Mac OS 9 Appearance control panel with Themes, Appearance, Fonts, Desktop, Sound and Options tabs built from group boxes, pop-ups, sliders, checkboxes, radios and little-arrows fields.
@nostalgia-ui


































registry/new-york/blocks/control-panel.tsx
"use client"
import * as React from "react"
import { cn } from "@/lib/utils"
import { RetroButton } from "@/registry/new-york/ui/retro-button"
import { RetroCheckbox } from "@/registry/new-york/ui/retro-checkbox"
import { RetroGroupBox } from "@/registry/new-york/ui/retro-group-box"
import { RetroLabel } from "@/registry/new-york/ui/retro-label"
import { RetroNumberField } from "@/registry/new-york/ui/retro-little-arrows"
import { RetroListBox, RetroListBoxItem } from "@/registry/new-york/ui/retro-list-box"
import { RetroRadioGroup, RetroRadioGroupItem } from "@/registry/new-york/ui/retro-radio"
import {
RetroSelect,
RetroSelectContent,
RetroSelectItem,
RetroSelectTrigger,
RetroSelectValue,
} from "@/registry/new-york/ui/retro-select"
import { RetroSlider } from "@/registry/new-york/ui/retro-slider"
import {
RetroTabs,
RetroTabsContent,
RetroTabsList,
RetroTabsTrigger,
} from "@/registry/new-york/ui/retro-tabs"
import { RetroWindow } from "@/registry/new-york/ui/retro-window"
/* ------------------------------------------------------------------ */
/* Data */
/* ------------------------------------------------------------------ */
type ControlPanelTab = "themes" | "appearance" | "fonts" | "desktop" | "sound" | "options"
const TABS: { value: ControlPanelTab; label: string }[] = [
{ value: "themes", label: "Themes" },
{ value: "appearance", label: "Appearance" },
{ value: "fonts", label: "Fonts" },
{ value: "desktop", label: "Desktop" },
{ value: "sound", label: "Sound" },
{ value: "options", label: "Options" },
]
/** Highlight colours are user content, so they carry their own values. */
const HIGHLIGHT_COLORS = [
{ id: "lavender", name: "Lavender", color: "var(--os9-lavender)" },
{ id: "blue", name: "Blue", color: "#99ccff" },
{ id: "gold", name: "Gold", color: "#ffcc66" },
{ id: "graphite", name: "Graphite", color: "var(--os9-gray-400)" },
{ id: "green", name: "Green", color: "#99ee99" },
{ id: "purple", name: "Purple", color: "#cc99ff" },
{ id: "red", name: "Red", color: "#ff9999" },
{ id: "silver", name: "Silver", color: "var(--os9-gray-300)" },
] as const
const DESKTOP_PATTERNS = [
{
id: "mac-os-default",
name: "Mac OS Default",
style: {
backgroundColor: "var(--os9-gray-400)",
backgroundImage: "radial-gradient(var(--os9-gray-700) 0.8px, transparent 0.8px)",
backgroundSize: "4px 4px",
},
},
{
id: "azul-dots",
name: "Azul Dots",
style: {
backgroundColor: "var(--os9-azul)",
backgroundImage: "radial-gradient(var(--os9-focus) 1px, transparent 1px)",
backgroundSize: "6px 6px",
},
},
{
id: "lavender-stripes",
name: "Lavender Stripes",
style: {
backgroundColor: "var(--os9-lavender)",
backgroundImage:
"repeating-linear-gradient(90deg, transparent 0 3px, var(--os9-white) 3px 4px)",
},
},
{
id: "platinum-grid",
name: "Platinum Grid",
style: {
backgroundColor: "var(--os9-gray-300)",
backgroundImage:
"linear-gradient(var(--os9-gray-500) 1px, transparent 1px), linear-gradient(90deg, var(--os9-gray-500) 1px, transparent 1px)",
backgroundSize: "8px 8px",
},
},
{
id: "checkerboard",
name: "Checkerboard",
style: {
backgroundColor: "var(--os9-gray-200)",
backgroundImage:
"conic-gradient(var(--os9-gray-600) 25%, transparent 0 50%, var(--os9-gray-600) 0 75%, transparent 0)",
backgroundSize: "4px 4px",
},
},
{
id: "solid-gray",
name: "Solid Gray",
style: { backgroundColor: "var(--os9-gray-600)" },
},
] as const satisfies readonly { id: string; name: string; style: React.CSSProperties }[]
const THEMES = [
{ id: "mac-os-default", name: "Mac OS Default", highlight: "lavender", pattern: "mac-os-default" },
{ id: "hicontrast", name: "Mac OS HiContrast", highlight: "silver", pattern: "solid-gray" },
{ id: "drawing-board", name: "Drawing Board", highlight: "gold", pattern: "platinum-grid" },
{ id: "gizmo", name: "Gizmo", highlight: "purple", pattern: "azul-dots" },
{ id: "sensible", name: "Sensible", highlight: "green", pattern: "lavender-stripes" },
{ id: "cafe", name: "Cafe", highlight: "red", pattern: "checkerboard" },
] as const
const LARGE_FONTS = ["Charcoal", "Chicago", "Gadget", "Sand", "Techno", "Textile"]
const SMALL_FONTS = ["Geneva", "Helvetica", "Monaco"]
/* ------------------------------------------------------------------ */
/* Settings */
/* ------------------------------------------------------------------ */
interface ControlPanelSettings {
theme: string
appearance: string
highlightColor: string
variation: string
largeFont: string
smallFont: string
viewsFont: string
viewsFontSize: number
smoothFonts: boolean
smoothFontsMinSize: number
desktopPattern: string
soundTrack: string
sounds: { menus: boolean; windows: boolean; controls: boolean; finder: boolean }
volume: number
smartScrolling: boolean
collapseOnDoubleClick: boolean
scrollArrows: "together" | "both"
menuBlinks: number
}
const DEFAULT_SETTINGS: ControlPanelSettings = {
theme: "mac-os-default",
appearance: "platinum",
highlightColor: "lavender",
variation: "blue",
largeFont: "Charcoal",
smallFont: "Geneva",
viewsFont: "Geneva",
viewsFontSize: 10,
smoothFonts: true,
smoothFontsMinSize: 12,
desktopPattern: "mac-os-default",
soundTrack: "platinum",
sounds: { menus: true, windows: true, controls: true, finder: false },
volume: 60,
smartScrolling: true,
collapseOnDoubleClick: true,
scrollArrows: "together",
menuBlinks: 1,
}
interface ControlPanelBlockProps
extends Omit<
React.ComponentPropsWithoutRef<typeof RetroWindow>,
"title" | "children" | "onChange" | "defaultValue"
> {
/** Initially selected tab. Defaults to "themes". */
defaultTab?: ControlPanelTab
/** Initial settings (merged over the Mac OS defaults). */
defaultSettings?: Partial<ControlPanelSettings>
/** Fired with the full settings object after every change. */
onChange?: (settings: ControlPanelSettings) => void
/** Window title. Defaults to "Appearance". */
title?: string
}
/* ------------------------------------------------------------------ */
/* Small building blocks */
/* ------------------------------------------------------------------ */
const TEXT = "font-[family-name:var(--os9-font-sans)] text-[10px] leading-[1.4] text-os9-black"
/** Label column + control column; stacks on narrow widths. */
function Row({
label,
htmlFor,
labelId,
children,
}: {
label: string
htmlFor?: string
labelId?: string
children: React.ReactNode
}) {
return (
<div className="grid grid-cols-[140px_minmax(0,1fr)] items-center gap-x-2 max-[480px]:grid-cols-1 max-[480px]:gap-y-1">
<RetroLabel
size="lg"
htmlFor={htmlFor}
id={labelId}
className="text-right max-[480px]:text-left"
>
{label}
</RetroLabel>
<div className="flex min-w-0 items-center gap-2">{children}</div>
</div>
)
}
function PopUp({
value,
onValueChange,
labelledBy,
className,
children,
}: {
value: string
onValueChange: (value: string) => void
labelledBy: string
className?: string
children: React.ReactNode
}) {
return (
<RetroSelect value={value} onValueChange={onValueChange}>
<RetroSelectTrigger aria-labelledby={labelledBy} className={cn("w-[200px] max-w-full", className)}>
<RetroSelectValue />
</RetroSelectTrigger>
<RetroSelectContent>{children}</RetroSelectContent>
</RetroSelect>
)
}
function CheckRow({
id,
checked,
onCheckedChange,
children,
}: {
id: string
checked: boolean
onCheckedChange: (checked: boolean) => void
children: React.ReactNode
}) {
return (
<div className="flex items-center gap-2">
<RetroCheckbox id={id} checked={checked} onCheckedChange={(c) => onCheckedChange(c === true)} />
<RetroLabel htmlFor={id} className="text-[10px]">
{children}
</RetroLabel>
</div>
)
}
function Swatch({ color }: { color: string }) {
return (
<span
aria-hidden="true"
className="inline-block size-[10px] shrink-0 border border-os9-black align-[-1px]"
style={{ background: color }}
/>
)
}
function patternStyle(id: string): React.CSSProperties {
return (DESKTOP_PATTERNS.find((p) => p.id === id) ?? DESKTOP_PATTERNS[0]).style
}
function highlightValue(id: string) {
return (HIGHLIGHT_COLORS.find((c) => c.id === id) ?? HIGHLIGHT_COLORS[0]).color
}
/** Tiny desktop-with-window preview used by theme tiles. */
function ThemePreview({ pattern, highlight }: { pattern: string; highlight: string }) {
return (
<span
aria-hidden="true"
className="relative block h-[48px] w-[72px] border border-os9-black"
style={patternStyle(pattern)}
>
<span className="absolute inset-x-0 top-0 h-[5px] border-b border-os9-black bg-os9-gray-300" />
<span className="absolute left-[10px] top-[12px] h-[28px] w-[44px] border border-os9-black bg-os9-white shadow-[1px_1px_0_var(--os9-black)]">
<span className="os9-stripes block h-[5px] border-b border-os9-black" />
<span className="mx-[4px] mt-[4px] block h-[4px]" style={{ background: highlightValue(highlight) }} />
<span className="mx-[4px] mt-[3px] block h-px bg-os9-gray-600" />
<span className="mx-[4px] mt-[3px] block h-px w-[20px] bg-os9-gray-600" />
</span>
</span>
)
}
/* ------------------------------------------------------------------ */
/* ControlPanelBlock */
/* ------------------------------------------------------------------ */
const ControlPanelBlock = React.forwardRef<HTMLDivElement, ControlPanelBlockProps>(
function ControlPanelBlock(
{
defaultTab = "themes",
defaultSettings,
onChange,
title = "Appearance",
className,
contentClassName,
...props
},
ref
) {
const id = React.useId()
const [tab, setTab] = React.useState<ControlPanelTab>(defaultTab)
const [settings, setSettings] = React.useState<ControlPanelSettings>(() => ({
...DEFAULT_SETTINGS,
...defaultSettings,
}))
const update = (patch: Partial<ControlPanelSettings>) => {
const next = { ...settings, ...patch }
setSettings(next)
onChange?.(next)
}
const s = settings
return (
<RetroWindow
ref={ref}
title={title}
className={cn("w-full max-w-[560px]", className)}
contentClassName={cn("p-[12px] max-[480px]:p-[6px]", contentClassName)}
{...props}
>
<RetroTabs value={tab} onValueChange={(v) => setTab(v as ControlPanelTab)}>
<RetroTabsList className="overflow-x-auto overflow-y-hidden pt-[3px] [scrollbar-width:none]">
{TABS.map((t) => (
<RetroTabsTrigger key={t.value} value={t.value} className="shrink-0 max-[480px]:px-[8px]">
{t.label}
</RetroTabsTrigger>
))}
</RetroTabsList>
{/* ---------------- Themes ---------------- */}
<RetroTabsContent value="themes" className="flex min-h-[300px] flex-col gap-3">
<p className={TEXT}>
Click a theme to change the appearance of your computer. A theme
sets the highlight colour, desktop pattern, fonts and sounds.
</p>
<RetroListBox
aria-label="Themes"
value={s.theme}
onValueChange={(v) => {
const theme = THEMES.find((t) => t.id === v)
if (!theme) return
update({ theme: theme.id, highlightColor: theme.highlight, desktopPattern: theme.pattern })
}}
className="grid grid-cols-[repeat(auto-fill,minmax(88px,1fr))] gap-[6px] overflow-y-auto p-[6px] max-h-[220px]"
>
{THEMES.map((t) => (
<RetroListBoxItem
key={t.id}
value={t.id}
textValue={t.name}
className="group/theme h-auto flex-col gap-[4px] whitespace-normal bg-transparent p-[4px] data-[selected]:bg-transparent data-[selected]:text-os9-black"
>
<span className="p-[2px] group-data-[selected]/theme:bg-os9-azul">
<ThemePreview pattern={t.pattern} highlight={t.highlight} />
</span>
<span className="px-[2px] text-center leading-[1.3] group-data-[selected]/theme:bg-os9-azul group-data-[selected]/theme:text-os9-white">
{t.name}
</span>
</RetroListBoxItem>
))}
</RetroListBox>
</RetroTabsContent>
{/* ---------------- Appearance ---------------- */}
<RetroTabsContent value="appearance" className="flex min-h-[300px] flex-col gap-3">
<RetroGroupBox title="Appearance" contentClassName="flex flex-col gap-2">
<Row label="Appearance:" labelId={`${id}-appearance`}>
<PopUp value={s.appearance} onValueChange={(v) => update({ appearance: v })} labelledBy={`${id}-appearance`}>
<RetroSelectItem value="platinum">Apple Platinum</RetroSelectItem>
</PopUp>
</Row>
</RetroGroupBox>
<RetroGroupBox title="Colors" contentClassName="flex flex-col gap-2">
<Row label="Highlight Color:" labelId={`${id}-highlight`}>
<RetroSelect value={s.highlightColor} onValueChange={(v) => update({ highlightColor: v })}>
<RetroSelectTrigger aria-labelledby={`${id}-highlight`} className="w-[200px] max-w-full">
<RetroSelectValue />
</RetroSelectTrigger>
<RetroSelectContent>
{HIGHLIGHT_COLORS.map((c) => (
<RetroSelectItem key={c.id} value={c.id}>
<span className="flex items-center gap-[6px]">
<Swatch color={c.color} />
{c.name}
</span>
</RetroSelectItem>
))}
</RetroSelectContent>
</RetroSelect>
</Row>
<Row label="Variation:" labelId={`${id}-variation`}>
<PopUp value={s.variation} onValueChange={(v) => update({ variation: v })} labelledBy={`${id}-variation`}>
<RetroSelectItem value="blue">Blue</RetroSelectItem>
<RetroSelectItem value="graphite">Graphite</RetroSelectItem>
</PopUp>
</Row>
<Row label="Sample:">
<p className={cn(TEXT, "truncate")}>
Some{" "}
<span className="px-[1px]" style={{ background: highlightValue(s.highlightColor) }}>
selected text
</span>{" "}
in a document.
</p>
</Row>
</RetroGroupBox>
</RetroTabsContent>
{/* ---------------- Fonts ---------------- */}
<RetroTabsContent value="fonts" className="flex min-h-[300px] flex-col gap-3">
<RetroGroupBox title="System Fonts" contentClassName="flex flex-col gap-2">
<Row label="Large System Font:" labelId={`${id}-large`}>
<PopUp value={s.largeFont} onValueChange={(v) => update({ largeFont: v })} labelledBy={`${id}-large`}>
{LARGE_FONTS.map((f) => (
<RetroSelectItem key={f} value={f}>{f}</RetroSelectItem>
))}
</PopUp>
</Row>
<Row label="Small System Font:" labelId={`${id}-small`}>
<PopUp value={s.smallFont} onValueChange={(v) => update({ smallFont: v })} labelledBy={`${id}-small`}>
{SMALL_FONTS.map((f) => (
<RetroSelectItem key={f} value={f}>{f}</RetroSelectItem>
))}
</PopUp>
</Row>
<Row label="Views Font:" labelId={`${id}-views`}>
<PopUp
value={s.viewsFont}
onValueChange={(v) => update({ viewsFont: v })}
labelledBy={`${id}-views`}
className="w-[130px]"
>
{SMALL_FONTS.map((f) => (
<RetroSelectItem key={f} value={f}>{f}</RetroSelectItem>
))}
</PopUp>
<RetroLabel htmlFor={`${id}-views-size`} className="shrink-0">Size:</RetroLabel>
<RetroNumberField
id={`${id}-views-size`}
size="sm"
min={9}
max={24}
value={s.viewsFontSize}
onValueChange={(v) => update({ viewsFontSize: v })}
inputClassName="w-[36px]"
/>
</Row>
</RetroGroupBox>
<RetroGroupBox
title={
<CheckRow
id={`${id}-smooth`}
checked={s.smoothFonts}
onCheckedChange={(c) => update({ smoothFonts: c })}
>
<span className="font-[family-name:var(--os9-font-heading)] text-[12px] tracking-[0.42px]">
Smooth all fonts on screen
</span>
</CheckRow>
}
contentClassName="flex flex-col gap-2"
>
<div className={cn("flex flex-wrap items-center gap-2", !s.smoothFonts && "opacity-50")}>
<RetroLabel htmlFor={`${id}-smooth-size`}>Smooth fonts at sizes</RetroLabel>
<RetroNumberField
id={`${id}-smooth-size`}
size="sm"
min={9}
max={24}
disabled={!s.smoothFonts}
value={s.smoothFontsMinSize}
onValueChange={(v) => update({ smoothFontsMinSize: v })}
inputClassName="w-[36px]"
/>
<span className={TEXT}>and above</span>
</div>
</RetroGroupBox>
</RetroTabsContent>
{/* ---------------- Desktop ---------------- */}
<RetroTabsContent value="desktop" className="flex min-h-[300px] flex-wrap gap-4">
<div className="flex flex-col items-center gap-2">
{/* Monitor preview */}
<div className="border border-os9-black bg-os9-gray-300 p-[6px] pb-[14px] shadow-[var(--os9-shadow-raised)]">
<div
aria-label="Desktop preview"
role="img"
className="h-[96px] w-[128px] border border-os9-black"
style={patternStyle(s.desktopPattern)}
/>
</div>
<p className={cn(TEXT, "text-center")}>
{DESKTOP_PATTERNS.find((p) => p.id === s.desktopPattern)?.name}
</p>
</div>
<div className="flex min-w-[180px] flex-1 flex-col gap-2">
<RetroLabel size="lg" id={`${id}-patterns`}>Patterns</RetroLabel>
<RetroListBox
aria-labelledby={`${id}-patterns`}
value={s.desktopPattern}
onValueChange={(v) => v && update({ desktopPattern: v })}
className="h-[140px]"
>
{DESKTOP_PATTERNS.map((p) => (
<RetroListBoxItem key={p.id} value={p.id}>
<span aria-hidden="true" className="size-[10px] shrink-0 border border-os9-black" style={p.style} />
{p.name}
</RetroListBoxItem>
))}
</RetroListBox>
<div className="flex flex-wrap gap-2">
<RetroButton size="sm" type="button" disabled>Place Picture…</RetroButton>
<RetroButton size="sm" type="button" disabled>Remove Picture</RetroButton>
</div>
</div>
</RetroTabsContent>
{/* ---------------- Sound ---------------- */}
<RetroTabsContent value="sound" className="flex min-h-[300px] flex-col gap-3">
<Row label="Sound track:" labelId={`${id}-track`}>
<PopUp value={s.soundTrack} onValueChange={(v) => update({ soundTrack: v })} labelledBy={`${id}-track`}>
<RetroSelectItem value="platinum">Platinum Sounds</RetroSelectItem>
<RetroSelectItem value="none">None</RetroSelectItem>
</PopUp>
</Row>
<RetroGroupBox title="Play sounds for:" contentClassName="grid grid-cols-2 gap-2 max-[420px]:grid-cols-1">
{(
[
["menus", "Menus"],
["windows", "Windows"],
["controls", "Controls"],
["finder", "Finder"],
] as const
).map(([key, label]) => (
<CheckRow
key={key}
id={`${id}-sound-${key}`}
checked={s.sounds[key] && s.soundTrack !== "none"}
onCheckedChange={(c) => update({ sounds: { ...s.sounds, [key]: c } })}
>
{label}
</CheckRow>
))}
</RetroGroupBox>
<RetroGroupBox title="Volume" contentClassName="flex items-center gap-3">
<span className={TEXT} aria-hidden="true">Quiet</span>
<RetroSlider
aria-label="Volume"
min={0}
max={100}
step={1}
value={[s.volume]}
onValueChange={([v]) => update({ volume: v })}
className="flex-1"
/>
<span className={TEXT} aria-hidden="true">Loud</span>
</RetroGroupBox>
</RetroTabsContent>
{/* ---------------- Options ---------------- */}
<RetroTabsContent value="options" className="flex min-h-[300px] flex-col gap-3">
<RetroGroupBox title="Scrolling" contentClassName="flex flex-col gap-2">
<CheckRow
id={`${id}-smart`}
checked={s.smartScrolling}
onCheckedChange={(c) => update({ smartScrolling: c })}
>
Smart Scrolling (proportional scroll boxes)
</CheckRow>
<p className={cn(TEXT, "mt-1")} id={`${id}-arrows`}>Scroll arrows:</p>
<RetroRadioGroup
aria-labelledby={`${id}-arrows`}
value={s.scrollArrows}
onValueChange={(v) => update({ scrollArrows: v as ControlPanelSettings["scrollArrows"] })}
className="gap-1.5 pl-3"
>
<div className="flex items-center gap-2">
<RetroRadioGroupItem id={`${id}-arrows-together`} value="together" />
<RetroLabel htmlFor={`${id}-arrows-together`}>Together</RetroLabel>
</div>
<div className="flex items-center gap-2">
<RetroRadioGroupItem id={`${id}-arrows-both`} value="both" />
<RetroLabel htmlFor={`${id}-arrows-both`}>At top and bottom</RetroLabel>
</div>
</RetroRadioGroup>
</RetroGroupBox>
<RetroGroupBox title="Windows & Menus" contentClassName="flex flex-col gap-2">
<CheckRow
id={`${id}-collapse`}
checked={s.collapseOnDoubleClick}
onCheckedChange={(c) => update({ collapseOnDoubleClick: c })}
>
Double-click title bar to collapse windows
</CheckRow>
<div className="flex items-center gap-2">
<RetroLabel htmlFor={`${id}-blinks`}>Menu blinking:</RetroLabel>
<RetroNumberField
id={`${id}-blinks`}
size="sm"
min={0}
max={3}
value={s.menuBlinks}
onValueChange={(v) => update({ menuBlinks: v })}
formatValue={(v) => (v === 0 ? "Off" : String(v))}
inputClassName="w-[36px]"
/>
<span className={TEXT}>{s.menuBlinks === 1 ? "time" : "times"}</span>
</div>
</RetroGroupBox>
</RetroTabsContent>
</RetroTabs>
</RetroWindow>
)
}
)
ControlPanelBlock.displayName = "ControlPanelBlock"
export { ControlPanelBlock, DEFAULT_SETTINGS as CONTROL_PANEL_DEFAULT_SETTINGS }
export type { ControlPanelBlockProps, ControlPanelSettings, ControlPanelTab }
