A DAW-style piano roll, laid out like Sona's note editor, a scrolling roll with a playable keyboard stuck to its side, a loop brace and bar ruler stuck on top, a velocity lane stuck at the bottom and a navigator to zoom across four bars: click to add notes, drag to move or resize either edge, Alt-drag to copy, shift-click to select and move several at once, double-click a note to delete it, Fold to keep only the pitches in use, with a BPM-driven loop that plays back in real time and always-on live preview as you edit. A timeline above the grid lets you click to seek or drag out a loop range to dial in a short phrase instead of always looping the whole grid. Drop a MIDI file onto the panel (or use the Import MIDI button) to load its notes and tempo onto the grid, and Export MIDI to save the current pattern back out as a .mid file
@audio-ui
block-piano-roll.tsx
"use client";
import {
encodeMidiFile,
type MidiFileNote,
parseMidiFile,
} from "@audio-ui/core/midi";
import {
createSource,
type PianoRoll as PianoRollPrimitive,
} from "@audio-ui/react";
import {
useCallback,
useEffect,
useId,
useMemo,
useRef,
useState,
} from "react";
import { IconPlaceholder } from "@/app/(create)/components/icon-placeholder";
import { Button } from "@/components/ui/button";
import { BpmControl } from "@/components/audio-ui/bpm-control";
import { Fader } from "@/components/audio-ui/fader";
import {
PianoRoll,
PianoRollGrid,
PianoRollKeys,
PianoRollStrip,
PianoRollVelocity,
PianoRollVelocityScale,
PianoRollViewport,
} from "@/components/audio-ui/piano-roll";
import {
Timeline,
TimelineLane,
TimelineMark,
TimelineNavigator,
TimelinePlayhead,
TimelineRange,
TimelineRangeHandle,
TimelineRuler,
} from "@/components/audio-ui/timeline";
import { useMasterBus } from "@/hooks/use-master-bus";
import { useMidiInput } from "@/hooks/use-midi-input";
import {
type UseSynthVoicesReturn,
useSynthVoices,
} from "@/hooks/use-synth-voices";
import {
type TransportRegion,
useTransportClock,
} from "@/hooks/use-transport-clock";
import type { EnvelopePoint } from "@/lib/envelope-ramp";
import { webAudio } from "@/lib/web-audio";
/** C2 to C6: more than fits, so the roll scrolls and opens on middle C. */
const MIN_PITCH = 36;
const MAX_PITCH = 84;
const DEFAULT_VOLUME = 0.7;
const BEATS_PER_BAR = 4;
/** Sixteenth notes: four steps to a beat. */
const STEPS_PER_BEAT = 4;
const STEPS_PER_BAR = STEPS_PER_BEAT * BEATS_PER_BAR;
const BARS = 4;
const TOTAL_STEPS = STEPS_PER_BAR * BARS;
/** The ruler's labels: the first step of each bar. */
const BAR_STEPS = Array.from({ length: BARS }, (_, bar) => bar * STEPS_PER_BAR);
const describeStep = (step: number) => `Step ${Math.floor(step) + 1}`;
const PITCH_NAMES = [
"C",
"C#",
"D",
"D#",
"E",
"F",
"F#",
"G",
"G#",
"A",
"A#",
"B",
];
/** "C4, step 5, 2 steps": where a note is, in the grid's own terms. */
const describeNote = (note: Note) =>
`${PITCH_NAMES[note.pitch % 12]}${Math.floor(note.pitch / 12) - 1}, step ${note.start + 1}, ${note.length} ${note.length === 1 ? "step" : "steps"}`;
const DEFAULT_BPM = 120;
const MIN_BPM = 20;
const MAX_BPM = 200;
/** Standard MIDI File resolution, ticks per quarter note, a common round value shared by most DAWs' own exports. */
const MIDI_TICKS_PER_QUARTER_NOTE = 480;
const MICROSECONDS_PER_MINUTE = 60_000_000;
const MIDI_FILE_ACCEPT = ".mid,.midi,audio/midi,audio/x-midi";
/** ADSR-shaped, matching the Envelope primitive's own default, this block doesn't expose an editable envelope, keeping it focused on the note grid. */
const DEFAULT_ENVELOPE: EnvelopePoint[] = [
{ x: 0, y: 0.05 },
{ x: 0.15, y: 1 },
{ x: 0.35, y: 0.6 },
{ x: 0.7, y: 0.6 },
{ x: 1, y: 0.05 },
];
type Note = PianoRollPrimitive.Root.Note;
type LoopRegion = TransportRegion;
/** No region set, the loop spans the full grid, the original always-loop-everything behavior. */
const FULL_LOOP_REGION: LoopRegion = { end: TOTAL_STEPS, start: 0 };
function clamp(value: number, min: number, max: number): number {
return Math.min(max, Math.max(min, value));
}
/** Quantizes a parsed MIDI file's tick-based notes onto the grid's fixed `TOTAL_STEPS` window, adopting the file's own tempo (clamped to the BPM control's range) rather than the grid's current one, notes starting at or past the last step are dropped, matching this block's fixed-length loop. */
function notesFromMidiFile(parsed: {
microsecondsPerQuarterNote: number;
notes: MidiFileNote[];
ticksPerQuarterNote: number;
}): { bpm: number; notes: Note[] } {
const bpm = clamp(
Math.round(MICROSECONDS_PER_MINUTE / parsed.microsecondsPerQuarterNote),
MIN_BPM,
MAX_BPM
);
const secondsPerTick =
parsed.microsecondsPerQuarterNote / 1_000_000 / parsed.ticksPerQuarterNote;
const stepDuration = 60 / bpm / STEPS_PER_BEAT;
const notes: Note[] = [];
for (const midiNote of parsed.notes) {
const start = Math.round(
(midiNote.startTick * secondsPerTick) / stepDuration
);
if (start < 0 || start >= TOTAL_STEPS) {
continue;
}
const length = clamp(
Math.round((midiNote.durationTicks * secondsPerTick) / stepDuration),
1,
TOTAL_STEPS - start
);
notes.push({
id: `midi-import-${notes.length}`,
length,
pitch: clamp(midiNote.note, MIN_PITCH, MAX_PITCH),
start,
velocity: clamp(midiNote.velocity, 0, 1),
});
}
return { bpm, notes };
}
/** The grid's own step/BPM timing converted to MIDI ticks at a fixed, common resolution, the inverse of `notesFromMidiFile`. */
function notesToMidiFile(notes: Note[], bpm: number): Uint8Array {
const ticksPerStep = MIDI_TICKS_PER_QUARTER_NOTE / STEPS_PER_BEAT;
const midiNotes: Omit<MidiFileNote, "track">[] = notes.map((note) => ({
channel: 0,
durationTicks: Math.round(note.length * ticksPerStep),
note: note.pitch,
startTick: Math.round(note.start * ticksPerStep),
velocity: note.velocity ?? 1,
}));
return encodeMidiFile({
bpm,
notes: midiNotes,
ticksPerQuarterNote: MIDI_TICKS_PER_QUARTER_NOTE,
});
}
interface UsePianoRollOptions {
bpm: number;
loopRegion: LoopRegion | null;
releaseAll: UseSynthVoicesReturn["releaseAll"];
releaseNote: UseSynthVoicesReturn["releaseNote"];
triggerNote: UseSynthVoicesReturn["triggerNote"];
}
/**
* Owns the notes, plays the ones the roll auditions (a key pressed, a note
* drawn or dragged), and wires the loop playback. The drift-free look-ahead
* timing lives in `useTransportClock`; this hook only schedules notes on its
* step boundaries and reads its position, so the audio and the playhead come
* from one source. Split out of the block component to keep it readable.
*/
function usePianoRoll({
bpm,
loopRegion,
releaseAll,
releaseNote,
triggerNote,
}: UsePianoRollOptions) {
const region = loopRegion ?? FULL_LOOP_REGION;
const [notes, setNotes] = useState<Note[]>([]);
const [playingPitches, setPlayingPitches] = useState<number[]>([]);
const notesRef = useRef(notes);
notesRef.current = notes;
const regionRef = useRef(region);
regionRef.current = region;
/** The clock's position, in steps, for the timeline's playhead to follow outside React. */
const [position] = useState(() => createSource(0));
/** The current tempo's step duration, mirrored from the transport clock so note-off offsets use its canonical step↔time mapping instead of a second copy. */
const secondsPerStepRef = useRef(0);
/** Mirrors the clock's `isPlaying` for the audition guard, which runs inside pointer callbacks rather than on render. */
const isPlayingRef = useRef<boolean>(false);
/** The pitches auditioned and not yet released. */
const auditionedRef = useRef(new Set<number>());
/**
* Plays what the roll auditions. While the loop plays, only the keys do:
* the loop schedules its own notes ahead through the same voices, and an
* edit sounding a pitch it has scheduled would cut it off.
*/
const handleNoteOn = useCallback(
(pitch: number, details: PianoRollPrimitive.Root.NoteOnEventDetails) => {
const fromKeys = details.reason === "press" || details.reason === "glide";
if (isPlayingRef.current && !fromKeys) {
return;
}
auditionedRef.current.add(pitch);
triggerNote(pitch, DEFAULT_ENVELOPE, details.velocity);
},
[triggerNote]
);
const handleNoteOff = useCallback(
(pitch: number) => {
if (auditionedRef.current.delete(pitch)) {
releaseNote(pitch, DEFAULT_ENVELOPE);
}
},
[releaseNote]
);
/** Fired on each step boundary the clock emits: schedules every note that starts on `step` as an absolute-time on/off pair, sample-accurate regardless of when the poll ran. Notes outside the loop region never match a step the clock emits, so they never sound, the region filter is the clock's, not ours. */
const scheduleStep = useCallback(
(step: number, time: number) => {
const secondsPerStep = secondsPerStepRef.current;
for (const recordedNote of notesRef.current) {
if (recordedNote.start !== step) {
continue;
}
const offTime = time + recordedNote.length * secondsPerStep;
triggerNote(
recordedNote.pitch,
DEFAULT_ENVELOPE,
recordedNote.velocity ?? 1,
time
);
releaseNote(recordedNote.pitch, DEFAULT_ENVELOPE, offTime);
}
},
[releaseNote, triggerNote]
);
const { getPosition, isPlaying, reanchor, secondsPerStep, start, stop } =
useTransportClock({
bpm,
onReset: releaseAll,
onStep: scheduleStep,
region: loopRegion,
stepsPerBeat: STEPS_PER_BEAT,
totalSteps: TOTAL_STEPS,
});
secondsPerStepRef.current = secondsPerStep;
isPlayingRef.current = isPlaying;
const stopPlayback = stop;
const startPlayback = useCallback(() => {
if (notesRef.current.length === 0) {
return;
}
start();
}, [start]);
/** Fired when a change to the loop range ends, re-anchors the loop so a region change is audible immediately instead of waiting for a stale iteration to finish. No-op while stopped. */
const commitLoopRegion = useCallback(() => {
reanchor();
}, [reanchor]);
/** Fired when the timeline's ruler moves the position. Clamps onto a step inside the region, then re-anchors so that step plays now. No-op while stopped. */
const seekTo = useCallback(
(step: number) => {
const { end, start: regionStart } = regionRef.current;
reanchor(clamp(Math.floor(step), regionStart, end - 1));
},
[reanchor]
);
const clearNotes = useCallback(() => {
stopPlayback();
setNotes([]);
}, [stopPlayback]);
/** Replaces the whole grid at once, after a MIDI file import. */
const importNotes = useCallback(
(next: Note[]) => {
stopPlayback();
setNotes(next);
},
[stopPlayback]
);
// Playhead + "which pitches are sounding" highlight, both derived from the
// clock's continuous position (fractional grid steps), one source, so there
// is no second note→time formula to keep in sync. The playhead follows the
// position source outside React.
useEffect(() => {
if (!isPlaying) {
setPlayingPitches([]);
return;
}
let rafId: number;
let lastSounding: number[] = [];
const tick = () => {
const position_ = getPosition();
const { end, start: regionStart } = regionRef.current;
position.set(position_);
const sounding = notesRef.current
.filter((n) => {
if (n.start < regionStart || n.start >= end) {
return false;
}
return position_ >= n.start && position_ < n.start + n.length;
})
.map((n) => n.pitch);
const changed =
sounding.length !== lastSounding.length ||
sounding.some((pitch, i) => pitch !== lastSounding[i]);
if (changed) {
lastSounding = sounding;
setPlayingPitches(sounding);
}
rafId = requestAnimationFrame(tick);
};
rafId = requestAnimationFrame(tick);
return () => cancelAnimationFrame(rafId);
}, [getPosition, isPlaying, position]);
return {
clearNotes,
commitLoopRegion,
handleNoteOff,
handleNoteOn,
importNotes,
isPlaying,
notes,
playingPitches,
position,
seekTo,
setNotes,
startPlayback,
stopPlayback,
};
}
export function BlockPianoRoll() {
const volumeId = useId();
const volumeLabelId = useId();
const volumeValueId = useId();
const helpId = useId();
const [volume, setVolume] = useState(DEFAULT_VOLUME);
/** Folded, only the pitches carrying notes get a row. */
const [folded, setFolded] = useState(false);
const toggleFolded = useCallback(() => setFolded((current) => !current), []);
const viewportRef = useRef<HTMLDivElement>(null);
// Opens on middle C, halfway down the range.
useEffect(() => {
const viewport = viewportRef.current;
if (viewport) {
viewport.scrollTop = (viewport.scrollHeight - viewport.clientHeight) / 2;
}
}, []);
const [bpm, setBpm] = useState(DEFAULT_BPM);
const [loopRegion, setLoopRegion] = useState<LoopRegion | null>(null);
const loopRange: readonly [number, number] = loopRegion
? [loopRegion.start, loopRegion.end]
: [0, TOTAL_STEPS];
/** The loop range moves freely under the pointer; the loop itself is in whole steps. */
const changeLoopRegion = useCallback(
([start, end]: readonly [number, number]) => {
setLoopRegion({ end: Math.round(end), start: Math.round(start) });
},
[]
);
const masterGain = useMasterBus(volume);
const { releaseAll, releaseNote, triggerNote } = useSynthVoices({
destination: masterGain,
});
const {
clearNotes,
commitLoopRegion,
handleNoteOff,
handleNoteOn,
importNotes,
isPlaying,
notes,
playingPitches,
position,
seekTo,
setNotes,
startPlayback,
stopPlayback,
} = usePianoRoll({
bpm,
loopRegion,
releaseAll,
releaseNote,
triggerNote,
});
// A MIDI keyboard plays the roll's voices and lights its keys, once the page's MIDI input is connected.
const midiNoteOn = useCallback(
(pitch: number, velocity: number) => {
const ctx = webAudio.getContext();
if (ctx?.state === "suspended") {
ctx.resume();
}
triggerNote(pitch, DEFAULT_ENVELOPE, velocity);
},
[triggerNote]
);
const midiNoteOff = useCallback(
(pitch: number) => releaseNote(pitch, DEFAULT_ENVELOPE),
[releaseNote]
);
const midi = useMidiInput({ onNoteOff: midiNoteOff, onNoteOn: midiNoteOn });
const activePitches = useMemo(
() => [...playingPitches, ...midi.activeNotes],
[midi.activeNotes, playingPitches]
);
/** A double-click on the loop goes back to looping the whole grid. */
const clearLoopRegion = useCallback(() => {
setLoopRegion(null);
commitLoopRegion();
}, [commitLoopRegion]);
useEffect(() => {
const handleKeyDown = (e: KeyboardEvent) => {
// A note takes Space for itself, to select it.
if (e.code !== "Space" || e.defaultPrevented) {
return;
}
const tag = (e.target as HTMLElement | null)?.tagName;
if (tag === "INPUT" || tag === "TEXTAREA" || tag === "BUTTON") {
return;
}
e.preventDefault();
if (isPlaying) {
stopPlayback();
} else if (notes.length > 0) {
startPlayback();
}
};
window.addEventListener("keydown", handleKeyDown);
return () => window.removeEventListener("keydown", handleKeyDown);
}, [isPlaying, notes.length, startPlayback, stopPlayback]);
const fileInputRef = useRef<HTMLInputElement | null>(null);
const [isDraggingFile, setIsDraggingFile] = useState(false);
const importMidiFile = useCallback(
async (file: File) => {
const buffer = await file.arrayBuffer();
const parsed = parseMidiFile(buffer);
const imported = notesFromMidiFile(parsed);
importNotes(imported.notes);
setBpm(imported.bpm);
},
[importNotes]
);
const handleImportButtonClick = useCallback(() => {
fileInputRef.current?.click();
}, []);
const handleFileInputChange = useCallback(
(e: React.ChangeEvent<HTMLInputElement>) => {
const file = e.target.files?.[0];
e.target.value = "";
if (file) {
importMidiFile(file);
}
},
[importMidiFile]
);
const handleDragOver = useCallback((e: React.DragEvent<HTMLDivElement>) => {
if (!e.dataTransfer.types.includes("Files")) {
return;
}
e.preventDefault();
setIsDraggingFile(true);
}, []);
const handleDragLeave = useCallback((e: React.DragEvent<HTMLDivElement>) => {
if (e.currentTarget.contains(e.relatedTarget as Node | null)) {
return;
}
setIsDraggingFile(false);
}, []);
const handleDrop = useCallback(
(e: React.DragEvent<HTMLDivElement>) => {
const [file] = e.dataTransfer.files;
if (!file) {
return;
}
e.preventDefault();
setIsDraggingFile(false);
importMidiFile(file);
},
[importMidiFile]
);
const handleExportMidiFile = useCallback(() => {
const bytes = notesToMidiFile(notes, bpm);
// `Uint8Array`'s `.buffer` types as `ArrayBufferLike` (which also covers
// `SharedArrayBuffer`) while `BlobPart` wants a concrete `ArrayBuffer`,
// safe here since `encodeMidiFile` always builds a fresh, non-shared one.
const blob = new Blob([bytes.buffer as ArrayBuffer], {
type: "audio/midi",
});
const url = URL.createObjectURL(blob);
const link = document.createElement("a");
link.href = url;
link.download = "piano-roll.mid";
link.click();
URL.revokeObjectURL(url);
}, [bpm, notes]);
return (
<div
className="rounded-xl relative flex w-full min-w-0 flex-col gap-4 border bg-card p-4"
onDragLeave={handleDragLeave}
onDragOver={handleDragOver}
onDrop={handleDrop}
role="group"
>
<input
accept={MIDI_FILE_ACCEPT}
className="sr-only"
onChange={handleFileInputChange}
ref={fileInputRef}
type="file"
/>
{isDraggingFile ? (
<div
aria-hidden="true"
className="pointer-events-none absolute inset-0 z-10 flex items-center justify-center rounded-[inherit] border-2 border-primary border-dashed bg-background/80 font-medium text-sm"
>
Drop a MIDI file to import
</div>
) : null}
<div className="flex flex-wrap items-center justify-between gap-2">
<div className="flex flex-wrap items-center gap-2">
<Button
disabled={notes.length === 0}
onClick={isPlaying ? stopPlayback : startPlayback}
size="sm"
type="button"
variant="outline"
>
{isPlaying ? "Stop" : "Play"}
</Button>
<Button
disabled={notes.length === 0}
onClick={clearNotes}
size="sm"
type="button"
variant="ghost"
>
Clear
</Button>
<Button
aria-label="Import a MIDI file"
onClick={handleImportButtonClick}
size="icon-sm"
title="Import a MIDI file"
type="button"
variant="ghost"
>
<IconPlaceholder
hugeicons="Upload01Icon"
lucide="UploadIcon"
phosphor="UploadIcon"
remixicon="RiUploadLine"
tabler="IconUpload"
/>
</Button>
<Button
aria-label="Export as a MIDI file"
disabled={notes.length === 0}
onClick={handleExportMidiFile}
size="icon-sm"
title="Export as a MIDI file"
type="button"
variant="ghost"
>
<IconPlaceholder
hugeicons="Download01Icon"
lucide="DownloadIcon"
phosphor="DownloadIcon"
remixicon="RiDownloadLine"
tabler="IconDownload"
/>
</Button>
</div>
<BpmControl onValueChange={setBpm} value={bpm} />
</div>
<Timeline
duration={TOTAL_STEPS}
onPositionChange={seekTo}
snapStep={1}
source={position}
>
<PianoRoll
activePitches={activePitches}
className="h-104"
folded={folded}
getNoteLabel={describeNote}
maxPitch={MAX_PITCH}
minPitch={MIN_PITCH}
mode="draw"
onNoteOff={handleNoteOff}
onNoteOn={handleNoteOn}
onValueChange={setNotes}
value={notes}
>
<PianoRollStrip className="border-b">
<TimelineNavigator className="mx-2 my-1.5" />
</PianoRollStrip>
<PianoRollViewport ref={viewportRef}>
<PianoRollStrip
className="border-b"
lead={
<Button
aria-pressed={folded}
className="h-full w-full rounded-none text-[10px] uppercase tracking-wide"
onClick={toggleFolded}
size="sm"
type="button"
variant={folded ? "default" : "ghost"}
>
Fold
</Button>
}
sticky="top"
>
<TimelineLane className="h-5.5 cursor-cell bg-muted/40">
<TimelineRange
aria-label="Loop region"
className="rounded-none bg-primary/70 ring-0"
drawable
getAriaValueText={describeStep}
onDoubleClick={clearLoopRegion}
onValueChange={changeLoopRegion}
onValueCommitted={commitLoopRegion}
value={loopRange}
>
<TimelineRangeHandle
aria-label="Loop start"
className="rounded-none bg-foreground/20 hover:bg-foreground/40"
edge="start"
/>
<TimelineRangeHandle
aria-label="Loop end"
className="rounded-none bg-foreground/20 hover:bg-foreground/40"
edge="end"
/>
</TimelineRange>
</TimelineLane>
<TimelineRuler
aria-label="Playhead"
className="h-4.5 border-b-0 text-[10px]"
getAriaValueText={describeStep}
>
{BAR_STEPS.map((step, bar) => (
<TimelineMark className="ps-1" key={step} value={step}>
{bar + 1}
</TimelineMark>
))}
{isPlaying ? <TimelinePlayhead /> : null}
</TimelineRuler>
</PianoRollStrip>
<PianoRollStrip className="flex-1" lead={<PianoRollKeys />}>
<PianoRollGrid
accentStep={STEPS_PER_BEAT}
aria-describedby={helpId}
aria-label="Notes"
gridStep={1}
>
{isPlaying ? <TimelinePlayhead /> : null}
</PianoRollGrid>
</PianoRollStrip>
<PianoRollStrip
className="border-t"
lead={<PianoRollVelocityScale />}
sticky="bottom"
>
<PianoRollVelocity />
</PianoRollStrip>
</PianoRollViewport>
</PianoRoll>
</Timeline>
<p className="sr-only" id={helpId}>
Click the grid to add a note. Drag a note to move it, with Alt to copy
it, and drag its edges to change its length. Shift and a click adds a
note to the selection; Shift and a key selects every note on its row.
The arrow keys move the focused note, Shift with Left or Right changes
its length, Shift with Up or Down moves it an octave, and Delete removes
it. Enter on the grid adds a note at the playhead, and Escape clears the
selection.
</p>
<div className="flex flex-wrap items-center justify-between gap-4">
<div aria-label="Volume" className="flex-1" role="group">
<div className="flex w-full min-w-0 flex-col gap-3">
<div className="flex w-full min-w-0 items-center justify-between gap-4 [&>*:not(output):not(span)]:min-w-0 [&>*:not(output):not(span)]:flex-1">
<span
className="text-center text-muted-foreground text-xs"
id={volumeLabelId}
>
Volume
</span>
<Fader
aria-describedby={volumeValueId}
aria-labelledby={volumeLabelId}
id={volumeId}
max={1}
min={0}
onValueChange={setVolume}
orientation="horizontal"
step={0.01}
value={volume}
valueLabel="hidden"
/>
<output
aria-live="polite"
className="min-w-12 text-center font-mono text-muted-foreground text-xs tabular-nums"
id={volumeValueId}
>
{Math.round(volume * 100)}%
</output>
</div>
</div>
</div>
</div>
</div>
);
}
