A photo gallery: filter chips with counts, a gap-free masonry of tiles that fade in, and a lightbox with caption, counter, thumbnail strip, arrow-key and swipe navigation, and a link to the original.
@ballmac
registry/ballmac/components/blocks/gallery-1/gallery-1.tsx
// Ballmac UI: Gallery 1. https://ui.ballmac.com/blocks/gallery-1
"use client"
import * as React from "react"
import { ArrowUpRight, ChevronLeft, ChevronRight, Expand, ImageOff, X } from "lucide-react"
import { Button } from "@/components/ballmac/button"
import { CoverArt, type CoverArtVariant } from "@/components/ballmac/cover-art"
import { Dialog, DialogClose, DialogContent, DialogDescription, DialogTitle } from "@/components/ballmac/dialog"
import { MasonryGrid, MasonryItem } from "@/components/ballmac/masonry-grid"
import { Media, type MediaSource } from "@/components/ballmac/media"
import { Skeleton } from "@/components/ballmac/skeleton"
import { useReturnFocus } from "@/lib/ballmac/return-focus"
import { frameProps, StateView, type StateProps } from "@/components/ballmac/state-view"
import { useDirection } from "@/lib/ballmac/direction"
import { cn } from "@/lib/utils"
type Gallery1Ratio = "square" | "landscape" | "portrait" | "tall"
type Gallery1Item = {
id: string
title: string
/** A sentence under the picture in the lightbox. */
caption?: string
/** A short line next to the title ("Lisbon, 2026"). */
meta?: string
category: string
/** The picture. Leave out and art is drawn from the id, so the gallery looks finished before you have photos. */
src?: MediaSource
/** Describes the picture. Required when `src` is set; use "" for decoration. */
alt?: string
/** The shape of the tile. */
ratio?: Gallery1Ratio
/** Where the full-size original lives. Adds a link in the lightbox. */
href?: string
}
type Gallery1Props = Omit<React.ComponentProps<"section">, "title"> &
StateProps & {
items?: Gallery1Item[]
title?: string
description?: string
/** The category shown at first, or "all". */
defaultCategory?: string
/** Called when a picture is opened in the lightbox. */
onOpen?: (item: Gallery1Item) => void
/** The id of a picture that is open in the lightbox at first. */
defaultOpenId?: string
}
const ratios: Record<Gallery1Ratio, string> = {
square: "aspect-square",
landscape: "aspect-[3/2]",
portrait: "aspect-[4/5]",
tall: "aspect-[3/4]",
}
const variants: CoverArtVariant[] = ["mesh", "rings", "bars", "dots", "waves"]
const sample: Gallery1Item[] = [
{ id: "g1", title: "The Lisbon studio", caption: "Our first office, above a bakery. The morning light on the long table is why we stayed.", meta: "Lisbon, 2024", category: "Offices", ratio: "landscape" },
{ id: "g2", title: "Launch day", caption: "Everyone in one room when version 2 went live, with pizza that arrived late.", meta: "March 2026", category: "Events", ratio: "portrait" },
{ id: "g3", title: "The first prototype", caption: "A paper model of the sidebar, taped to a window and argued over for a week.", meta: "2023", category: "Product", ratio: "square" },
{ id: "g4", title: "Design offsite", caption: "Two days in the mountains, no laptops until the second afternoon.", meta: "Serra da Estrela", category: "Team", ratio: "tall" },
{ id: "g5", title: "Standing desks", caption: "The new floor, with room for the support team to sit next to engineering.", meta: "Porto, 2026", category: "Offices", ratio: "square" },
{ id: "g6", title: "Conference talk", caption: "Mara on stage explaining why empty states deserve a designer.", meta: "Berlin, 2025", category: "Events", ratio: "landscape" },
{ id: "g7", title: "Sketching the dashboard", caption: "Four weeks of whiteboards before a single pixel was drawn.", meta: "2025", category: "Product", ratio: "portrait" },
{ id: "g8", title: "Friday lunch", caption: "The one rule: nobody talks about work for the first twenty minutes.", meta: "Every week", category: "Team", ratio: "landscape" },
{ id: "g9", title: "The wall of notes", caption: "Every customer letter we have kept, pinned where we pass it daily.", meta: "Lisbon", category: "Offices", ratio: "tall" },
{ id: "g10", title: "Community meetup", caption: "Sixty people, a projector and a very patient host.", meta: "Lisbon, 2025", category: "Events", ratio: "square" },
{ id: "g11", title: "Color study", caption: "Forty swatches narrowed to five over one long lunch.", meta: "2024", category: "Product", ratio: "landscape" },
{ id: "g12", title: "The whole team", caption: "Twenty-three people on one staircase, and one blurry photographer.", meta: "Autumn 2026", category: "Team", ratio: "portrait" },
]
function GallerySkeleton() {
const heights = ["h-56", "h-72", "h-48", "h-64", "h-80", "h-52"]
return (
<div className="grid gap-4 sm:grid-cols-2 lg:grid-cols-3" aria-hidden="true">
{heights.map((h, i) => (
<div key={i} className="grid gap-2">
<Skeleton className={cn("rounded-2xl", h)} />
<Skeleton className="h-3.5 w-1/2" />
</div>
))}
</div>
)
}
function Picture({ item, index, className, fit = "cover" }: { item: Gallery1Item; index: number; className?: string; fit?: "cover" | "contain" }) {
return (
<Media
media={item.src}
alt={item.alt ?? ""}
fit={fit}
fill
className={cn("absolute inset-0", className)}
fallback={<CoverArt seed={item.id} variant={variants[index % variants.length]} grid className="absolute inset-0" />}
/>
)
}
/**
* A photo gallery: filter chips with counts, a gap-free masonry of tiles that fade in, and a lightbox with the caption, a counter, a
* thumbnail strip, arrow-key and swipe navigation (mirrored in right-to-left), and a link to the original.
*/
function Gallery1({
items = sample,
title = "Life at Acme",
description = "Offices, launches and the people behind the work.",
defaultCategory = "all",
onOpen,
defaultOpenId,
state = "ready",
onRetry,
emptyState,
errorState,
className,
...props
}: Gallery1Props) {
const id = React.useId()
const dir = useDirection()
const [category, setCategory] = React.useState(defaultCategory)
const [openIndex, setOpenIndex] = React.useState<number | null>(() => {
const at = defaultOpenId ? items.filter((i) => defaultCategory === "all" || i.category === defaultCategory).findIndex((i) => i.id === defaultOpenId) : -1
return at >= 0 ? at : null
})
const swipe = React.useRef<number | null>(null)
const ready = state === "ready" || state === "empty"
const categories = [...new Set(items.map((i) => i.category))]
const list = state === "empty" ? [] : items
const filtered = list.filter((i) => category === "all" || i.category === category)
const current = openIndex !== null ? filtered[openIndex] : undefined
const returnFocus = useReturnFocus(current !== undefined)
const indexInAll = (item: Gallery1Item) => items.findIndex((x) => x.id === item.id)
const go = (delta: number) => setOpenIndex((i) => (i === null || !filtered.length ? i : (i + delta + filtered.length) % filtered.length))
const open = (index: number) => {
setOpenIndex(index)
const item = filtered[index]
if (item) onOpen?.(item)
}
function onKeyDown(e: React.KeyboardEvent) {
const forward = dir === "rtl" ? "ArrowLeft" : "ArrowRight"
const back = dir === "rtl" ? "ArrowRight" : "ArrowLeft"
if (e.key === forward) {
e.preventDefault()
go(1)
} else if (e.key === back) {
e.preventDefault()
go(-1)
} else if (e.key === "Home") {
e.preventDefault()
setOpenIndex(0)
} else if (e.key === "End") {
e.preventDefault()
setOpenIndex(filtered.length - 1)
}
}
const content = (
<>
{categories.length > 1 ? (
<fieldset className="mb-8" disabled={!ready}>
<legend className="sr-only">Category</legend>
<div className="flex flex-wrap gap-2">
{[{ key: "all", label: "All", n: list.length }, ...categories.map((c) => ({ key: c, label: c, n: list.filter((i) => i.category === c).length }))].map((c) => (
<label
key={c.key}
className="has-[:focus-visible]:ring-ring/50 hover:bg-accent/60 has-[:checked]:bg-foreground has-[:checked]:text-background has-[:checked]:border-foreground flex cursor-pointer items-center gap-2 rounded-full border px-4 py-1.5 text-sm transition-colors duration-150 has-[:focus-visible]:ring-[3px]"
>
<input type="radio" name={`${id}-cat`} value={c.key} checked={category === c.key} onChange={() => setCategory(c.key)} className="sr-only" />
{c.label}{" "}
<span className="text-xs tabular-nums opacity-70">{c.n}</span>
</label>
))}
</div>
</fieldset>
) : null}
{filtered.length ? (
<MasonryGrid key={category} columns={{ base: 1, sm: 2, lg: 3 }} gap="lg" reveal>
{filtered.map((item, i) => (
<MasonryItem key={item.id}>
<button
type="button"
aria-haspopup="dialog"
onClick={() => open(i)}
className="group/tile focus-visible:ring-ring/50 block w-full rounded-2xl text-start outline-none focus-visible:ring-[3px]"
>
<span className={cn("bg-muted relative block w-full overflow-hidden rounded-2xl border shadow-xs", ratios[item.ratio ?? "landscape"])}>
<Picture item={item} index={indexInAll(item)} className="transition-transform duration-700 ease-out group-hover/tile:scale-[1.05] motion-reduce:transition-none motion-reduce:group-hover/tile:scale-100" />
<span aria-hidden="true" className="absolute inset-0 bg-gradient-to-t from-black/30 to-transparent opacity-0 transition-opacity duration-300 group-hover/tile:opacity-100 group-focus-visible/tile:opacity-100 motion-reduce:transition-none" />
<span aria-hidden="true" className="bg-background/90 text-foreground absolute end-3 top-3 flex size-8 translate-y-1 items-center justify-center rounded-full opacity-0 shadow-sm backdrop-blur transition-all duration-300 group-hover/tile:translate-y-0 group-hover/tile:opacity-100 group-focus-visible/tile:translate-y-0 group-focus-visible/tile:opacity-100 motion-reduce:transition-none">
<Expand className="size-4" />
</span>
</span>
<span className="mt-3 flex items-baseline justify-between gap-3 px-1">
<span className="min-w-0 text-sm font-medium tracking-tight text-pretty">{item.title}</span>
<span className="text-muted-foreground shrink-0 text-xs">{item.category}</span>
</span>
{item.meta ? <span className="text-muted-foreground mt-0.5 block px-1 text-xs">{item.meta}</span> : null}
</button>
</MasonryItem>
))}
</MasonryGrid>
) : (
<div className="bg-card rounded-2xl border px-6 py-16 text-center">
<span aria-hidden="true" className="bg-muted mx-auto flex size-12 items-center justify-center rounded-full">
<ImageOff className="size-6" />
</span>
<h2 className="mt-5 text-lg font-semibold tracking-tight">{emptyState?.title ?? (list.length ? "Nothing in this category yet" : "No pictures yet")}</h2>
<p className="text-muted-foreground mx-auto mt-1.5 max-w-sm text-sm text-pretty">{emptyState?.description ?? (list.length ? "Try another category to see more." : "Pictures will appear here as they are added.")}</p>
{list.length ? (
<Button variant="outline" size="sm" className="mt-5" onClick={() => setCategory("all")}>
Show everything
</Button>
) : (
emptyState?.action
)}
</div>
)}
</>
)
return (
<section data-slot="gallery-1" data-state={state} aria-labelledby={`${id}-title`} className={cn("mx-auto w-full max-w-6xl px-4 py-12 sm:px-6", className)} {...frameProps(props)}>
<header className="mb-10 max-w-2xl">
<h1 id={`${id}-title`} className="text-4xl font-semibold tracking-[-0.04em] text-balance sm:text-5xl">
{title}
</h1>
<p className="text-muted-foreground mt-3 text-base text-pretty">{description}</p>
</header>
<StateView state={state === "loading" || state === "error" ? state : "ready"} onRetry={onRetry} label="Loading pictures" loading={<GallerySkeleton />} error={{ title: errorState?.title ?? "The pictures could not be loaded", description: errorState?.description ?? "Check your connection and try again.", ...errorState }}>
{content}
</StateView>
<Dialog open={current !== undefined} onOpenChange={(o) => !o && setOpenIndex(null)}>
{current ? (
<DialogContent showCloseButton={false} onKeyDown={onKeyDown} {...returnFocus} className="max-w-5xl gap-0 overflow-hidden p-0 sm:p-0">
<DialogTitle className="sr-only">{current.title}</DialogTitle>
<DialogDescription className="sr-only">
Picture {(openIndex ?? 0) + 1} of {filtered.length}. Use the left and right arrow keys to move between pictures.
</DialogDescription>
<div
className="bg-muted relative h-[min(60dvh,34rem)] touch-pan-y select-none"
onPointerDown={(e) => (swipe.current = e.clientX)}
onPointerUp={(e) => {
if (swipe.current === null) return
const dx = e.clientX - swipe.current
swipe.current = null
if (Math.abs(dx) > 60) go((dx < 0 ? 1 : -1) * (dir === "rtl" ? -1 : 1))
}}
>
<Picture item={current} index={indexInAll(current)} fit="contain" />
<DialogClose aria-label="Close" className="bg-background/85 hover:bg-background focus-visible:ring-ring/50 absolute end-3 top-3 z-10 flex size-9 items-center justify-center rounded-full border shadow-sm backdrop-blur outline-none focus-visible:ring-[3px]">
<X aria-hidden="true" className="size-4" />
</DialogClose>
{filtered.length > 1 ? (
<>
<button type="button" aria-label="Previous picture" onClick={() => go(-1)} className="bg-background/85 hover:bg-background focus-visible:ring-ring/50 absolute start-3 top-1/2 flex size-10 -translate-y-1/2 items-center justify-center rounded-full border shadow-sm backdrop-blur outline-none focus-visible:ring-[3px]">
<ChevronLeft aria-hidden="true" className="size-5 rtl:rotate-180" />
</button>
<button type="button" aria-label="Next picture" onClick={() => go(1)} className="bg-background/85 hover:bg-background focus-visible:ring-ring/50 absolute end-3 top-1/2 flex size-10 -translate-y-1/2 items-center justify-center rounded-full border shadow-sm backdrop-blur outline-none focus-visible:ring-[3px]">
<ChevronRight aria-hidden="true" className="size-5 rtl:rotate-180" />
</button>
</>
) : null}
</div>
<div className="flex flex-wrap items-start gap-x-6 gap-y-3 border-t p-5">
<div className="min-w-0 flex-1 basis-72">
<h2 className="text-lg font-semibold tracking-tight text-pretty">{current.title}</h2>
{current.caption ? <p className="text-muted-foreground mt-1 text-sm leading-relaxed text-pretty">{current.caption}</p> : null}
<p className="text-muted-foreground mt-2 text-xs">
{current.category}
{current.meta ? ` · ${current.meta}` : ""}
</p>
</div>
<div className="flex items-center gap-3">
<p className="text-muted-foreground text-sm tabular-nums" aria-hidden="true">
{(openIndex ?? 0) + 1} / {filtered.length}
</p>
{current.href ? (
<a href={current.href} className="focus-visible:ring-ring/50 hover:bg-accent inline-flex h-8 items-center gap-1.5 rounded-md border px-3 text-[13px] font-medium outline-none focus-visible:ring-[3px]">
Open original
<ArrowUpRight aria-hidden="true" className="size-3.5 rtl:-scale-x-100" />
</a>
) : null}
</div>
</div>
{filtered.length > 1 ? (
<div className="flex gap-2 overflow-x-auto border-t p-3" role="group" aria-label="All pictures">
{filtered.map((item, i) => (
<button
key={item.id}
type="button"
aria-label={`Picture ${i + 1}: ${item.title}`}
aria-current={i === openIndex ? "true" : undefined}
onClick={() => setOpenIndex(i)}
className={cn("bg-muted focus-visible:ring-ring/50 relative size-14 shrink-0 overflow-hidden rounded-lg border outline-none transition-[opacity,box-shadow] duration-150 focus-visible:ring-[3px]", i === openIndex ? "ring-foreground ring-2 ring-offset-2 ring-offset-card" : "opacity-60 hover:opacity-100")}
>
<Picture item={item} index={indexInAll(item)} />
</button>
))}
</div>
) : null}
</DialogContent>
) : null}
</Dialog>
</section>
)
}
export { Gallery1, type Gallery1Props, type Gallery1Item, type Gallery1Ratio }
