A hub-and-spoke integrations diagram: the center pops in, paths draw out to six logos, then a dot travels each line. Uses MotionPathPlugin.
@tween-ui
components/tweenui/integration-hub.tsx
'use client';
import { useRef, type ComponentPropsWithoutRef, type ReactNode } from 'react';
import { useGSAP } from '@gsap/react';
import gsap from 'gsap';
import { MotionPathPlugin } from 'gsap/MotionPathPlugin';
import { cn } from '@/lib/utils';
gsap.registerPlugin(useGSAP, MotionPathPlugin);
const prefersReducedMotion = () =>
typeof window !== 'undefined' && window.matchMedia('(prefers-reduced-motion: reduce)').matches;
export interface IntegrationHubLogo {
src: string;
/** Optional mark shown under `.dark`. */
srcDark?: string;
alt: string;
}
export interface IntegrationHubProps extends Omit<ComponentPropsWithoutRef<'section'>, 'title'> {
/** Section heading. */
title?: ReactNode;
/** Supporting line under the heading. */
description?: string;
/** Three logos on the left (top, middle, bottom). */
left?: IntegrationHubLogo[];
/** Three logos on the right (top, middle, bottom). */
right?: IntegrationHubLogo[];
}
const DEFAULT_LEFT: IntegrationHubLogo[] = [
{ src: 'https://cdn.simpleicons.org/telegram/26A5E4', alt: 'Telegram' },
{ src: 'https://cdn.simpleicons.org/google/4285F4', alt: 'Google' },
{
src: 'https://cdn.simpleicons.org/notion/000000',
srcDark: 'https://cdn.simpleicons.org/notion/ffffff',
alt: 'Notion',
},
];
const DEFAULT_RIGHT: IntegrationHubLogo[] = [
{ src: 'https://cdn.simpleicons.org/reddit/FF4500', alt: 'Reddit' },
{ src: 'https://cdn.simpleicons.org/stripe/635BFF', alt: 'Stripe' },
{ src: 'https://cdn.simpleicons.org/zoom/2D8CFF', alt: 'Zoom' },
];
const PATHS = [
{
transform: 'translate(449,240) scale(1.5) translate(-227,-147.703)',
d: 'M227 147.703H192.062C172.52 147.703 154.769 136.319 146.619 118.558L105.908 29.8482C97.7568 12.0876 80.006 0.703125 60.4644 0.703125H0',
},
{
transform: 'translate(500,250) scale(1.7) translate(-227,0)',
d: 'M227 0.703125H0',
},
{
transform: 'translate(450,262) scale(1.5) translate(-227,0)',
d: 'M227 0.703132H192.062C172.52 0.703132 154.769 12.0876 146.619 29.8482L105.908 118.558C97.7568 136.319 80.006 147.703 60.4644 147.703H0',
},
{
transform: 'translate(555,238) scale(1.5) translate(0,-147.703)',
d: 'M0 147.703H34.9383C54.4799 147.703 72.2306 136.319 80.3814 118.558L121.092 29.8482C129.243 12.0876 146.994 0.703125 166.536 0.703125H227',
},
{
transform: 'translate(500,250) scale(1.7) translate(0,0)',
d: 'M0 0.703125H227',
},
{
transform: 'translate(566,263) scale(1.5) translate(0,0)',
d: 'M0 0.703132H34.9383C54.4799 0.703132 72.2306 12.0876 80.3814 29.8482L121.092 118.558C129.243 136.319 146.994 147.703 166.536 147.703H227',
},
] as const;
/** Path ends in the 1000×500 viewBox. Keep the diagram at aspect-[2/1]. */
const NODE_SLOTS = [
{ x: '10.9%', y: '3.9%', side: 'left' },
{ x: '11.4%', y: '50.2%', side: 'left' },
{ x: '11.0%', y: '96.7%', side: 'left' },
{ x: '89.6%', y: '3.5%', side: 'right' },
{ x: '88.6%', y: '50.2%', side: 'right' },
{ x: '90.7%', y: '96.9%', side: 'right' },
] as const;
function HubMark() {
return (
<svg viewBox="0 0 24 24" className="size-8 fill-white lg:size-10" aria-hidden="true">
<path d="M8 5H10V7H8V5Z" />
<path d="M11 8H13V10H11V8Z" />
<path d="M14 11H16V13H14V11Z" />
<path d="M11 14H13V16H11V14Z" />
<path d="M8 17H10V19H8V17Z" />
</svg>
);
}
function LogoNode({ logo, slot }: { logo: IntegrationHubLogo; slot: (typeof NODE_SLOTS)[number] }) {
return (
<div
className={cn(
'absolute z-10 -translate-y-1/2',
slot.side === 'left' ? '-translate-x-full' : null
)}
style={{ left: slot.x, top: slot.y }}
>
<div
data-hub-node
className="relative grid size-14 scale-0 place-items-center rounded-3xl border border-[#045f64]/10 bg-white motion-reduce:scale-100 sm:size-16 md:size-[4.5rem] dark:border-white/10 dark:bg-[#12161F]"
>
<div className="absolute top-1/2 left-1/2 size-10 -translate-x-1/2 -translate-y-1/2 rounded-2xl border border-[#045f64]/10 sm:size-12 md:size-14 dark:border-white/10" />
<figure className="size-9 overflow-hidden rounded-xl bg-white sm:size-11 md:size-12 dark:bg-transparent">
{logo.srcDark ? (
<>
<img
src={logo.src}
alt={logo.alt}
className="size-full object-contain p-2 dark:hidden"
/>
<img
src={logo.srcDark}
alt=""
aria-hidden="true"
className="hidden size-full object-contain p-2 dark:block"
/>
</>
) : (
<img src={logo.src} alt={logo.alt} className="size-full object-contain p-2" />
)}
</figure>
</div>
</div>
);
}
export default function IntegrationHub({
title = 'One hub for every integration',
description = 'Connect Notion, Zoom, Stripe, and the rest of your stack without leaving your product.',
left = DEFAULT_LEFT,
right = DEFAULT_RIGHT,
className,
...props
}: IntegrationHubProps) {
const rootRef = useRef<HTMLElement>(null);
useGSAP(
() => {
const root = rootRef.current;
if (!root) return;
const diagram = root.querySelector<HTMLElement>('[data-hub-diagram]');
const rings = gsap.utils.toArray<HTMLElement>('[data-hub-ring]', root);
const paths = gsap.utils.toArray<SVGPathElement>('[data-hub-path]', root);
const dots = gsap.utils.toArray<SVGCircleElement>('[data-hub-dot]', root);
const nodes = gsap.utils.toArray<HTMLElement>('[data-hub-node]', root);
if (!diagram || rings.length < 1 || paths.length < 1) return;
const canDraw = paths.every((path) => typeof path.getTotalLength === 'function');
if (prefersReducedMotion() || !canDraw) {
gsap.set([...rings, ...nodes], { scale: 1 });
gsap.set(paths, { opacity: 1, strokeDashoffset: 0, strokeDasharray: 'none' });
gsap.set(dots, { autoAlpha: 0 });
return;
}
gsap.set(rings, { scale: 0, transformOrigin: '50% 50%' });
gsap.set(nodes, { scale: 0, transformOrigin: '50% 50%' });
paths.forEach((path) => {
const len = path.getTotalLength();
gsap.set(path, { strokeDasharray: len, strokeDashoffset: len, opacity: 1 });
});
gsap.set(dots, { autoAlpha: 0 });
const tl = gsap.timeline();
tl.to(rings, { scale: 1, duration: 0.55, ease: 'back.out(1.15)' });
tl.to(
paths,
{ strokeDashoffset: 0, duration: 0.85, stagger: 0.06, ease: 'power2.inOut' },
'-=0.1'
);
tl.to(nodes, { scale: 1, duration: 0.4, stagger: 0.07, ease: 'back.out(1.2)' }, '-=0.05');
tl.add(() => {
paths.forEach((path, index) => {
const dot = dots[index];
if (!dot) return;
const tween = gsap.to(dot, {
duration: 4,
repeat: -1,
ease: 'none',
paused: true,
motionPath: {
path,
align: path,
alignOrigin: [0.5, 0.5],
autoRotate: false,
start: 0,
end: 1,
},
});
gsap.set(dot, { autoAlpha: 1 });
tween.progress((0.45 + index * 0.08) % 1).play();
});
});
},
{ scope: rootRef }
);
return (
<section
{...props}
ref={rootRef}
data-integration-hub
className={cn('w-full py-16 md:py-20', className)}
>
<div className="mx-auto w-full max-w-[804px] space-y-16 px-4">
<div className="space-y-6 text-center">
<h2 className="text-2xl leading-[1.15] font-medium tracking-tight text-[#12161F] md:text-3xl lg:text-4xl dark:text-white">
{title}
</h2>
<p className="mx-auto max-w-[400px] text-sm leading-relaxed text-[#045f64]/70 dark:text-[#9fd4d6]/80">
{description}
</p>
</div>
<div data-hub-diagram className="relative mx-auto aspect-[2/1] w-full max-w-full">
<svg
className="absolute inset-0 h-full w-full"
viewBox="0 0 1000 500"
preserveAspectRatio="xMidYMid meet"
aria-hidden="true"
>
{PATHS.map((path) => (
<g key={path.transform} transform={path.transform}>
<path
data-hub-path
className="fill-none stroke-[#045f64]/15 stroke-1 opacity-0 motion-reduce:opacity-100 dark:stroke-white/15"
d={path.d}
/>
<circle
data-hub-dot
className="fill-[#045f64] opacity-0 motion-reduce:hidden dark:fill-[#c6f56f]"
r={2}
/>
</g>
))}
</svg>
<div className="absolute top-1/2 left-1/2 -translate-x-1/2 -translate-y-1/2">
<div
data-hub-ring
className="relative grid size-20 scale-0 place-items-center rounded-full border border-[#045f64]/10 bg-white/80 backdrop-blur-[20px] motion-reduce:scale-100 md:size-36 lg:size-40 dark:border-white/10 dark:bg-[#12161F]/80"
>
<div className="absolute inset-[14%] rounded-full border border-[#045f64]/10 dark:border-white/10" />
<figure className="relative z-10 grid size-16 place-items-center rounded-full bg-[linear-gradient(90deg,#045f64_0%,#c6f56f_100%)] md:size-20">
<HubMark />
</figure>
</div>
</div>
{left.map((logo, index) => (
<LogoNode key={logo.alt} logo={logo} slot={NODE_SLOTS[index] ?? NODE_SLOTS[0]} />
))}
{right.map((logo, index) => (
<LogoNode key={logo.alt} logo={logo} slot={NODE_SLOTS[index + 3] ?? NODE_SLOTS[3]} />
))}
</div>
</div>
</section>
);
}
Docs, props and examples: https://tween-ui.vercel.app/block/integration-hub GSAP plugins (MotionPathPlugin) are registered inside the component, so there is nothing to set up. The sample content loads images from cdn.simpleicons.org. Replace them with your own before shipping.
