Public product roadmap with Planned, In progress and Shipped columns or a quarter timeline, where cards fly between the two views through shared layout, re-sort by votes as you upvote with a direction-aware rolling count, carry tag badges, and can be filtered by status.
@karaui
"use client";
// karaui.kamisama-v0.my.id/components/blocks/roadmap
import { ChevronUp, Columns3, ListTree } from "lucide-react";
import {
AnimatePresence,
LayoutGroup,
motion,
useReducedMotion,
type Variants,
} from "motion/react";
import { useCallback, useId, useMemo, useState } from "react";
import { Badge, type BadgeVariant } from "@/components/motion/badge";
import { EmptyState } from "@/components/motion/empty-state";
import { SegmentedControl } from "@/components/motion/segmented-control";
import { ToggleGroup, ToggleGroupItem } from "@/components/motion/toggle-group";
import { EASE_OUT, SPRING_LAYOUT, SPRING_PRESS, SPRING_SWAP } from "@/lib/ease";
import { cn } from "@/lib/utils";
export type RoadmapStatus = "planned" | "in-progress" | "shipped";
export type RoadmapView = "board" | "timeline";
export interface RoadmapItem {
id: string;
title: string;
description?: string;
status: RoadmapStatus;
tags?: string[];
votes: number;
/** The current viewer has upvoted this item. */
voted?: boolean;
/** Timeline bucket, e.g. "Q4 2026". Items without one land in "Later". */
quarter?: string;
}
export interface RoadmapProps {
items?: RoadmapItem[];
defaultItems?: RoadmapItem[];
onItemsChange?: (items: RoadmapItem[]) => void;
view?: RoadmapView;
defaultView?: RoadmapView;
onViewChange?: (view: RoadmapView) => void;
/** Visible statuses (the status filter). Default: all three. */
statuses?: RoadmapStatus[];
defaultStatuses?: RoadmapStatus[];
onStatusesChange?: (statuses: RoadmapStatus[]) => void;
/** Fires after the optimistic vote toggle. */
onVote?: (id: string, voted: boolean) => void;
/** Quarter order for the timeline view; defaults to first-seen order. */
quarters?: string[];
className?: string;
}
const STATUSES: RoadmapStatus[] = ["planned", "in-progress", "shipped"];
const STATUS_LABEL: Record<RoadmapStatus, string> = {
planned: "Planned",
"in-progress": "In progress",
shipped: "Shipped",
};
const STATUS_DOT: Record<RoadmapStatus, string> = {
planned: "bg-chart-2",
"in-progress": "bg-warning",
shipped: "bg-success",
};
const STATUS_BADGE: Record<RoadmapStatus, BadgeVariant> = {
planned: "secondary",
"in-progress": "warning",
shipped: "success",
};
function useControllable<T>(
value: T | undefined,
defaultValue: T,
onChange: ((next: T) => void) | undefined,
) {
const [internal, setInternal] = useState(defaultValue);
const controlled = value !== undefined;
const current = controlled ? value : internal;
const set = useCallback(
(next: T) => {
if (!controlled) setInternal(next);
onChange?.(next);
},
[controlled, onChange],
);
return [current, set] as const;
}
const byVotes = (a: RoadmapItem, b: RoadmapItem) => b.votes - a.votes;
export function Roadmap({
items: itemsProp,
defaultItems = [],
onItemsChange,
view: viewProp,
defaultView = "board",
onViewChange,
statuses: statusesProp,
defaultStatuses = STATUSES,
onStatusesChange,
onVote,
quarters: quartersProp,
className,
}: RoadmapProps) {
const uid = useId();
const reduce = useReducedMotion() ?? false;
const [items, setItems] = useControllable(itemsProp, defaultItems, onItemsChange);
const [view, setView] = useControllable(viewProp, defaultView, onViewChange);
const [statuses, setStatuses] = useControllable(statusesProp, defaultStatuses, onStatusesChange);
const visible = useMemo(() => items.filter((i) => statuses.includes(i.status)), [items, statuses]);
const vote = (id: string) => {
let next = false;
setItems(
items.map((item) => {
if (item.id !== id) return item;
next = !item.voted;
return { ...item, voted: next, votes: item.votes + (next ? 1 : -1) };
}),
);
onVote?.(id, next);
};
const quarters = useMemo(() => {
const seen = quartersProp ? [...quartersProp] : [];
for (const i of visible) {
const q = i.quarter ?? "Later";
if (!seen.includes(q)) seen.push(q);
}
return seen.filter((q) => visible.some((i) => (i.quarter ?? "Later") === q));
}, [visible, quartersProp]);
const visibleStatuses = STATUSES.filter((s) => statuses.includes(s));
return (
<div className={cn("@container flex w-full flex-col gap-4 text-sm", className)}>
<div className="flex flex-wrap items-center justify-between gap-2">
<ToggleGroup
type="multiple"
variant="outline"
size="sm"
aria-label="Filter by status"
value={statuses}
onValueChange={(v) => setStatuses(STATUSES.filter((s) => v.includes(s)))}
>
{STATUSES.map((s) => (
<ToggleGroupItem key={s} value={s}>
<span aria-hidden="true" className={cn("size-2 rounded-full", STATUS_DOT[s])} />
{STATUS_LABEL[s]}
</ToggleGroupItem>
))}
</ToggleGroup>
<SegmentedControl
aria-label="View"
size="sm"
value={view}
onValueChange={(v) => setView(v as RoadmapView)}
options={[
{ value: "board", label: "Board", icon: <Columns3 aria-hidden="true" /> },
{ value: "timeline", label: "Timeline", icon: <ListTree aria-hidden="true" /> },
]}
/>
</div>
{visible.length === 0 ? (
<EmptyState size="sm" bordered title="Nothing to show" description="Turn on a status to see its items." />
) : (
// Cards share a layoutId across views, so switching Board ↔ Timeline
// flies each card to its new slot instead of re-rendering the list.
<LayoutGroup id={uid}>
{view === "board" ? (
<div
className={cn(
"grid gap-3",
visibleStatuses.length === 3 && "@lg:grid-cols-3",
visibleStatuses.length === 2 && "@md:grid-cols-2",
)}
>
{visibleStatuses.map((status) => {
const column = visible.filter((i) => i.status === status).sort(byVotes);
return (
<section
key={status}
aria-labelledby={`${uid}-${status}`}
className="flex min-w-0 flex-col gap-2 rounded-xl border border-border bg-muted/40 p-2"
>
<h3
id={`${uid}-${status}`}
className="flex items-center gap-2 px-1.5 pt-1 text-xs font-medium text-muted-foreground"
>
<span aria-hidden="true" className={cn("size-2 rounded-full", STATUS_DOT[status])} />
{STATUS_LABEL[status]}
<span className="ml-auto font-mono tabular-nums">{column.length}</span>
</h3>
<ul className="flex flex-col gap-2">
<AnimatePresence initial={false} mode="popLayout">
{column.map((item) => (
<RoadmapCard key={item.id} uid={uid} item={item} reduce={reduce} onVote={vote} />
))}
</AnimatePresence>
</ul>
</section>
);
})}
</div>
) : (
<ol className="flex flex-col gap-4">
{quarters.map((quarter, qi) => (
<li key={quarter} className="relative grid grid-cols-[4.5rem_1fr] gap-3">
<div className="relative pt-2 text-right">
<span className="font-mono text-xs font-semibold text-foreground">{quarter}</span>
{qi < quarters.length - 1 && (
<span aria-hidden="true" className="absolute -right-[7px] top-6 -bottom-6 w-px bg-border" />
)}
<span
aria-hidden="true"
className="absolute -right-[11px] top-3 size-2 rounded-full bg-foreground/40 ring-4 ring-background"
/>
</div>
<ul className="flex flex-col gap-2 pl-2">
<AnimatePresence initial={false} mode="popLayout">
{visible
.filter((i) => (i.quarter ?? "Later") === quarter)
.sort(
(a, b) => STATUSES.indexOf(b.status) - STATUSES.indexOf(a.status) || byVotes(a, b),
)
.map((item) => (
<RoadmapCard key={item.id} uid={uid} item={item} reduce={reduce} onVote={vote} showStatus />
))}
</AnimatePresence>
</ul>
</li>
))}
</ol>
)}
</LayoutGroup>
)}
</div>
);
}
function RoadmapCard({
uid,
item,
reduce,
onVote,
showStatus,
}: {
uid: string;
item: RoadmapItem;
reduce: boolean;
onVote: (id: string) => void;
showStatus?: boolean;
}) {
return (
<motion.li
layoutId={reduce ? undefined : `${uid}-card-${item.id}`}
layout={!reduce}
initial={reduce ? { opacity: 0 } : { opacity: 0, scale: 0.97 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, transition: { duration: 0.12 } }}
transition={SPRING_LAYOUT}
className="flex gap-3 rounded-lg border border-border bg-card p-3 shadow-sm"
>
<div className="min-w-0 flex-1">
{showStatus && (
<Badge size="sm" variant={STATUS_BADGE[item.status]} dot className="mb-1.5">
{STATUS_LABEL[item.status]}
</Badge>
)}
<p className="font-medium leading-snug text-foreground">{item.title}</p>
{item.description && (
<p className="mt-1 line-clamp-2 text-xs text-muted-foreground">{item.description}</p>
)}
{item.tags?.length ? (
<div className="mt-2 flex flex-wrap gap-1">
{item.tags.map((tag) => (
<Badge key={tag} size="sm" variant="outline">
{tag}
</Badge>
))}
</div>
) : null}
</div>
<UpvoteButton count={item.votes} voted={!!item.voted} title={item.title} reduce={reduce} onClick={() => onVote(item.id)} />
</motion.li>
);
}
const ROLL: Variants = {
enter: (d: number) => ({ y: d > 0 ? "100%" : "-100%", opacity: 0 }),
center: { y: "0%", opacity: 1 },
exit: (d: number) => ({ y: d > 0 ? "-100%" : "100%", opacity: 0 }),
};
const FADE: Variants = { enter: { opacity: 0 }, center: { opacity: 1 }, exit: { opacity: 0 } };
function UpvoteButton({
count,
voted,
title,
reduce,
onClick,
}: {
count: number;
voted: boolean;
title: string;
reduce: boolean;
onClick: () => void;
}) {
// Direction is derived during render from the last seen count (React's
// "adjust state on prop change" pattern), so rolls go up on +1, down on -1.
const [last, setLast] = useState(count);
const [direction, setDirection] = useState(1);
if (count !== last) {
setDirection(count > last ? 1 : -1);
setLast(count);
}
const variants = reduce ? FADE : ROLL;
return (
<motion.button
type="button"
aria-pressed={voted}
aria-label={`Upvote ${title}, ${count} vote${count === 1 ? "" : "s"}`}
onClick={onClick}
whileTap={reduce ? undefined : { scale: 0.9 }}
transition={SPRING_PRESS}
className={cn(
"flex h-12 w-10 shrink-0 flex-col items-center justify-center gap-0.5 rounded-lg border border-border text-xs font-semibold outline-none transition-colors",
"focus-visible:ring-2 focus-visible:ring-ring focus-visible:ring-offset-1 focus-visible:ring-offset-card",
voted
? "border-primary bg-primary text-primary-foreground"
: "border-border bg-background text-foreground hover:border-border-strong hover:bg-muted",
)}
>
<motion.span
aria-hidden="true"
animate={voted && !reduce ? { y: [0, -3, 0] } : { y: 0 }}
transition={{ duration: 0.3, ease: EASE_OUT }}
className="flex"
>
<ChevronUp className="size-4" />
</motion.span>
<span aria-hidden="true" className="relative flex h-4 overflow-hidden font-mono tabular-nums">
<AnimatePresence initial={false} mode="popLayout" custom={direction}>
<motion.span
key={count}
custom={direction}
variants={variants}
initial="enter"
animate="center"
exit="exit"
transition={SPRING_SWAP}
>
{count}
</motion.span>
</AnimatePresence>
</span>
</motion.button>
);
}
