A connector grid where tiles run a real connect sequence and settle into connected.
@spectrumui
'use client';
import * as React from 'react';
import { AnimatePresence, motion, useReducedMotion } from 'motion/react';
import { cn } from '@/lib/utils';
import {
EmptyAction,
EmptyPanel,
EmptyState,
IconArrowRight,
IconSwap,
IconTickSquare,
SPRING_FLUID,
SPRING_SNAPPY,
EASE_IN_OUT,
} from './empty-state-kit';
export type IntegrationEmptyVariant = 'Catalog' | 'Featured' | 'Minimal';
export interface Connector {
id: string;
name: string;
kind: string;
/** A drawn mark on a 24-grid. Never ship someone else's trademark in a block. */
mark: React.ReactNode;
}
export interface IntegrationEmptyProps {
panelTitle?: string;
title?: string;
description?: string;
connectors?: Connector[];
browseLabel?: string;
onConnect?: (id: string) => void;
variant?: IntegrationEmptyVariant;
className?: string;
}
function Mark({ children }: { children: React.ReactNode }) {
return (
<svg viewBox="0 0 24 24" fill="none" stroke="currentColor" strokeWidth={1.6} aria-hidden="true">
{children}
</svg>
);
}
const CONNECTORS: Connector[] = [
{
id: 'postgres',
name: 'Postgres',
kind: 'Database',
mark: (
<Mark>
<ellipse cx="12" cy="6.5" rx="7" ry="3" />
<path d="M5 6.5v11c0 1.7 3.1 3 7 3s7-1.3 7-3v-11" />
<path d="M5 12c0 1.7 3.1 3 7 3s7-1.3 7-3" />
</Mark>
),
},
{
id: 'storage',
name: 'Object store',
kind: 'Files',
mark: (
<Mark>
<rect x="3.5" y="4" width="17" height="6" rx="1.5" />
<rect x="3.5" y="14" width="17" height="6" rx="1.5" />
<path d="M7 7h.01M7 17h.01" strokeLinecap="round" />
</Mark>
),
},
{
id: 'webhook',
name: 'Webhooks',
kind: 'Events',
mark: (
<Mark>
<circle cx="7" cy="7" r="2.5" />
<circle cx="17" cy="17" r="2.5" />
<path d="M9 8.5 15 15.5" />
<path d="M17 7v4M5 17h4" strokeLinecap="round" />
</Mark>
),
},
{
id: 'warehouse',
name: 'Warehouse',
kind: 'Analytics',
mark: (
<Mark>
<path d="M4 10 12 4l8 6v9a1 1 0 0 1-1 1H5a1 1 0 0 1-1-1z" />
<path d="M9 20v-6h6v6" />
</Mark>
),
},
{
id: 'queue',
name: 'Message queue',
kind: 'Streaming',
mark: (
<Mark>
<rect x="3.5" y="8" width="5" height="8" rx="1.2" />
<rect x="10" y="8" width="5" height="8" rx="1.2" />
<path d="M17.5 12h3M19 10.5 20.5 12 19 13.5" strokeLinecap="round" strokeLinejoin="round" />
</Mark>
),
},
{
id: 'sheet',
name: 'Spreadsheets',
kind: 'Import',
mark: (
<Mark>
<rect x="3.5" y="4.5" width="17" height="15" rx="2" />
<path d="M3.5 10h17M9.5 10v9.5M15 10v9.5" />
</Mark>
),
},
];
export function IntegrationEmpty({
panelTitle = 'Sources',
title = 'Nothing is connected yet',
description = 'A source is where your data comes from. Connect one and every chart, table and alert in this project has something to read.',
connectors = CONNECTORS,
browseLabel = 'Browse all 42 connectors',
onConnect,
variant = 'Catalog',
className,
}: IntegrationEmptyProps) {
const [connecting, setConnecting] = React.useState<string | null>(null);
const [connected, setConnected] = React.useState<string[]>([]);
const reduced = useReducedMotion();
const timer = React.useRef<ReturnType<typeof setTimeout> | undefined>(undefined);
React.useEffect(() => () => clearTimeout(timer.current), []);
function connect(id: string) {
if (connected.includes(id) || connecting) return;
setConnecting(id);
onConnect?.(id);
clearTimeout(timer.current);
timer.current = setTimeout(
() => {
setConnecting(null);
setConnected((current) => [...current, id]);
},
reduced ? 200 : 900,
);
}
const shown = variant === 'Featured' ? connectors.slice(0, 3) : connectors;
return (
<EmptyPanel
title={panelTitle}
meta={connected.length ? `${connected.length} connected` : 'None connected'}
className={className}
>
<EmptyState
icon={<IconSwap />}
backdrop="cells"
tone={connected.length ? 'positive' : 'neutral'}
title={
connected.length
? `${connected.length} source${connected.length > 1 ? 's' : ''} connected`
: title
}
description={
connected.length
? 'First sync runs within a minute. Add another whenever you need one.'
: description
}
actions={
<>
<EmptyAction
emphasis={connected.length ? 'secondary' : 'primary'}
trailing={<IconArrowRight />}
>
{browseLabel}
</EmptyAction>
<EmptyAction emphasis="quiet">Import a CSV instead</EmptyAction>
</>
}
>
{variant !== 'Minimal' && (
<div
className={cn(
'grid w-full max-w-[560px] gap-2',
variant === 'Featured' ? 'grid-cols-1 sm:grid-cols-3' : 'grid-cols-2 sm:grid-cols-3',
)}
>
{shown.map((connector) => {
const isDone = connected.includes(connector.id);
const isBusy = connecting === connector.id;
return (
<motion.button
key={connector.id}
type="button"
onClick={() => connect(connector.id)}
disabled={isDone || Boolean(connecting)}
whileTap={reduced || isDone ? undefined : { scale: 0.98 }}
transition={SPRING_SNAPPY}
className={cn(
'group relative flex cursor-pointer items-center gap-2.5 overflow-hidden rounded-xl border px-3 py-2.5 text-left',
'transition-transform duration-150 ease-out',
!isDone && 'hover:-translate-y-0.5',
'focus-visible:outline-hidden focus-visible:ring-1 focus-visible:ring-neutral-950 dark:focus-visible:ring-neutral-300',
'disabled:cursor-default',
isDone
? 'border-emerald-500/30 bg-emerald-500/[0.06]'
: 'border-black/[0.08] hover:border-black/[0.16] dark:border-white/[0.09] dark:hover:border-white/20',
)}
>
{isBusy && !reduced && (
<motion.span
aria-hidden
initial={{ x: '-110%' }}
animate={{ x: '110%' }}
transition={{ duration: 0.85, ease: EASE_IN_OUT }}
className="pointer-events-none absolute inset-y-0 w-1/2 bg-gradient-to-r from-transparent via-black/[0.06] to-transparent dark:via-white/[0.09]"
/>
)}
<span
className={cn(
'grid size-8 shrink-0 place-items-center rounded-[10px] border [&_svg]:size-[17px]',
isDone
? 'border-emerald-500/30 text-emerald-600 dark:text-emerald-400'
: 'border-black/[0.07] text-neutral-600 dark:border-white/[0.09] dark:text-neutral-300',
)}
>
{connector.mark}
</span>
<span className="min-w-0 flex-1">
<span className="block truncate text-[13.5px] font-medium text-neutral-800 dark:text-neutral-100">
{connector.name}
</span>
<span className="block truncate text-[12.5px] text-neutral-600 dark:text-neutral-400">
{isBusy ? 'Connecting…' : isDone ? 'Connected' : connector.kind}
</span>
</span>
<AnimatePresence initial={false}>
{isDone && (
<motion.span
initial={{ opacity: 0, scale: 0.5 }}
animate={{ opacity: 1, scale: 1 }}
transition={SPRING_FLUID}
className="shrink-0 text-emerald-600 [&_svg]:size-4 dark:text-emerald-400"
>
<IconTickSquare />
</motion.span>
)}
</AnimatePresence>
</motion.button>
);
})}
</div>
)}
</EmptyState>
</EmptyPanel>
);
}
