Four-step install section. Picking a step fills the connector up to it and swaps in a detail panel with a short checklist, and the section closes on a copyable install command.
@hirael
registry/hirael/bases/radix/blocks/process-02/process-02.tsx
// Process 02 from Hirael <https://hirael.com/blocks/process/process-02>
// MIT · Mohammad Shehadeh · https://github.com/MohammadShehadeh/hirael
'use client';
import * as React from 'react';
import { Check } from 'lucide-react';
import { cn } from '@/lib/utils';
import { CopyButton } from '@/registry/hirael/bases/radix/components/copy-button';
import { Tabs, TabsContent, TabsList, TabsTrigger } from '@/registry/hirael/bases/radix/ui/tabs';
const ENTER =
'animate-in fade-in slide-in-from-bottom-4 duration-500 ease-[cubic-bezier(0.22,1,0.36,1)] fill-mode-both motion-reduce:animate-none';
const SWAP =
'animate-in fade-in slide-in-from-bottom-2 duration-250 ease-[cubic-bezier(0.22,1,0.36,1)] fill-mode-both motion-reduce:animate-none';
const stagger = (index: number, step = 60, offset = 0): React.CSSProperties => ({
animationDelay: `${offset + index * step}ms`,
});
const COMMAND = 'npx shadcn add https://hirael.com/r/command-palette.json';
interface Step {
value: string;
title: string;
body: string;
detail: string;
panelTitle: string;
panelBody: string;
checklist: readonly string[];
}
const STEPS: readonly Step[] = [
{
value: 'discover',
title: 'Discover',
body: 'Search the catalog by what you need, not by package name.',
detail: 'Around 170 items to browse',
panelTitle: 'Find the item that fits',
panelBody:
'Every item has a live preview in light, dark and right to left, so you can rule things out before reading any code.',
checklist: ['Filter by component, block or template', 'Switch the preview between Radix UI and Base UI'],
},
{
value: 'inspect',
title: 'Inspect',
body: 'Read the full source and the props table before it touches your repo.',
detail: 'One file for most components',
panelTitle: 'Know what you are adding',
panelBody:
'The source tab shows exactly what the CLI will write, including the shadcn primitives it expects you to have.',
checklist: [
'Registry dependencies listed by name',
'npm dependencies listed with the item',
'No runtime package, no telemetry',
],
},
{
value: 'sandbox',
title: 'Sandbox',
body: 'Try it inside a framed preview with your own theme tokens.',
detail: 'Takes about a minute',
panelTitle: 'Check it against your theme',
panelBody:
'The customizer swaps radius, base color and fonts on the preview, so you see the item the way your app will render it.',
checklist: ['Toggle light and dark', 'Flip the direction to check right to left', 'Resize to phone width'],
},
{
value: 'install',
title: 'Install',
body: 'Run one shadcn command and commit the files like any other code.',
detail: 'Writes 1 to 3 files',
panelTitle: 'Own the source',
panelBody:
'The CLI resolves the item, installs missing primitives and writes plain TSX into your components folder. From here it is your code.',
checklist: ['components/command-palette.tsx', 'Missing primitives: dialog, input', 'npm: lucide-react'],
},
];
const formatIndex = (index: number) => String(index + 1).padStart(2, '0');
const Process02 = () => {
const [active, setActive] = React.useState(STEPS[0].value);
const activeIndex = STEPS.findIndex((step) => step.value === active);
return (
<section data-slot="process" className="bg-background py-20 sm:py-28">
<div className="mx-auto flex w-full max-w-6xl flex-col gap-12 px-6 md:gap-16 md:px-10">
<div data-slot="process-header" className="flex max-w-xl flex-col gap-4">
<span className={cn(ENTER, 'text-xs text-muted-foreground uppercase')}>Install flow</span>
<h2
style={stagger(1, 70)}
className={cn(ENTER, 'text-3xl font-semibold tracking-tight text-balance sm:text-4xl')}
>
From the catalog to production
</h2>
<p style={stagger(2, 70)} className={cn(ENTER, 'text-base leading-relaxed text-muted-foreground')}>
Four steps, and only the last one changes your repo. Pick a step to see what happens during it.
</p>
</div>
<Tabs value={active} onValueChange={(value) => setActive(value)}>
<TabsList
variant="line"
className="grid h-auto w-full grid-cols-1 items-stretch group-data-[orientation=horizontal]/tabs:h-auto lg:grid-cols-4"
>
{STEPS.map((step, index) => {
const reached = index <= activeIndex;
const isLast = index === STEPS.length - 1;
return (
<TabsTrigger
key={step.value}
value={step.value}
style={stagger(index, 60, 200)}
className={cn(
ENTER,
'group/step relative h-auto flex-row items-start justify-start text-start whitespace-normal lg:flex-col',
'after:hidden',
)}
>
{!isLast && (
<>
<span aria-hidden className="absolute start-5.5 top-10 bottom-1 w-px bg-border lg:hidden">
<span
className={cn(
'absolute inset-0 origin-top bg-foreground transition-transform duration-500 ease-[cubic-bezier(0.22,1,0.36,1)] motion-reduce:transition-none',
index < activeIndex ? 'scale-y-100' : 'scale-y-0',
)}
/>
</span>
<span aria-hidden className="absolute start-12 end-2 top-4.5 hidden h-px bg-border lg:block">
<span
className={cn(
'absolute inset-0 origin-left bg-foreground transition-transform duration-500 ease-[cubic-bezier(0.22,1,0.36,1)] motion-reduce:transition-none rtl:origin-right',
index < activeIndex ? 'scale-x-100' : 'scale-x-0',
)}
/>
</span>
</>
)}
<span
dir="ltr"
className={cn(
'relative me-2.5 grid size-7 shrink-0 place-items-center rounded-full border text-[11px] font-medium tabular-nums transition-colors duration-250 lg:me-0 lg:mb-3.5',
index === activeIndex
? 'border-foreground bg-foreground text-background'
: reached
? 'border-foreground bg-background text-foreground'
: 'border-border bg-background text-muted-foreground group-hover/step:border-muted-foreground',
)}
>
{formatIndex(index)}
</span>
<span className="flex min-w-0 flex-col gap-1.5 pe-4 pt-0.5 pb-8 lg:pt-0 lg:pb-0">
<span
className={cn(
'text-base font-medium transition-colors duration-150',
reached ? 'text-foreground' : 'text-muted-foreground group-hover/step:text-foreground',
)}
>
{step.title}
</span>
<span className="text-sm leading-relaxed font-normal text-muted-foreground">{step.body}</span>
<span className="text-xs font-normal text-muted-foreground/80">{step.detail}</span>
</span>
</TabsTrigger>
);
})}
</TabsList>
{STEPS.map((step, index) => (
<TabsContent key={step.value} value={step.value} className="mt-6">
<div
data-slot="process-detail"
className="grid gap-8 border-y border-border py-8 md:grid-cols-[minmax(0,1fr)_minmax(0,1fr)] md:gap-14"
>
<div className={cn(SWAP, 'flex flex-col gap-3')}>
<span dir="ltr" className="self-start text-xs text-muted-foreground tabular-nums">
{formatIndex(index)}
<span className="mx-1.5 text-border">|</span>
{formatIndex(STEPS.length - 1)}
</span>
<h3 className="text-lg font-medium">{step.panelTitle}</h3>
<p className="max-w-md text-sm leading-relaxed text-muted-foreground">{step.panelBody}</p>
</div>
<ul className="flex flex-col gap-3 md:pt-7">
{step.checklist.map((item, itemIndex) => (
<li
key={item}
style={stagger(itemIndex + 1, 50)}
className={cn(SWAP, 'flex items-start gap-3 text-sm')}
>
<Check aria-hidden className="mt-0.5 size-4 shrink-0 text-primary" />
{item}
</li>
))}
</ul>
</div>
</TabsContent>
))}
</Tabs>
<div data-slot="process-command" className="flex flex-col gap-3">
<span className="text-xs text-muted-foreground uppercase">Try it now</span>
<div
dir="ltr"
className="flex items-center gap-3 rounded-lg border border-border bg-card/40 py-1.5 ps-4 pe-1.5"
>
<span aria-hidden className="text-sm text-muted-foreground select-none">
$
</span>
<span className="min-w-0 flex-1 truncate text-sm tabular-nums">{COMMAND}</span>
<CopyButton value={COMMAND} size="md" />
</div>
</div>
</div>
</section>
);
};
export default Process02;
