The complete Developer Tools Pack — installs the Deployment Command Center block and its four components (Deployment Pipeline, Live Log Stream, API Request Inspector, Environment Switcher) as editable source, deduping shared utilities.
@motiq
registry/blocks/deployment-command-center.tsx
"use client";
import * as React from "react";
import { motion } from "motion/react";
import { cn } from "@/lib/utils";
import { useReducedMotion } from "@/lib/motiq";
import {
EnvironmentSwitcher,
type Environment,
} from "@/components/motiq/environment-switcher";
import {
DeploymentPipeline,
type Stage,
type StageStatus,
} from "@/components/motiq/deployment-pipeline";
import {
LiveLogStream,
type LogEntry,
type LogLevel,
type LogStreamStatus,
} from "@/components/motiq/live-log-stream";
import {
ApiRequestInspector,
type ApiRequest,
type ApiResponse,
type InspectorState,
type AuthSummary,
} from "@/components/motiq/api-request-inspector";
/**
* DeploymentCommandCenter — a composed, app-controlled "deploy console" block
* that wires four presentation-only developer-tools components together behind a
* single small demo state machine: an EnvironmentSwitcher in the top bar, a
* DeploymentPipeline as the main column, a LiveLogStream beneath it, and an
* ApiRequestInspector in the side panel.
*
* IMPORTANT — DEMO ONLY. Nothing here talks to a real deployment provider. Every
* repo, endpoint, id, header, and timing is fictional and provider-neutral
* (repo `acme/ledger-web`, host `api.acme-deploy.dev`). Credential headers are
* pre-masked placeholders (`Bearer ••••••`) and the inspector redacts them
* anyway. The block only feeds the components a scripted request/response/log
* timeline in response to its own controls — it is a copy-paste starting point
* you rewire to your real backend.
*
* Determinism: no `Date.now()` / `Math.random()` / `new Date()` runs during
* render, initializers, or module scope. Timestamps derive from a fixed
* baseline; the run only advances inside timers/handlers. Clean-room original.
*/
/* -------------------------------------------------------------------------- */
/* Fixed, deterministic demo timeline */
/* -------------------------------------------------------------------------- */
// A fixed baseline so the server-rendered first paint is deterministic. Handlers
// advance a step counter from here — never wall-clock now().
const BASE_TS = 1_700_000_000_000;
type StageId = "build" | "test" | "deploy" | "promote";
const STAGE_PLAN: { id: StageId; name: string; durationMs: number }[] = [
{ id: "build", name: "Build", durationMs: 42_100 },
{ id: "test", name: "Test", durationMs: 18_400 },
{ id: "deploy", name: "Deploy", durationMs: 9_200 },
{ id: "promote", name: "Promote", durationMs: 6_000 },
];
interface ScriptLine {
stage: StageId;
level: LogLevel;
message: string;
}
// The happy path: every stage passes.
const SUCCESS_SCRIPT: ScriptLine[] = [
{ stage: "build", level: "info", message: "Cloning acme/ledger-web at ref main…" },
{ stage: "build", level: "info", message: "Resolving 214 packages with pnpm…" },
{ stage: "build", level: "success", message: "Compiled Next.js app in 42.1s" },
{ stage: "test", level: "info", message: "Running 128 unit + integration tests…" },
{ stage: "test", level: "success", message: "All 128 tests passed (18.4s)" },
{ stage: "deploy", level: "info", message: "Uploading build artifacts to region iad1…" },
{ stage: "deploy", level: "info", message: "POST /v1/deployments → dpl_7Kq2 (queued)" },
{ stage: "deploy", level: "success", message: "Deployment dpl_7Kq2 is live at ledger-web-7kq2.acme.app" },
{ stage: "promote", level: "info", message: "Shifting production traffic to dpl_7Kq2…" },
{ stage: "promote", level: "success", message: "Promotion complete - 100% of traffic on dpl_7Kq2" },
];
// The failure path: build + test pass, the deploy stage fails a health check.
const FAILURE_SCRIPT: ScriptLine[] = [
{ stage: "build", level: "info", message: "Cloning acme/ledger-web at ref main…" },
{ stage: "build", level: "info", message: "Resolving 214 packages with pnpm…" },
{ stage: "build", level: "success", message: "Compiled Next.js app in 42.1s" },
{ stage: "test", level: "info", message: "Running 128 unit + integration tests…" },
{ stage: "test", level: "success", message: "All 128 tests passed (18.4s)" },
{ stage: "deploy", level: "info", message: "Uploading build artifacts to region iad1…" },
{ stage: "deploy", level: "info", message: "POST /v1/deployments → dpl_7Kq2 (queued)" },
{ stage: "deploy", level: "error", message: "Deployment dpl_7Kq2 failed: origin health check timed out after 30s" },
];
function toEntries(script: ScriptLine[]): LogEntry[] {
return script.map((line, i) => ({
id: i,
level: line.level,
message: line.message,
source: line.stage,
timestamp: BASE_TS + i * 1_400,
}));
}
const SUCCESS_ENTRIES = toEntries(SUCCESS_SCRIPT);
const FAILURE_ENTRIES = toEntries(FAILURE_SCRIPT);
type RunMode = "ok" | "fail";
function scriptFor(mode: RunMode): ScriptLine[] {
return mode === "fail" ? FAILURE_SCRIPT : SUCCESS_SCRIPT;
}
function entriesFor(mode: RunMode): LogEntry[] {
return mode === "fail" ? FAILURE_ENTRIES : SUCCESS_ENTRIES;
}
/**
* Derive the pipeline stages purely from how many log lines are revealed, the
* run mode, and whether the reader cancelled. No time, no randomness.
*/
function deriveStages(mode: RunMode, revealed: number, cancelled: boolean): Stage[] {
const script = scriptFor(mode);
let sawFailure = false;
return STAGE_PLAN.map((plan) => {
const idxs = script
.map((l, i) => (l.stage === plan.id ? i : -1))
.filter((i) => i >= 0);
const shownMessages = idxs.filter((i) => i < revealed).map((i) => script[i].message);
let status: StageStatus;
if (idxs.length === 0) {
// No scripted lines for this stage in this run (e.g. promote on failure).
status = mode === "fail" && sawFailure ? "cancelled" : "queued";
} else {
const start = idxs[0];
const end = idxs[idxs.length - 1];
if (revealed <= start) {
status = sawFailure ? "cancelled" : "queued";
} else if (revealed > end) {
status = script[end].level === "error" ? "failed" : "passed";
} else {
status = cancelled ? "cancelled" : "running";
}
}
if (status === "failed") sawFailure = true;
const stage: Stage = {
id: plan.id,
name: plan.name,
status,
logs: shownMessages.length ? shownMessages : undefined,
};
if (status === "passed" || status === "failed") stage.durationMs = plan.durationMs;
return stage;
});
}
/* -------------------------------------------------------------------------- */
/* Inspector request/response (fictional, provider-neutral) */
/* -------------------------------------------------------------------------- */
const AUTH: AuthSummary = {
scheme: "Bearer",
principal: "svc_deploy_bot",
scopes: ["deployments:write", "projects:read"],
note: "Service token · rotates every 24h",
};
function makeRequest(env: Environment, repo: string): ApiRequest {
const isProd = env.type === "production";
return {
method: "POST",
url: "https://api.acme-deploy.dev/v1/deployments",
environment: env.type,
requestId: "req_9fa2c1e7b0",
timestamp: BASE_TS,
query: {
project: "ledger-web",
target: env.type,
wait: "true",
region: env.region ?? "iad1",
},
headers: {
"Content-Type": "application/json",
Accept: "application/json",
Authorization: "Bearer ••••••",
"X-Api-Key": "••••••",
"User-Agent": "deploy-console/2.1",
},
body: {
project: "ledger-web",
repo,
ref: "main",
target: env.type,
env: {
NODE_ENV: isProd ? "production" : "preview",
FLAGS: "edge,streaming",
},
},
};
}
const SUCCESS_RESPONSE: ApiResponse = {
status: 201,
statusText: "Created",
durationMs: 812,
retryCount: 0,
headers: {
"Content-Type": "application/json",
"X-Request-Id": "req_9fa2c1e7b0",
"X-Ratelimit-Remaining": "4998",
"Set-Cookie": "session=••••••; HttpOnly",
},
body: {
id: "dpl_7Kq2",
state: "ready",
url: "https://ledger-web-7kq2.acme.app",
createdAt: "2024-11-14T22:13:20Z",
},
phases: [
{ label: "DNS", durationMs: 24 },
{ label: "TCP", durationMs: 41 },
{ label: "TLS", durationMs: 88 },
{ label: "TTFB", durationMs: 502 },
{ label: "Download", durationMs: 157 },
],
};
const FAIL_RESPONSE: ApiResponse = {
status: 503,
statusText: "Service Unavailable",
durationMs: 30_142,
retryCount: 0,
error: "Deployment dpl_7Kq2 failed: origin health check timed out after 30s.",
headers: {
"Content-Type": "application/json",
"X-Request-Id": "req_9fa2c1e7b0",
"Retry-After": "5",
},
body: {
error: {
code: "health_check_timeout",
deploymentId: "dpl_7Kq2",
message: "Origin did not become healthy within 30s.",
},
},
};
function deriveInspector(
deployStatus: StageStatus,
cancelled: boolean,
retried: boolean,
): { state: InspectorState; response?: ApiResponse } {
if (cancelled) return { state: "cancelled", response: undefined };
switch (deployStatus) {
case "running":
return { state: retried ? "retrying" : "loading", response: undefined };
case "passed":
return { state: "success", response: { ...SUCCESS_RESPONSE, retryCount: retried ? 1 : 0 } };
case "failed":
return { state: "server_error", response: FAIL_RESPONSE };
default:
return { state: "idle", response: undefined };
}
}
/* -------------------------------------------------------------------------- */
/* Default environments */
/* -------------------------------------------------------------------------- */
const DEFAULT_ENVIRONMENTS: Environment[] = [
{
id: "preview",
name: "Preview · PR-248",
type: "preview",
status: "available",
region: "iad1",
branch: "feat/ledger-export",
version: "v0.9.3-rc",
health: 96,
lastDeploy: BASE_TS - 1000 * 60 * 12,
},
{
id: "staging",
name: "Staging",
type: "staging",
status: "active",
region: "iad1",
branch: "main",
version: "v2.4.0",
health: 99,
lastDeploy: BASE_TS - 1000 * 60 * 47,
},
{
id: "production",
name: "Production",
type: "production",
status: "active",
region: "iad1 · sfo1",
branch: "main",
version: "v2.3.9",
health: 98,
warning: "Live customer data - deploys shift real traffic.",
lastDeploy: BASE_TS - 1000 * 60 * 60 * 5,
},
];
/* -------------------------------------------------------------------------- */
/* Shared chrome */
/* -------------------------------------------------------------------------- */
const focusRing =
"focus-visible:outline-none focus-visible:ring-2 focus-visible:ring-[var(--color-focus,var(--color-accent))] focus-visible:ring-offset-1 focus-visible:ring-offset-[var(--color-surface)]";
const controlBtn = cn(
"inline-flex items-center gap-1.5 rounded-lg border border-[var(--color-border)] bg-[var(--color-surface)]",
"px-2.5 py-1.5 text-[12.5px] font-medium text-[var(--color-fg)] transition-colors",
"hover:border-[var(--color-accent)] hover:text-[var(--color-accent)]",
"disabled:cursor-not-allowed disabled:opacity-45 disabled:hover:border-[var(--color-border)] disabled:hover:text-[var(--color-fg)]",
focusRing,
);
const primaryBtn = cn(
"inline-flex min-h-[40px] items-center gap-2 rounded-xl border border-[var(--color-accent)]",
"bg-[var(--color-accent)] px-4 py-2 text-[13px] font-semibold text-[var(--color-accent-fg,white)] transition-colors",
"hover:bg-[color-mix(in_oklab,var(--color-accent)_88%,black)]",
"disabled:cursor-not-allowed disabled:opacity-55",
focusRing,
);
function RocketGlyph() {
return (
<svg width={15} height={15} viewBox="0 0 24 24" fill="none" stroke="currentColor" strokeWidth={2} strokeLinecap="round" strokeLinejoin="round" aria-hidden focusable="false">
<path d="M4.5 16.5c-1.5 1.3-2 5-2 5s3.7-.5 5-2c.7-.9.7-2.2-.1-3a2.1 2.1 0 0 0-2.9 0Z" />
<path d="M12 15 9 12a15 15 0 0 1 8-9c2.5 0 4 1.5 4 4a15 15 0 0 1-9 8Z" />
<path d="M9 12H4s.5-2.8 2-4c1.7-1.3 4 0 4 0M12 15v5s2.8-.5 4-2c1.3-1.7 0-4 0-4" />
</svg>
);
}
/* -------------------------------------------------------------------------- */
/* Props */
/* -------------------------------------------------------------------------- */
export interface DeploymentCommandCenterProps {
/** Environments offered in the top-bar switcher. The app owns this data. */
environments?: Environment[];
/** Which environment id is selected on first render. */
defaultEnvironmentId?: string;
/** Repository slug shown in the request body (fictional in the demo). */
repo?: string;
className?: string;
}
/* -------------------------------------------------------------------------- */
/* Main block */
/* -------------------------------------------------------------------------- */
export function DeploymentCommandCenter({
environments = DEFAULT_ENVIRONMENTS,
defaultEnvironmentId,
repo = "acme/ledger-web",
className,
}: DeploymentCommandCenterProps) {
const reduce = useReducedMotion();
/* selected environment ------------------------------------------------- */
const initialEnvId =
defaultEnvironmentId ?? environments.find((e) => e.type === "staging")?.id ?? environments[0]?.id ?? "";
const [selectedEnvId, setSelectedEnvId] = React.useState(initialEnvId);
const selectedEnv =
environments.find((e) => e.id === selectedEnvId) ?? environments[0];
/* run state machine ---------------------------------------------------- */
// Default first paint: a finished successful run so the console reads richly.
const [mode, setMode] = React.useState<RunMode>("ok");
const [revealed, setRevealed] = React.useState<number>(SUCCESS_ENTRIES.length);
const [running, setRunning] = React.useState(false);
const [retried, setRetried] = React.useState(false);
const [cancelled, setCancelled] = React.useState(false);
// Bumped per run so the log stream re-pins to the tail on a fresh deploy.
const [runToken, setRunToken] = React.useState(0);
const [following, setFollowing] = React.useState(true);
const timerRef = React.useRef<ReturnType<typeof setInterval> | null>(null);
const lenRef = React.useRef<number>(SUCCESS_ENTRIES.length);
const clearTimer = React.useCallback(() => {
if (timerRef.current != null) {
clearInterval(timerRef.current);
timerRef.current = null;
}
}, []);
React.useEffect(() => () => clearTimer(), [clearTimer]);
// Stop the run when the scripted timeline is exhausted.
React.useEffect(() => {
if (running && revealed >= lenRef.current) {
setRunning(false);
clearTimer();
}
}, [running, revealed, clearTimer]);
const startRun = React.useCallback(
(nextMode: RunMode, isRetry: boolean) => {
clearTimer();
lenRef.current = entriesFor(nextMode).length;
setMode(nextMode);
setRetried(isRetry);
setCancelled(false);
setRevealed(0);
setRunning(true);
setFollowing(true);
setRunToken((t) => t + 1);
timerRef.current = setInterval(() => {
setRevealed((r) => Math.min(r + 1, lenRef.current));
}, 750);
},
[clearTimer],
);
const deploy = React.useCallback(() => startRun("ok", false), [startRun]);
const deployWithFailure = React.useCallback(() => startRun("fail", false), [startRun]);
const retryRun = React.useCallback(() => startRun("ok", true), [startRun]);
const cancelRun = React.useCallback(() => {
clearTimer();
setRunning(false);
setCancelled(true);
}, [clearTimer]);
const reset = React.useCallback(() => {
clearTimer();
setMode("ok");
setRetried(false);
setCancelled(false);
setRunning(false);
setRevealed(SUCCESS_ENTRIES.length);
setFollowing(true);
setRunToken((t) => t + 1);
}, [clearTimer]);
/* derived views -------------------------------------------------------- */
const entries = entriesFor(mode);
const target = entries.length;
const visibleEntries = React.useMemo(() => entries.slice(0, revealed), [entries, revealed]);
const stages = React.useMemo(
() => deriveStages(mode, revealed, cancelled),
[mode, revealed, cancelled],
);
const done = !running && revealed >= target;
const failed = mode === "fail" && done && !cancelled;
const completed = mode === "ok" && done && !cancelled;
const deployStage = stages.find((s) => s.id === "deploy")!;
const { state: inspectorState, response: inspectorResponse } = deriveInspector(
deployStage.status,
cancelled,
retried,
);
const request = React.useMemo(() => makeRequest(selectedEnv, repo), [selectedEnv, repo]);
const streamStatus: LogStreamStatus = cancelled
? "idle"
: running
? "streaming"
: failed
? "error"
: completed
? "completed"
: "idle";
const phaseLabel = cancelled
? "Cancelled"
: running
? "Deploying"
: failed
? "Failed"
: completed
? "Deployed"
: "Idle";
const onEnvChange = React.useCallback((id: string) => setSelectedEnvId(id), []);
return (
<div
className={cn(
"w-full rounded-2xl border border-[var(--color-border)] bg-[var(--color-bg-secondary)] p-3 text-[var(--color-fg)] shadow-[var(--shadow-md)] sm:p-4",
className,
)}
>
{/* Top bar -------------------------------------------------------- */}
<div className="flex flex-col gap-3 rounded-xl border border-[var(--color-border)] bg-[var(--color-surface)] p-3 sm:p-3.5">
<div className="flex flex-wrap items-center gap-x-3 gap-y-2">
<span className="flex items-center gap-2 text-[13.5px] font-semibold">
<span className="grid h-7 w-7 place-items-center rounded-lg bg-[color-mix(in_oklab,var(--color-accent)_16%,transparent)] text-[var(--color-accent)]" aria-hidden>
<RocketGlyph />
</span>
<span className="flex flex-col leading-tight">
<span>Deployment Command Center</span>
<span className="font-mono text-[11px] font-normal text-[var(--color-muted)]">{repo}</span>
</span>
</span>
<span
className="inline-flex items-center gap-1.5 rounded-full border border-[var(--color-border)] bg-[var(--color-bg-secondary)] px-2 py-0.5 text-[11.5px] font-medium text-[var(--color-muted)]"
role="status"
aria-live="polite"
>
<span className="relative grid h-2 w-2 place-items-center" aria-hidden>
<span
className="h-1.5 w-1.5 rounded-full"
style={{
background: running
? "var(--color-accent)"
: failed
? "var(--color-error)"
: completed
? "var(--color-success)"
: "var(--color-muted)",
}}
/>
{running && !reduce ? (
<motion.span
className="absolute inset-0 rounded-full"
style={{ background: "var(--color-accent)" }}
initial={{ opacity: 0.55, scale: 1 }}
animate={{ opacity: 0, scale: 2.6 }}
transition={{ duration: 1.4, repeat: Infinity, ease: "easeOut" }}
/>
) : null}
</span>
{phaseLabel}
</span>
<span className="ml-auto flex flex-wrap items-center gap-2">
<button type="button" className={primaryBtn} onClick={deploy} disabled={running}>
<RocketGlyph />
{running ? "Deploying…" : "Deploy"}
</button>
</span>
</div>
<div className="flex flex-wrap items-end gap-x-3 gap-y-2">
<div className="min-w-[15rem] flex-1">
<EnvironmentSwitcher
environments={environments}
value={selectedEnvId}
onValueChange={onEnvChange}
requireProductionConfirmation
recentIds={["staging"]}
favoriteIds={["production"]}
now={BASE_TS}
label="Target environment"
/>
</div>
</div>
</div>
{/* Console grid --------------------------------------------------- */}
<div className="mt-3 grid gap-3 lg:grid-cols-[minmax(0,1fr)_minmax(0,26rem)]">
{/* Main column: pipeline + logs ------------------------------- */}
<div className="flex min-w-0 flex-col gap-3">
<section aria-label="Deployment pipeline" className="min-w-0">
<div className="mb-2 flex items-center gap-2">
<h3 className="text-[12.5px] font-semibold uppercase tracking-wide text-[var(--color-muted)]">Pipeline</h3>
<span className="font-mono text-[11.5px] text-[var(--color-muted)]">
{stages.filter((s) => s.status === "passed").length}/{stages.length} stages
</span>
</div>
<DeploymentPipeline stages={stages} onRetry={() => retryRun()} />
</section>
<section aria-label="Live logs" className="min-w-0">
<div className="mb-2 flex items-center gap-2">
<h3 className="text-[12.5px] font-semibold uppercase tracking-wide text-[var(--color-muted)]">Logs</h3>
<span className="inline-flex items-center gap-1 font-mono text-[11.5px] text-[var(--color-muted)]">
<span
className="h-1.5 w-1.5 rounded-full"
style={{ background: following ? "var(--color-success)" : "var(--color-muted)" }}
aria-hidden
/>
{following ? "Following latest" : "Paused - scroll to resume"}
</span>
</div>
<LiveLogStream
key={runToken}
entries={visibleEntries}
status={streamStatus}
errorMessage={FAIL_RESPONSE.error}
onFollowChange={setFollowing}
onRetry={retryRun}
title="Deploy output"
className="[--log-height:16rem]"
/>
</section>
</div>
{/* Side panel: request inspector ------------------------------ */}
<aside aria-label="Request inspector" className="min-w-0">
<div className="mb-2 flex items-center gap-2">
<h3 className="text-[12.5px] font-semibold uppercase tracking-wide text-[var(--color-muted)]">Deploy request</h3>
</div>
<div className="lg:sticky lg:top-3">
<ApiRequestInspector
request={request}
response={inspectorResponse}
state={inspectorState}
auth={AUTH}
onRetry={retryRun}
onCancel={cancelRun}
defaultSection="response-body"
title="POST /v1/deployments"
/>
</div>
</aside>
</div>
{/* Demo controls + note ------------------------------------------ */}
<div className="mt-3 flex flex-wrap items-center gap-x-2 gap-y-2 rounded-xl border border-[var(--color-border)] bg-[var(--color-surface)] p-2.5">
<div className="flex flex-wrap items-center gap-1.5" role="group" aria-label="Console controls">
<button type="button" className={controlBtn} onClick={deploy} disabled={running}>
Run deploy
</button>
<button type="button" className={controlBtn} onClick={deployWithFailure} disabled={running}>
Run with failure
</button>
<button type="button" className={controlBtn} onClick={retryRun}>
Retry
</button>
{running ? (
<button type="button" className={controlBtn} onClick={cancelRun}>
Cancel
</button>
) : null}
<button type="button" className={controlBtn} onClick={reset}>
Reset
</button>
</div>
<span className="ml-auto inline-flex items-center gap-1.5 text-[11.5px] text-[var(--color-muted)]">
<span className="h-1.5 w-1.5 rounded-full bg-[var(--color-accent)]" aria-hidden />
Demo data - fictional, no live provider
</span>
</div>
</div>
);
}
export default DeploymentCommandCenter;
