A numbered section index where each row is a 3D drum that rolls a quarter turn onto a filled face on hover. The roll follows the pointer — in from the top rolls down, out through the bottom keeps rolling down — while the rules draw in on load.
@tween-ui
components/tweenui/cube-roll-item.tsx
'use client';
import { useRef, type ComponentPropsWithoutRef, type FocusEvent, type MouseEvent } from 'react';
import { useGSAP } from '@gsap/react';
import gsap from 'gsap';
import { cn } from '@/lib/utils';
gsap.registerPlugin(useGSAP);
const prefersReducedMotion = () =>
typeof window !== 'undefined' && window.matchMedia('(prefers-reduced-motion: reduce)').matches;
/** The roll follows the pointer — skip it on touch, where there is no hover. */
const canHover = () =>
typeof window !== 'undefined' && window.matchMedia('(hover: hover) and (pointer: fine)').matches;
/** Keyboard focus rolls the row; a mouse click that happens to focus it does not. */
const isFocusVisible = (el: HTMLElement) => {
try {
return el.matches(':focus-visible');
} catch {
return true;
}
};
/** Settles a touch past the face, like a drum clicking into its detent. */
const ROLL_EASE = 'back.out(1.6)';
/**
* Each row is a four-sided drum turning on its X axis. Front and back carry the
* resting face, top and bottom the filled one — so every quarter turn lands on
* the opposite state, and the drum can keep rolling the way the pointer moves.
* `--depth` matches the row height, which makes the drum a true square prism.
*/
const FACE_TRANSFORM = {
front: '[transform:translateZ(calc(var(--depth)/2))]',
back: '[transform:rotateX(180deg)_translateZ(calc(var(--depth)/2))]',
top: '[transform:rotateX(90deg)_translateZ(calc(var(--depth)/2))]',
bottom: '[transform:rotateX(-90deg)_translateZ(calc(var(--depth)/2))]',
} as const;
type Side = keyof typeof FACE_TRANSFORM;
const SIDES: Side[] = ['front', 'back', 'top', 'bottom'];
export interface CubeRollItemEntry {
/** Large title in the middle of the row. */
title: string;
/** Short line on the right. */
label?: string;
/** Link target for the row. */
href: string;
}
export interface CubeRollItemProps extends ComponentPropsWithoutRef<'nav'> {
/** Rows in the list, numbered in order. Defaults to a four-row sample. */
items?: CubeRollItemEntry[];
}
const DEFAULT_ITEMS: CubeRollItemEntry[] = [
{ title: 'Components', label: 'Buttons, text & logos', href: '#components' },
{ title: 'Blocks', label: 'Ready-made sections', href: '#blocks' },
{ title: 'Installation', label: 'One command, no config', href: '#installation' },
{ title: 'Changelog', label: 'What shipped lately', href: '#changelog' },
];
function Face({ side, item, number }: { side: Side; item: CubeRollItemEntry; number: string }) {
const filled = side === 'top' || side === 'bottom';
return (
<div
data-roll-face={side}
aria-hidden={side === 'front' ? undefined : true}
className={cn(
'absolute inset-0 backface-hidden',
FACE_TRANSFORM[side],
filled
? 'bg-[#045f64] text-white dark:bg-[#c6f56f] dark:text-[#071d1b]'
: 'bg-white text-[#12161F] dark:bg-[#0d1117] dark:text-white'
)}
>
{/* Equal side columns keep the title on the row's true center line. */}
<div className="flex h-full flex-wrap items-start px-3 pt-3.5 md:grid md:grid-cols-[1fr_2fr_1fr] md:items-center md:gap-6 md:px-4 md:pt-0">
<span
className={cn(
'order-1 flex items-center gap-1.5 text-xs tabular-nums',
filled ? 'text-[#c6f56f] dark:text-[#045f64]' : 'text-[#045f64] dark:text-[#9fd4d6]'
)}
>
{number}
{filled && (
<svg viewBox="0 0 12 12" className="size-3" fill="none" aria-hidden="true">
<path d="M1 6h9.5M6.5 2 10.5 6l-4 4" stroke="currentColor" strokeWidth="1.25" />
</svg>
)}
</span>
{/* Leading above 1 keeps descenders (g, y, p) inside the overflow box. */}
<span className="order-3 mt-2.5 w-full min-w-0 overflow-hidden text-center text-3xl leading-[1.3] font-normal tracking-tight text-ellipsis whitespace-nowrap md:order-2 md:mt-0 md:w-auto md:text-4xl">
{item.title}
</span>
{item.label && (
<span
className={cn(
'order-2 ml-auto text-right text-[13px] tracking-wide md:order-3 md:ml-0',
filled
? 'text-white/80 dark:text-[#071d1b]/75'
: 'text-[#045f64]/75 dark:text-[#9fd4d6]/80'
)}
>
{item.label}
</span>
)}
</div>
</div>
);
}
export default function CubeRollItem({
items = DEFAULT_ITEMS,
className,
'aria-label': ariaLabel = 'Sections',
...props
}: CubeRollItemProps) {
const rootRef = useRef<HTMLElement>(null);
/** Accumulated drum angle per row, in quarter turns of ±90°. */
const anglesRef = useRef<number[]>([]);
const activeRef = useRef<boolean[]>([]);
const { contextSafe } = useGSAP(
(_context, contextSafe) => {
anglesRef.current = items.map(() => 0);
activeRef.current = items.map(() => false);
if (prefersReducedMotion()) return;
// Park every drum half a turn over with its back face blanked, so each row
// starts as an empty slab and nothing shows in the fallback font.
const backContent = '[data-roll-face="back"] > *';
gsap.set('[data-roll-rule]', { scaleX: 0 });
gsap.set('[data-roll-drum]', { rotationX: 180 });
gsap.set(backContent, { opacity: 0 });
let cancelled = false;
// Rules draw in while the drums flip over one after another, flashing
// their filled face on the way past.
const play = contextSafe!(() => {
if (cancelled) return;
gsap
.timeline({ onComplete: () => gsap.set(backContent, { opacity: 1 }) })
.to(
'[data-roll-rule]',
{ scaleX: 1, duration: 0.9, ease: 'expo.inOut', stagger: 0.15 },
0
)
.to(
'[data-roll-drum]',
{ rotationX: 0, duration: 0.9, ease: 'power4.inOut', stagger: 0.15 },
0.15
);
});
// Wait for web fonts so the text never swaps mid-reveal; give up after a
// beat so a slow or failed font can't hold the block hidden.
const fonts = typeof document !== 'undefined' ? document.fonts?.ready : undefined;
Promise.race([fonts, new Promise((resolve) => setTimeout(resolve, 1500))]).then(play);
return () => {
cancelled = true;
};
},
{ scope: rootRef, dependencies: [items] }
);
/** Turn a row a quarter — downward when `down`, upward otherwise. */
const turn = contextSafe((link: HTMLElement, index: number, active: boolean, down: boolean) => {
if (activeRef.current[index] === active) return;
activeRef.current[index] = active;
link.closest('li')?.setAttribute('data-active', String(active));
const drum = link.querySelector('[data-roll-drum]');
if (!drum) return;
// Hovered before the intro finished: the back face may still be blank.
gsap.set(link.querySelectorAll('[data-roll-face="back"] > *'), { opacity: 1 });
if (prefersReducedMotion()) {
anglesRef.current[index] = active ? -90 : 0;
gsap.set(drum, { rotationX: anglesRef.current[index], opacity: 1 });
return;
}
anglesRef.current[index] = (anglesRef.current[index] ?? 0) + (down ? -90 : 90);
// `auto` takes rotationX from this drum's intro flip only, so hovering
// mid-reveal leaves the other rows' flips running.
gsap.to(drum, {
rotationX: anglesRef.current[index],
duration: active ? 0.6 : 0.7,
ease: ROLL_EASE,
overwrite: 'auto',
});
});
/** Did the pointer cross the top half of the row? */
const fromTop = (event: MouseEvent<HTMLElement>) => {
const rect = event.currentTarget.getBoundingClientRect();
return event.clientY < rect.top + rect.height / 2;
};
return (
<nav
ref={rootRef}
data-cube-roll-item
aria-label={ariaLabel}
className={cn('mx-auto w-full max-w-[1100px] px-4 py-14 md:py-20', className)}
{...props}
>
{/* No gap between rows, so the filled face covers the whole row edge to edge. */}
<ul className="flex flex-col">
{items.map((item, index) => {
const number = String(index + 1).padStart(3, '0');
return (
<li
key={item.href + item.title}
data-roll-row
data-active="false"
className="relative h-[5.75rem] overflow-y-clip [--depth:5.75rem] md:h-[4.5rem] md:[--depth:4.5rem]"
>
<span
data-roll-rule
aria-hidden="true"
className="pointer-events-none absolute inset-x-0 top-0 z-10 h-px origin-left bg-[#045f64] dark:bg-[#9fd4d6]/60"
/>
<a
href={item.href}
className="block size-full outline-none perspective-[1200px]"
// Enter from the top and the drum rolls down; leave through the
// bottom and it keeps rolling down rather than reversing.
onMouseEnter={(event) =>
canHover() && turn(event.currentTarget, index, true, fromTop(event))
}
onMouseLeave={(event) =>
canHover() && turn(event.currentTarget, index, false, !fromTop(event))
}
onFocus={(event: FocusEvent<HTMLAnchorElement>) =>
isFocusVisible(event.currentTarget) &&
turn(event.currentTarget, index, true, true)
}
onBlur={(event: FocusEvent<HTMLAnchorElement>) =>
turn(event.currentTarget, index, false, true)
}
>
<div className="relative size-full [transform:translateZ(calc(var(--depth)/-2))] transform-3d">
{/* Under reduced motion the drum only snaps, so skip the layer promotion. */}
<div
data-roll-drum
className="absolute inset-0 will-change-transform transform-3d motion-reduce:will-change-auto"
>
{SIDES.map((side) => (
<Face key={side} side={side} item={item} number={number} />
))}
</div>
</div>
</a>
</li>
);
})}
</ul>
{/* Closing rule under the last row. */}
<span
data-roll-rule
aria-hidden="true"
className="block h-px origin-left bg-[#045f64] dark:bg-[#9fd4d6]/60"
/>
</nav>
);
}
Docs, props and examples: https://tween-ui.vercel.app/block/cube-roll-item
