }: { className?: string }) {
return (
<svg
viewBox="0 0 24 32"
width={96}
height={128}
className={className}
shapeRendering="crispEdges"
aria-hidden
>
{/* Case */}
<rect x="0.5" y="0.5" width="23" height="26" fill="var(--os9-white)" stroke="var(--os9-black)" />
{/* Screen */}
<rect x="3.5" y="3.5" width="17" height="13" fill="var(--os9-white)" stroke="var(--os9-black)" />
<g fill="var(--os9-black)">
{/* X eyes */}
<rect x="7" y="6" width="1" height="1" />
<rect x="9" y="6" width="1" height="1" />
<rect x="8" y="7" width="1" height="1" />
<rect x="7" y="8" width="1" height="1" />
<rect x="9" y="8" width="1" height="1" />
<rect x="14" y="6" width="1" height="1" />
<rect x="16" y="6" width="1" height="1" />
<rect x="15" y="7" width="1" height="1" />
<rect x="14" y="8" width="1" height="1" />
<rect x="16" y="8" width="1" height="1" />
{/* Nose */}
<rect x="12" y="7" width="1" height="4" />
<rect x="11" y="10" width="1" height="1" />
{/* Frown */}
<rect x="9" y="12" width="6" height="1" />
<rect x="8" y="13" width="1" height="1" />
<rect x="15" y="13" width="1" height="1" />
{/* Floppy slot */}
<rect x="13" y="21" width="7" height="1" />
{/* Logo badge */}
<rect x="4" y="21" width="2" height="2" />
</g>
{/* Foot */}
<rect x="2.5" y="26.5" width="19" height="4" fill="var(--os9-white)" stroke="var(--os9-black)" />
</svg>
)
}
/* ------------------------------------------------------------------ */
/* SadMac404Block */
/* ------------------------------------------------------------------ */
interface SadMac404BlockProps
extends Omit<React.HTMLAttributes<HTMLDivElement>, "children"> {
/** Error code shown on the second line (zero-padded to 8 characters). Defaults to 404. */
code?: string | number
/** Where the Restart button links to. Defaults to "/". */
homeHref?: string
/** "dark" is the classic black screen; "light" sits on a platinum background. */
variant?: "dark" | "light"
/** Short explanation below the codes. Pass `null` to hide. */
message?: React.ReactNode
/** Label for the home link. Defaults to "Restart". */
restartLabel?: string
}
function toHexLine(value: string | number) {
return String(value).toUpperCase().padStart(8, "0").slice(-8)
}
const SadMac404Block = React.forwardRef<HTMLDivElement, SadMac404BlockProps>(
function SadMac404Block(
{
code = 404,
homeHref = "/",
variant = "dark",
message = "The page you were looking for could not be found.",
restartLabel = "Restart",
className,
...props
},
ref
) {
const dark = variant === "dark"
return (
<div
ref={ref}
className={cn(
"flex min-h-dvh w-full flex-col items-center justify-center gap-6 px-6 py-10 text-center",
dark ? "bg-os9-black text-os9-white" : "bg-os9-gray-200 text-os9-black",
className
)}
{...props}
>
<SadMacArt className="h-auto w-[72px] sm:w-[96px]" />
<h1 className="sr-only">Page not found (error {String(code)})</h1>
<div
aria-hidden
className="font-[family-name:var(--os9-font-heading)] text-[14px] leading-[1.4] tracking-[2px] tabular-nums"
>
<div>0000000F</div>
<div>{toHexLine(code)}</div>
</div>
{message !== null && (
<p
className={cn(
"max-w-[320px] font-[family-name:var(--os9-font-sans)] text-[11px] leading-[1.5]",
dark ? "text-os9-gray-600" : "text-os9-gray-800"
)}
>
{message}
</p>
)}
<RetroButton {...AS_CHILD} className="min-w-[90px] no-underline">
<a href={homeHref}>{restartLabel}</a>
</RetroButton>
</div>
)
}
)
SadMac404Block.displayName = "SadMac404Block"
export { SadMac404Block }
export type { SadMac404BlockProps }
