An analytics bento where a range toggle, segment chips and saved reports drive one shared dataset, so the visitor count, funnel and country list always add up.
@hirael
registry/hirael/bases/radix/blocks/bento-03/bento-03.tsx
// Bento 03 from Hirael <https://hirael.com/blocks/bento/bento-03>
// MIT · Mohammad Shehadeh · https://github.com/MohammadShehadeh/hirael
'use client';
import * as React from 'react';
import { Plus, Star } from 'lucide-react';
import { cn } from '@/lib/utils';
import { AnimatedNumber } from '@/registry/hirael/bases/radix/components/animated-number';
import {
Sparkline,
SparklineArea,
SparklineDot,
SparklineLine,
} from '@/registry/hirael/bases/radix/components/sparkline';
import { Button } from '@/registry/hirael/bases/radix/ui/button';
import { ToggleGroup, ToggleGroupItem } from '@/registry/hirael/bases/radix/ui/toggle-group';
const EASE = 'ease-[cubic-bezier(0.22,1,0.36,1)]';
const ENTER = `animate-in fade-in slide-in-from-bottom-4 duration-500 ${EASE} fill-mode-both motion-reduce:animate-none`;
const SWAP = `animate-in fade-in slide-in-from-bottom-1 duration-300 ${EASE} fill-mode-both motion-reduce:animate-none`;
const stagger = (index: number, step = 60, offset = 0): React.CSSProperties => ({
animationDelay: `${offset + index * step}ms`,
});
// Integer hash instead of Math.random so server and client render the same numbers.
const noise = (seed: number) => {
let t = Math.imul(seed + 1, 2654435761) >>> 0;
t ^= t >>> 15;
t = Math.imul(t, 2246822519) >>> 0;
t ^= t >>> 13;
return (t >>> 0) / 4294967296;
};
type Range = '7d' | '30d' | '90d';
type SegmentId = 'all' | 'new' | 'returning' | 'mobile' | 'desktop' | 'search';
const RANGES: Record<Range, { days: number; label: string }> = {
'7d': { days: 7, label: 'Last 7 days' },
'30d': { days: 30, label: 'Last 30 days' },
'90d': { days: 90, label: 'Last 90 days' },
};
interface Segment {
id: SegmentId;
label: string;
description: string;
share: number;
seed: number;
rates: { signup: number; activate: number; pay: number };
bounce: number;
/** Median session length in seconds. */
session: number;
}
const SEGMENTS: readonly Segment[] = [
{
id: 'all',
label: 'All visitors',
description: 'Every session on the marketing site and the app.',
share: 1,
seed: 3,
rates: { signup: 0.062, activate: 0.54, pay: 0.21 },
bounce: 41,
session: 154,
},
{
id: 'new',
label: 'New',
description: 'People on their first visit in the last 12 months.',
share: 0.64,
seed: 17,
rates: { signup: 0.071, activate: 0.49, pay: 0.17 },
bounce: 48,
session: 118,
},
{
id: 'returning',
label: 'Returning',
description: 'People who visited before, signed in or not.',
share: 0.36,
seed: 29,
rates: { signup: 0.043, activate: 0.68, pay: 0.31 },
bounce: 28,
session: 221,
},
{
id: 'mobile',
label: 'Mobile',
description: 'Phones and small tablets.',
share: 0.47,
seed: 41,
rates: { signup: 0.041, activate: 0.45, pay: 0.14 },
bounce: 52,
session: 97,
},
{
id: 'desktop',
label: 'Desktop',
description: 'Laptops, desktops and large tablets.',
share: 0.53,
seed: 53,
rates: { signup: 0.078, activate: 0.59, pay: 0.25 },
bounce: 33,
session: 203,
},
{
id: 'search',
label: 'From search',
description: 'Sessions that started on a search engine result.',
share: 0.41,
seed: 67,
rates: { signup: 0.066, activate: 0.52, pay: 0.22 },
bounce: 44,
session: 139,
},
];
const segmentById = (id: SegmentId) => SEGMENTS.find((segment) => segment.id === id) ?? SEGMENTS[0];
const HISTORY = 180;
// Two 90-day windows so every range has a previous period to compare against.
const BASE_DAILY = Array.from({ length: HISTORY }, (_, day) => {
const weekday = day % 7;
const weekend = weekday === 5 || weekday === 6 ? 0.84 : 1;
const growth = 1 + day * 0.0021;
return 5200 * weekend * growth;
});
const dailyVisitors = (segment: Segment) =>
BASE_DAILY.map((value, day) => Math.round(value * segment.share * (0.93 + 0.14 * noise(segment.seed * 1000 + day))));
const sum = (values: readonly number[]) => values.reduce((total, value) => total + value, 0);
const REGIONS = [
{ name: 'United States', share: 0.34 },
{ name: 'Germany', share: 0.12 },
{ name: 'United Kingdom', share: 0.1 },
{ name: 'India', share: 0.09 },
{ name: 'Brazil', share: 0.06 },
{ name: 'Japan', share: 0.05 },
] as const;
const LAST_DAY = Date.UTC(2026, 8, 23);
const DAY_MS = 86_400_000;
const dayFormat = new Intl.DateTimeFormat('en-US', { month: 'short', day: 'numeric', timeZone: 'UTC' });
const integer = new Intl.NumberFormat('en-US');
const formatDuration = (seconds: number) => `${Math.floor(seconds / 60)}m ${String(seconds % 60).padStart(2, '0')}s`;
interface View {
range: Range;
segment: SegmentId;
}
const useAnalytics = ({ range, segment: segmentId }: View) => {
const segment = segmentById(segmentId);
const history = React.useMemo(() => dailyVisitors(segment), [segment]);
return React.useMemo(() => {
const days = RANGES[range].days;
const series = history.slice(HISTORY - days);
const visitors = sum(series);
const previous = sum(history.slice(HISTORY - days * 2, HISTORY - days));
const signedUp = Math.round(visitors * segment.rates.signup);
const activated = Math.round(signedUp * segment.rates.activate);
const paid = Math.round(activated * segment.rates.pay);
const regionCounts = REGIONS.map((region, index) => ({
name: region.name,
count: Math.round(visitors * region.share * (0.8 + 0.4 * noise(segment.seed * 31 + index))),
})).sort((a, b) => b.count - a.count);
const other = visitors - sum(regionCounts.map((region) => region.count));
return {
segment,
series,
visitors,
change: ((visitors - previous) / previous) * 100,
funnel: [
{ label: 'Visited', count: visitors },
{ label: 'Signed up', count: signedUp },
{ label: 'Activated', count: activated },
{ label: 'Paid', count: paid },
],
regions: [...regionCounts, { name: 'Other', count: other }],
firstDay: dayFormat.format(new Date(LAST_DAY - (days - 1) * DAY_MS)),
lastDay: dayFormat.format(new Date(LAST_DAY)),
};
}, [history, range, segment]);
};
type Analytics = ReturnType<typeof useAnalytics>;
interface TileProps extends Omit<React.ComponentProps<'article'>, 'title'> {
title: React.ReactNode;
description?: React.ReactNode;
action?: React.ReactNode;
}
const Tile = ({ title, description, action, className, children, ...props }: TileProps) => {
return (
<article
data-slot="bento-tile"
className={cn('flex min-w-0 flex-col gap-6 bg-background p-6', className)}
{...props}
>
<div data-slot="bento-tile-header" className="flex flex-wrap items-start justify-between gap-x-4 gap-y-3">
<div className="flex min-w-0 flex-col gap-1">
<h3 className="text-base font-medium">{title}</h3>
{description ? <p className="max-w-sm text-sm text-muted-foreground">{description}</p> : null}
</div>
{action}
</div>
<div data-slot="bento-tile-body" className="flex flex-1 flex-col">
{children}
</div>
</article>
);
};
interface MetricTileProps extends Omit<TileProps, 'title' | 'description' | 'action' | 'children'> {
data: Analytics;
range: Range;
onRangeChange: (range: Range) => void;
}
const MetricTile = ({ data, range, onRangeChange, ...props }: MetricTileProps) => {
const up = data.change >= 0;
return (
<Tile
data-slot="metric"
title="Visitors"
description={data.segment.description}
action={
<ToggleGroup
type="single"
variant="outline"
size="sm"
value={range}
onValueChange={(next) => {
if (next) onRangeChange(next as Range);
}}
aria-label="Date range"
>
<ToggleGroupItem value="7d">7d</ToggleGroupItem>
<ToggleGroupItem value="30d">30d</ToggleGroupItem>
<ToggleGroupItem value="90d">90d</ToggleGroupItem>
</ToggleGroup>
}
{...props}
>
<div className="flex flex-1 flex-col gap-6">
<div className="flex flex-wrap items-end gap-x-4 gap-y-2">
<span className="text-5xl font-medium tracking-tight sm:text-6xl">
<AnimatedNumber value={data.visitors} duration={600} />
</span>
<span className="flex flex-col pb-1.5 text-sm">
<span className={cn('tabular-nums', up ? 'text-success' : 'text-destructive')}>
{up ? '+' : ''}
{data.change.toFixed(1)}%
</span>
<span className="text-muted-foreground">vs previous {RANGES[range].days} days</span>
</span>
</div>
<div className="flex flex-col gap-2">
<Sparkline
data={data.series}
variant={range === '7d' ? 'bar' : 'area'}
curve
min={0}
label={`${data.segment.label}, ${RANGES[range].label}: ${integer.format(data.visitors)} visitors`}
className="h-48 w-full sm:h-56"
>
{range === '7d' ? null : (
<>
<SparklineArea fillOpacity={0.08} />
<SparklineLine />
<SparklineDot />
</>
)}
</Sparkline>
<div className="flex justify-between text-xs text-muted-foreground tabular-nums">
<span>{data.firstDay}</span>
<span>{data.lastDay}</span>
</div>
</div>
<dl className="mt-auto grid grid-cols-3 gap-4 border-t border-border pt-4">
<div className="flex flex-col gap-1">
<dt className="text-xs text-muted-foreground">Daily average</dt>
<dd className="text-lg font-medium">
<AnimatedNumber value={Math.round(data.visitors / RANGES[range].days)} duration={500} />
</dd>
</div>
<div className="flex flex-col gap-1">
<dt className="text-xs text-muted-foreground">Bounce rate</dt>
<dd className="text-lg font-medium">
<AnimatedNumber value={data.segment.bounce} suffix="%" duration={500} />
</dd>
</div>
<div className="flex flex-col gap-1">
<dt className="text-xs text-muted-foreground">Median session</dt>
<dd key={data.segment.id} className={cn(SWAP, 'text-lg font-medium tabular-nums')}>
{formatDuration(data.segment.session)}
</dd>
</div>
</dl>
</div>
</Tile>
);
};
interface SegmentTileProps extends Omit<TileProps, 'title' | 'description' | 'action' | 'children'> {
segment: SegmentId;
onSegmentChange: (segment: SegmentId) => void;
}
const SegmentTile = ({ segment, onSegmentChange, ...props }: SegmentTileProps) => {
const current = segmentById(segment);
return (
<Tile data-slot="segments" title="Segments" description="Filter every panel to one group of people." {...props}>
<div className="flex flex-col gap-4">
<ToggleGroup
type="single"
variant="outline"
size="sm"
spacing={2}
value={segment}
onValueChange={(next) => {
if (next) onSegmentChange(next as SegmentId);
}}
aria-label="Segment"
className="flex-wrap"
>
{SEGMENTS.map((s) => (
<ToggleGroupItem key={s.id} value={s.id}>
{s.label}
</ToggleGroupItem>
))}
</ToggleGroup>
<div className="flex items-center gap-3 text-sm">
<span aria-hidden className="h-1.5 flex-1 overflow-hidden rounded-full bg-muted">
<span
className="block h-full rounded-full bg-primary transition-transform duration-500 ease-out ltr:origin-left rtl:origin-right"
style={{ transform: `scaleX(${current.share})` }}
/>
</span>
<span className="shrink-0 text-muted-foreground">
<AnimatedNumber value={current.share * 100} startValue={100} suffix="% of traffic" duration={400} />
</span>
</div>
</div>
</Tile>
);
};
type FunnelTileProps = Omit<TileProps, 'title' | 'description' | 'action' | 'children'> & { data: Analytics };
const FunnelTile = ({ data, ...props }: FunnelTileProps) => {
return (
<Tile data-slot="funnel" title="Funnel" description="How many make it to each step." {...props}>
<ol className="flex flex-col gap-4">
{data.funnel.map((step, index) => {
const previous = index === 0 ? step.count : data.funnel[index - 1].count;
const rate = previous === 0 ? 0 : step.count / previous;
return (
<li key={step.label} className="flex flex-col gap-1.5 text-sm">
<div className="flex items-baseline justify-between gap-3">
<span>{step.label}</span>
<span className="flex items-baseline gap-2">
<span className="font-medium">
<AnimatedNumber value={step.count} duration={500} />
</span>
{index > 0 ? (
<span className="w-12 text-end text-xs text-muted-foreground tabular-nums">
{(rate * 100).toFixed(1)}%
</span>
) : (
<span className="w-12" />
)}
</span>
</div>
<span aria-hidden className="h-1.5 overflow-hidden rounded-full bg-muted">
<span
className={cn(
'block h-full rounded-full transition-transform duration-500 ease-out ltr:origin-left rtl:origin-right',
index === data.funnel.length - 1 ? 'bg-primary' : 'bg-muted-foreground/60',
)}
style={{ transform: `scaleX(${rate})` }}
/>
</span>
</li>
);
})}
</ol>
<p className="mt-auto pt-4 text-xs text-muted-foreground">Bars show the share kept from the step before.</p>
</Tile>
);
};
type RegionTileProps = Omit<TileProps, 'title' | 'description' | 'action' | 'children'> & { data: Analytics };
const RegionTile = ({ data, ...props }: RegionTileProps) => {
// Other is a remainder, not a country, so it doesn't set the scale.
const max = Math.max(...data.regions.filter((region) => region.name !== 'Other').map((region) => region.count));
return (
<Tile data-slot="regions" title="Where they are" description="Visitors by country for the current view." {...props}>
<ul className="flex flex-col gap-2.5">
{data.regions.map((region) => {
const other = region.name === 'Other';
return (
<li
key={region.name}
className="grid grid-cols-[6.5rem_1fr_auto] items-center gap-3 text-sm sm:grid-cols-[7.5rem_1fr_auto]"
>
<span className={cn('truncate', other && 'text-muted-foreground')}>{region.name}</span>
<span aria-hidden className={cn('h-1.5 overflow-hidden rounded-full', !other && 'bg-muted')}>
<span
className="block h-full rounded-full bg-muted-foreground/60 transition-transform duration-500 ease-out ltr:origin-left rtl:origin-right"
style={{ transform: `scaleX(${other ? 0 : region.count / max})` }}
/>
</span>
<span className="flex w-24 items-baseline justify-end gap-2">
<AnimatedNumber value={region.count} duration={500} />
<span className="w-9 text-end text-xs text-muted-foreground tabular-nums">
{Math.round((region.count / data.visitors) * 100)}%
</span>
</span>
</li>
);
})}
</ul>
</Tile>
);
};
interface Report extends View {
id: string;
name: string;
owner: string;
pinned: boolean;
}
const INITIAL_REPORTS: readonly Report[] = [
{ id: 'r1', name: 'Mobile, last 30 days', owner: 'Priya Nair', range: '30d', segment: 'mobile', pinned: true },
{ id: 'r2', name: 'Search traffic this week', owner: 'Leo Brandt', range: '7d', segment: 'search', pinned: false },
{ id: 'r3', name: 'Returning, this quarter', owner: 'You', range: '90d', segment: 'returning', pinned: false },
{ id: 'r4', name: 'New visitor funnel', owner: 'Priya Nair', range: '30d', segment: 'new', pinned: false },
];
interface ReportsTileProps extends Omit<TileProps, 'title' | 'description' | 'action' | 'children'> {
view: View;
onOpen: (view: View) => void;
}
const ReportsTile = ({ view, onOpen, ...props }: ReportsTileProps) => {
const [reports, setReports] = React.useState<readonly Report[]>(INITIAL_REPORTS);
const sorted = [...reports].sort((a, b) => Number(b.pinned) - Number(a.pinned));
const saved = reports.some((report) => report.range === view.range && report.segment === view.segment);
const save = () =>
setReports((list) => [
...list,
{
id: `r${list.length + 1}`,
name: `${segmentById(view.segment).label}, ${RANGES[view.range].label.toLowerCase()}`,
owner: 'You',
range: view.range,
segment: view.segment,
pinned: false,
},
]);
return (
<Tile
data-slot="saved-reports"
title="Saved reports"
description="Open one to load its segment and range."
action={
<Button variant="outline" size="sm" onClick={save} disabled={saved}>
<Plus aria-hidden />
{saved ? 'Saved' : 'Save view'}
</Button>
}
{...props}
>
<ul className="-mx-2 flex flex-col">
{sorted.map((report) => {
const active = report.range === view.range && report.segment === view.segment;
return (
<li
key={report.id}
className={cn(
Number(report.id.slice(1)) > INITIAL_REPORTS.length && SWAP,
'flex items-center gap-1 rounded-md transition-colors duration-150',
active && 'bg-muted',
)}
>
<button
type="button"
aria-current={active || undefined}
onClick={() => onOpen({ range: report.range, segment: report.segment })}
className="flex min-w-0 flex-1 flex-col items-start gap-0.5 rounded-md px-2 py-2 text-start text-sm outline-none focus-visible:ring-[3px] focus-visible:ring-ring/50"
>
<span className={cn('truncate', active && 'font-medium')}>{report.name}</span>
<span className="text-xs text-muted-foreground">
{report.owner}, {RANGES[report.range].label.toLowerCase()}
</span>
</button>
<Button
variant="ghost"
size="icon-sm"
aria-pressed={report.pinned}
aria-label={report.pinned ? `Unpin ${report.name}` : `Pin ${report.name}`}
onClick={() =>
setReports((list) => list.map((r) => (r.id === report.id ? { ...r, pinned: !r.pinned } : r)))
}
className="me-1"
>
<Star aria-hidden className={cn(report.pinned && 'fill-current text-primary')} />
</Button>
</li>
);
})}
</ul>
</Tile>
);
};
const Bento03 = () => {
const [view, setView] = React.useState<View>({ range: '30d', segment: 'all' });
const data = useAnalytics(view);
return (
<section data-slot="bento" className="bg-background px-6 py-16 md:px-10 md:py-24">
<div className="mx-auto flex w-full max-w-6xl flex-col gap-12">
<header data-slot="bento-header" className="flex max-w-2xl flex-col gap-4">
<h2
className={cn(ENTER, 'font-serif text-3xl font-medium tracking-tight text-balance md:text-4xl lg:text-5xl')}
>
See who visits and where they drop off
</h2>
<p style={stagger(1)} className={cn(ENTER, 'text-base text-pretty text-muted-foreground md:text-lg')}>
Pick a segment, a range or a saved report. Every panel answers from the same numbers, so they always add up.
</p>
</header>
<div
data-slot="bento-grid"
className="grid grid-cols-1 gap-px overflow-hidden rounded-xl border border-border bg-border md:grid-cols-6 lg:grid-cols-12"
>
<MetricTile
data={data}
range={view.range}
onRangeChange={(range) => setView((v) => ({ ...v, range }))}
style={stagger(0, 70, 150)}
className={cn(ENTER, 'md:col-span-6 lg:col-span-8 lg:row-span-2')}
/>
<SegmentTile
segment={view.segment}
onSegmentChange={(segment) => setView((v) => ({ ...v, segment }))}
style={stagger(1, 70, 150)}
className={cn(ENTER, 'md:col-span-3 lg:col-span-4')}
/>
<FunnelTile data={data} style={stagger(2, 70, 150)} className={cn(ENTER, 'md:col-span-3 lg:col-span-4')} />
<RegionTile data={data} style={stagger(3, 70, 150)} className={cn(ENTER, 'md:col-span-3 lg:col-span-6')} />
<ReportsTile
view={view}
onOpen={setView}
style={stagger(4, 70, 150)}
className={cn(ENTER, 'md:col-span-3 lg:col-span-6')}
/>
</div>
</div>
</section>
);
};
export default Bento03;
