Task board whose cards drag within and across columns, opening a dashed drop slot where they will land, lighting up the column underneath and flying into place via shared layout. Space, arrows and Escape move cards from the keyboard with live announcements. Columns show count badges, cards carry tags, assignee initials and a priority dot, and on mobile the columns scroll horizontally with snap. Controlled/uncontrolled, reduced-motion safe.
@karaui
"use client";
// karaui.kamisama-v0.my.id/components/blocks/kanban-board
import {
type DragControls,
LayoutGroup,
motion,
type PanInfo,
useDragControls,
useReducedMotion,
} from "motion/react";
import {
type KeyboardEvent,
type PointerEvent as ReactPointerEvent,
useCallback,
useEffect,
useId,
useRef,
useState,
} from "react";
import { SPRING_LAYOUT } from "@/lib/ease";
import { TOUCH_GESTURE_CONTENT_CLASS } from "@/lib/touch";
import { cn } from "@/lib/utils";
export type KanbanPriority = "low" | "medium" | "high" | "urgent";
export type KanbanCard = {
id: string;
title: string;
tags?: string[];
/** Assignee name; initials are derived unless `initials` is given. */
assignee?: { name: string; initials?: string };
priority?: KanbanPriority;
};
export type KanbanColumn = {
id: string;
title: string;
cards: KanbanCard[];
};
export type KanbanMove = {
cardId: string;
from: { columnId: string; index: number };
to: { columnId: string; index: number };
};
export interface KanbanBoardProps {
/** Controlled columns. */
columns?: KanbanColumn[];
/** Initial columns when uncontrolled. */
defaultColumns?: KanbanColumn[];
/** Fires once per completed move with the next columns and what moved. */
onChange?: (columns: KanbanColumn[], move: KanbanMove) => void;
className?: string;
columnClassName?: string;
cardClassName?: string;
}
type Location = { columnId: string; index: number };
type PointerDrag = {
cardId: string;
from: Location;
height: number;
};
type KeyboardGrab = {
cardId: string;
original: KanbanColumn[];
};
const INSTANT = { duration: 0 } as const;
const FADE = { duration: 0.15 } as const;
// Touch needs a short press before a card lifts, so a swipe across the board
// still scrolls the columns instead of grabbing whatever card is underneath.
const TOUCH_LIFT_DELAY = 220;
const TOUCH_SLOP = 8;
const PRIORITY: Record<KanbanPriority, { label: string; dot: string }> = {
low: { label: "Low priority", dot: "bg-sky-500" },
medium: { label: "Medium priority", dot: "bg-amber-500" },
high: { label: "High priority", dot: "bg-orange-500" },
urgent: { label: "Urgent", dot: "bg-red-500" },
};
function initialsOf(name: string) {
return name
.split(/\s+/)
.filter(Boolean)
.slice(0, 2)
.map((part) => part[0]?.toUpperCase() ?? "")
.join("");
}
function locate(columns: KanbanColumn[], cardId: string): Location | null {
for (const column of columns) {
const index = column.cards.findIndex((card) => card.id === cardId);
if (index !== -1) return { columnId: column.id, index };
}
return null;
}
/** Move a card to `to`, where `to.index` counts the target's other cards. */
function moveCard(
columns: KanbanColumn[],
cardId: string,
to: Location,
): KanbanColumn[] {
let moving: KanbanCard | undefined;
const without = columns.map((column) => {
const card = column.cards.find((entry) => entry.id === cardId);
if (!card) return column;
moving = card;
return {
...column,
cards: column.cards.filter((entry) => entry.id !== cardId),
};
});
if (!moving) return columns;
const card = moving;
return without.map((column) => {
if (column.id !== to.columnId) return column;
const cards = column.cards.slice();
cards.splice(Math.max(0, Math.min(cards.length, to.index)), 0, card);
return { ...column, cards };
});
}
function KanbanCardView({
card,
layoutId,
reduce,
dragging,
grabbed,
describedBy,
className,
registerCard,
onLift,
onDragMove,
onDrop,
onKeyDown,
onBlur,
}: {
card: KanbanCard;
layoutId: string;
reduce: boolean;
dragging: boolean;
grabbed: boolean;
describedBy: string;
className?: string;
registerCard: (id: string, el: HTMLElement | null) => void;
onLift: (card: KanbanCard, el: HTMLElement | null) => void;
onDragMove: (point: { x: number; y: number }) => void;
onDrop: (card: KanbanCard) => void;
onKeyDown: (event: KeyboardEvent<HTMLButtonElement>, card: KanbanCard) => void;
onBlur: (relatedTarget: EventTarget | null) => void;
}) {
const controls = useDragControls();
const itemRef = useRef<HTMLLIElement>(null);
const lifted = dragging || grabbed;
const startTouchLift = useTouchLift(controls);
const priority = card.priority ? PRIORITY[card.priority] : null;
return (
<motion.li
ref={(el) => {
itemRef.current = el;
registerCard(card.id, el);
}}
layout
layoutId={layoutId}
drag
dragControls={controls}
dragListener={false}
dragSnapToOrigin
dragMomentum={false}
onDragStart={() => onLift(card, itemRef.current)}
onDrag={(_event, info: PanInfo) =>
// `info.point` is page space; hit-testing reads viewport rects.
onDragMove({
x: info.point.x - window.scrollX,
y: info.point.y - window.scrollY,
})
}
onDragEnd={() => onDrop(card)}
animate={{ scale: lifted && !reduce ? 1.03 : 1 }}
transition={reduce ? INSTANT : SPRING_LAYOUT}
className={cn("relative list-none", lifted ? "z-30" : "z-0")}
>
<motion.span
aria-hidden="true"
initial={false}
animate={{ opacity: lifted ? 1 : 0 }}
transition={reduce ? INSTANT : FADE}
className="pointer-events-none absolute inset-0 rounded-xl shadow-[0_16px_36px_-14px_rgb(0_0_0/0.4)]"
/>
<button
type="button"
aria-roledescription="draggable card"
aria-describedby={describedBy}
aria-pressed={grabbed}
onPointerDown={(event) => {
if (event.button !== 0) return;
startTouchLift(event);
}}
onKeyDown={(event) => onKeyDown(event, card)}
onBlur={(event) => onBlur(event.relatedTarget)}
className={cn(
"relative flex w-full cursor-grab flex-col gap-2.5 rounded-xl border border-border bg-card p-3 text-left outline-none transition-colors active:cursor-grabbing",
"hover:border-foreground/20 focus-visible:ring-2 focus-visible:ring-ring focus-visible:ring-offset-2 focus-visible:ring-offset-background",
grabbed && "border-foreground/30",
TOUCH_GESTURE_CONTENT_CLASS,
dragging && "select-none",
className,
)}
>
<span className="flex items-start gap-2">
{priority ? (
<span
className={cn("mt-1.5 h-2 w-2 shrink-0 rounded-full", priority.dot)}
>
<span className="sr-only">{priority.label}</span>
</span>
) : null}
<span className="text-sm font-medium leading-snug text-foreground">
{card.title}
</span>
</span>
{card.tags?.length || card.assignee ? (
<span className="flex items-end justify-between gap-2">
<span className="flex flex-wrap gap-1">
{card.tags?.map((tag) => (
<span
key={tag}
className="rounded-md bg-muted px-1.5 py-0.5 text-[11px] font-medium text-muted-foreground"
>
{tag}
</span>
))}
</span>
{card.assignee ? (
<span
title={card.assignee.name}
className="grid h-6 w-6 shrink-0 place-items-center rounded-full bg-foreground text-[10px] font-semibold text-background"
>
<span aria-hidden="true">
{card.assignee.initials ?? initialsOf(card.assignee.name)}
</span>
<span className="sr-only">Assigned to {card.assignee.name}</span>
</span>
) : null}
</span>
) : null}
</button>
</motion.li>
);
}
/**
* Mouse and pen lift immediately (motion still waits for a few pixels of
* travel before it calls it a drag). Touch lifts after a short still press;
* moving first hands the gesture back to the scroller.
*/
function useTouchLift(controls: DragControls) {
const timer = useRef<number | null>(null);
const cleanup = useRef<(() => void) | null>(null);
useEffect(() => () => cleanup.current?.(), []);
return useCallback(
(event: ReactPointerEvent<HTMLElement>) => {
if (event.pointerType !== "touch") {
controls.start(event);
return;
}
cleanup.current?.();
const native = event.nativeEvent;
const startX = native.clientX;
const startY = native.clientY;
let lifted = false;
// Once lifted, the page must not scroll under the finger.
const blockScroll = (touch: TouchEvent) => {
if (lifted) touch.preventDefault();
};
const onMove = (move: PointerEvent) => {
if (lifted) return;
if (
Math.abs(move.clientX - startX) > TOUCH_SLOP ||
Math.abs(move.clientY - startY) > TOUCH_SLOP
) {
cleanup.current?.();
}
};
const stop = () => {
if (timer.current !== null) window.clearTimeout(timer.current);
timer.current = null;
window.removeEventListener("pointermove", onMove);
window.removeEventListener("pointerup", stop);
window.removeEventListener("pointercancel", stop);
window.removeEventListener("touchmove", blockScroll);
cleanup.current = null;
};
window.addEventListener("pointermove", onMove);
window.addEventListener("pointerup", stop);
window.addEventListener("pointercancel", stop);
window.addEventListener("touchmove", blockScroll, { passive: false });
cleanup.current = stop;
timer.current = window.setTimeout(() => {
timer.current = null;
lifted = true;
controls.start(native);
}, TOUCH_LIFT_DELAY);
},
[controls],
);
}
export function KanbanBoard({
columns,
defaultColumns,
onChange,
className,
columnClassName,
cardClassName,
}: KanbanBoardProps) {
const reduce = useReducedMotion() ?? false;
const boardId = useId();
const instructionsId = useId();
const [internal, setInternal] = useState<KanbanColumn[]>(
defaultColumns ?? [],
);
const isControlled = columns !== undefined;
const committed = isControlled ? columns : internal;
const [draft, setDraft] = useState<KanbanColumn[] | null>(null);
const [pointer, setPointer] = useState<PointerDrag | null>(null);
const [over, setOver] = useState<Location | null>(null);
const [grab, setGrab] = useState<KeyboardGrab | null>(null);
const [announcement, setAnnouncement] = useState("");
const overRef = useRef<Location | null>(null);
const cardEls = useRef(new Map<string, HTMLElement>());
const columnEls = useRef(new Map<string, HTMLElement>());
const view = draft ?? committed;
const registerCard = useCallback((id: string, el: HTMLElement | null) => {
if (el) cardEls.current.set(id, el);
else cardEls.current.delete(id);
}, []);
const titleOf = (cardId: string, list = view) => {
for (const column of list) {
const card = column.cards.find((entry) => entry.id === cardId);
if (card) return card.title;
}
return "Card";
};
const describe = (list: KanbanColumn[], cardId: string) => {
const at = locate(list, cardId);
const column = list.find((entry) => entry.id === at?.columnId);
if (!at || !column) return "";
return `${column.title}, position ${at.index + 1} of ${column.cards.length}`;
};
const commit = (next: KanbanColumn[], move: KanbanMove) => {
if (
move.from.columnId === move.to.columnId &&
move.from.index === move.to.index
) {
return;
}
if (!isControlled) setInternal(next);
onChange?.(next, move);
};
// Keep focus on the grabbed card as it changes place; crossing a column
// remounts it, and the shared layoutId flies it to its new slot.
const grabbedId = grab?.cardId;
const grabbedAt = grabbedId ? locate(view, grabbedId) : null;
const grabbedSlot = grabbedAt ? `${grabbedAt.columnId}:${grabbedAt.index}` : "";
useEffect(() => {
if (!grabbedId || !grabbedSlot) return;
const el = cardEls.current.get(grabbedId)?.querySelector("button");
if (el && document.activeElement !== el) el.focus();
}, [grabbedId, grabbedSlot]);
/* ----------------------------- pointer drag ----------------------------- */
const onLift = (card: KanbanCard, el: HTMLElement | null) => {
const from = locate(committed, card.id);
if (!from) return;
setPointer({
cardId: card.id,
from,
height: el?.getBoundingClientRect().height ?? 72,
});
};
const onDragMove = (point: { x: number; y: number }) => {
if (!pointer) return;
let target: KanbanColumn | undefined;
let nearest = Number.POSITIVE_INFINITY;
for (const column of view) {
const rect = columnEls.current.get(column.id)?.getBoundingClientRect();
if (!rect) continue;
const distance =
point.x < rect.left
? rect.left - point.x
: point.x > rect.right
? point.x - rect.right
: 0;
if (distance < nearest) {
nearest = distance;
target = column;
}
}
// Only a column the pointer is actually over (or right beside) accepts.
if (!target || nearest > 24) {
if (overRef.current) {
overRef.current = null;
setOver(null);
}
return;
}
let index = 0;
for (const card of target.cards) {
if (card.id === pointer.cardId) continue;
const rect = cardEls.current.get(card.id)?.getBoundingClientRect();
if (rect && point.y > rect.top + rect.height / 2) index += 1;
}
const prev = overRef.current;
if (prev?.columnId === target.id && prev.index === index) return;
const next = { columnId: target.id, index };
overRef.current = next;
setOver(next);
};
const onPointerDrop = (card: KanbanCard) => {
const to = overRef.current;
const from = pointer?.from;
overRef.current = null;
setOver(null);
setPointer(null);
if (!to || !from) return;
const next = moveCard(committed, card.id, to);
commit(next, { cardId: card.id, from, to });
setAnnouncement(`${card.title} dropped in ${describe(next, card.id)}.`);
};
/* ---------------------------- keyboard moves ---------------------------- */
const drop = (cardId: string) => {
if (!grab) return;
const from = locate(grab.original, cardId);
const to = locate(view, cardId);
setGrab(null);
setDraft(null);
if (!from || !to) return;
setAnnouncement(`${titleOf(cardId)} dropped in ${describe(view, cardId)}.`);
commit(view, { cardId, from, to });
};
const onCardKeyDown = (
event: KeyboardEvent<HTMLButtonElement>,
card: KanbanCard,
) => {
const isToggle = event.key === " " || event.key === "Enter";
if (!grab) {
if (!isToggle) return;
event.preventDefault();
setGrab({ cardId: card.id, original: committed });
setDraft(committed);
setAnnouncement(
`Picked up ${card.title} in ${describe(committed, card.id)}. Use the arrow keys to move, Space to drop, Escape to cancel.`,
);
return;
}
if (grab.cardId !== card.id) return;
if (isToggle) {
event.preventDefault();
drop(card.id);
return;
}
if (event.key === "Escape") {
event.preventDefault();
setGrab(null);
setDraft(null);
setAnnouncement(
`Move cancelled. ${card.title} returned to ${describe(grab.original, card.id)}.`,
);
return;
}
const at = locate(view, card.id);
if (!at) return;
const columnIndex = view.findIndex((column) => column.id === at.columnId);
let to: Location | null = null;
if (event.key === "ArrowUp" || event.key === "ArrowDown") {
const length = view[columnIndex].cards.length;
const index = at.index + (event.key === "ArrowUp" ? -1 : 1);
if (index >= 0 && index < length) to = { columnId: at.columnId, index };
} else if (event.key === "ArrowLeft" || event.key === "ArrowRight") {
const target = view[columnIndex + (event.key === "ArrowLeft" ? -1 : 1)];
if (target) {
to = {
columnId: target.id,
index: Math.min(at.index, target.cards.length),
};
}
} else {
return;
}
event.preventDefault();
if (!to) return;
const next = moveCard(view, card.id, to);
setDraft(next);
setAnnouncement(`${card.title} moved to ${describe(next, card.id)}.`);
};
const onCardBlur = (relatedTarget: EventTarget | null) => {
// Tabbing or clicking away drops the card in place. A null target is the
// card being remounted into another column mid-move.
if (grab && relatedTarget) drop(grab.cardId);
};
return (
<div className={cn("w-full", className)}>
<p id={instructionsId} className="sr-only">
Press Space to pick up a card. Use the left and right arrow keys to
change column, the up and down arrow keys to change position, Space to
drop and Escape to cancel.
</p>
<LayoutGroup id={boardId}>
<div className="flex snap-x snap-mandatory gap-3 overflow-x-auto pb-4 [scrollbar-color:var(--border-strong)_transparent] [scrollbar-width:thin] sm:snap-none">
{view.map((column) => {
const isOver = pointer !== null && over?.columnId === column.id;
const sameSlot =
pointer !== null &&
over !== null &&
pointer.from.columnId === over.columnId &&
pointer.from.index === over.index;
const showPlaceholder = isOver && !sameSlot;
let counted = 0;
const placeholder = (
<motion.li
key="kanban-placeholder"
layout
aria-hidden="true"
initial={{ opacity: 0 }}
animate={{ opacity: 1 }}
transition={reduce ? INSTANT : FADE}
style={{ height: pointer?.height }}
className="list-none rounded-xl border-2 border-dashed border-foreground/20 bg-foreground/[0.03]"
/>
);
return (
<section
key={column.id}
aria-label={`${column.title}, ${column.cards.length} ${column.cards.length === 1 ? "card" : "cards"}`}
className={cn(
"relative flex w-[78%] max-w-72 shrink-0 snap-start flex-col rounded-2xl bg-muted/60 p-2 sm:w-auto sm:min-w-56 sm:max-w-none sm:flex-1",
columnClassName,
)}
>
{/* Highlight is its own layer so only opacity animates. */}
<motion.span
aria-hidden="true"
initial={false}
animate={{ opacity: isOver ? 1 : 0 }}
transition={reduce ? INSTANT : FADE}
className="pointer-events-none absolute inset-0 rounded-2xl bg-foreground/[0.04] ring-2 ring-foreground/15 ring-inset"
/>
<header className="relative flex items-center justify-between px-1.5 pt-1 pb-2.5">
<h3 className="text-sm font-semibold text-foreground">
{column.title}
</h3>
<span
aria-hidden="true"
className="min-w-6 rounded-full bg-background px-2 py-0.5 text-center text-xs font-medium tabular-nums text-muted-foreground"
>
{column.cards.length}
</span>
</header>
<ul
ref={(el) => {
if (el) columnEls.current.set(column.id, el);
else columnEls.current.delete(column.id);
}}
className="relative flex min-h-24 flex-1 flex-col gap-2"
>
{column.cards.flatMap((card) => {
const isDragged = pointer?.cardId === card.id;
const before =
showPlaceholder && !isDragged && counted === over?.index;
if (!isDragged) counted += 1;
const node = (
<KanbanCardView
key={card.id}
card={card}
layoutId={`card-${card.id}`}
reduce={reduce}
dragging={isDragged}
grabbed={grab?.cardId === card.id}
describedBy={instructionsId}
className={cardClassName}
registerCard={registerCard}
onLift={onLift}
onDragMove={onDragMove}
onDrop={onPointerDrop}
onKeyDown={onCardKeyDown}
onBlur={onCardBlur}
/>
);
return before ? [placeholder, node] : [node];
})}
{showPlaceholder && counted === over?.index
? placeholder
: null}
</ul>
</section>
);
})}
</div>
</LayoutGroup>
<div aria-live="polite" aria-atomic="true" className="sr-only">
{announcement}
</div>
</div>
);
}
