Centered integrations section: heading and copy above a hub with 6 linked tool tiles on straight spokes, with pulses travelling in and out along each line.
@hirael
registry/hirael/bases/radix/blocks/integrations-04/integrations-04.tsx
// Integrations 04 from Hirael <https://hirael.com/blocks/integrations/integrations-04>
// MIT · Mohammad Shehadeh · https://github.com/MohammadShehadeh/hirael
import { ArrowRight, Cloud, Database, GitBranch, Lock, Mail, MessageCircle, type LucideIcon } from 'lucide-react';
import { cn } from '@/lib/utils';
import { Button } from '@/registry/hirael/bases/radix/ui/button';
interface BrandMarkProps {
className?: string;
}
const BrandMark = ({ className }: BrandMarkProps) => {
return (
<svg viewBox="0 0 24 24" fill="currentColor" aria-hidden className={className}>
<path d="M2.3 12h2.4v10.95h6.2V14.6h4.6v8.35h6.2V12h-2.4V1.05h-6.2V9.4H8.5V1.05H2.3Z" />
</svg>
);
};
const ENTER =
'animate-in fade-in slide-in-from-bottom-4 duration-500 ease-[cubic-bezier(0.22,1,0.36,1)] fill-mode-both motion-reduce:animate-none';
const stagger = (index: number, step = 60, offset = 0): React.CSSProperties => ({
animationDelay: `${offset + index * step}ms`,
});
interface Spoke {
name: string;
icon: LucideIcon;
/** Degrees clockwise from 12 o'clock. */
angle: number;
href: string;
}
const SPOKES: readonly Spoke[] = [
{ name: 'Postgres', icon: Database, angle: 0, href: '#' },
{ name: 'Resend', icon: Mail, angle: 60, href: '#' },
{ name: 'S3', icon: Cloud, angle: 120, href: '#' },
{ name: 'Git', icon: GitBranch, angle: 180, href: '#' },
{ name: 'Vault', icon: Lock, angle: 240, href: '#' },
{ name: 'Discord', icon: MessageCircle, angle: 300, href: '#' },
] as const;
// The viewBox is 100 x 72 and the diagram keeps that aspect ratio, so a percentage of the
// box is the same point in both the SVG and the absolutely placed tiles.
const WIDTH = 100;
const HEIGHT = 72;
const CX = WIDTH / 2;
const CY = HEIGHT / 2;
const RX = 34;
const RY = 29;
const spokePosition = (angle: number) => {
const rad = (angle * Math.PI) / 180;
return {
x: Math.round((CX + RX * Math.sin(rad)) * 100) / 100,
y: Math.round((CY - RY * Math.cos(rad)) * 100) / 100,
};
};
const Integrations04 = () => {
return (
<section
data-slot="integrations"
className="bg-background py-20 sm:py-28"
aria-labelledby="integrations-04-heading"
>
<div className="mx-auto flex w-full max-w-3xl flex-col items-center px-4 text-center">
<h2
id="integrations-04-heading"
style={stagger(1)}
className={cn(ENTER, 'font-serif text-4xl font-medium tracking-tight text-balance sm:text-5xl')}
>
One hub for your entire stack
</h2>
<p style={stagger(2)} className={cn(ENTER, 'mt-4 max-w-xl text-base text-pretty text-muted-foreground')}>
Hirael sits in the middle of your workflow and keeps every tool you already run in step, so nothing drifts.
</p>
</div>
<div
data-slot="integrations-hub"
dir="ltr"
role="group"
aria-label="Hirael at the center of its integrations"
style={stagger(3)}
className={cn(ENTER, 'relative mx-auto mt-12 aspect-[100/72] w-full max-w-xl px-4 sm:mt-16')}
>
<div className="relative size-full">
<div aria-hidden className="absolute inset-[16%] rounded-full border border-dashed border-border/70" />
<div
aria-hidden
className="absolute start-1/2 top-1/2 size-40 -translate-x-1/2 -translate-y-1/2 rounded-full bg-primary/20 blur-3xl"
/>
<svg aria-hidden viewBox={`0 0 ${WIDTH} ${HEIGHT}`} className="absolute inset-0 size-full text-border">
{SPOKES.map((spoke, index) => {
const { x, y } = spokePosition(spoke.angle);
const path = index % 2 === 0 ? `M${x} ${y} L${CX} ${CY}` : `M${CX} ${CY} L${x} ${y}`;
return (
<g key={spoke.name}>
<line x1={CX} y1={CY} x2={x} y2={y} stroke="currentColor" strokeWidth="0.3" />
<circle r="0.9" className="fill-primary motion-reduce:hidden">
<animateMotion dur="3s" begin={`-${index * 0.5}s`} repeatCount="indefinite" path={path} />
</circle>
</g>
);
})}
</svg>
<div className="absolute start-1/2 top-1/2 z-10 flex size-16 -translate-x-1/2 -translate-y-1/2 items-center justify-center rounded-2xl bg-primary text-primary-foreground shadow-lg sm:size-20">
<BrandMark className="size-7 sm:size-9" />
</div>
{SPOKES.map((spoke) => {
const { x, y } = spokePosition(spoke.angle);
return (
<a
key={spoke.name}
href={spoke.href}
aria-label={spoke.name}
title={spoke.name}
className="group absolute z-10 flex size-11 -translate-x-1/2 -translate-y-1/2 items-center justify-center rounded-xl border border-border bg-card text-muted-foreground shadow-xs transition-[color,transform,box-shadow] duration-150 ease-out hover:-translate-y-[55%] hover:text-foreground hover:shadow-md focus-visible:ring-2 focus-visible:ring-ring focus-visible:outline-none motion-reduce:transition-none sm:size-14"
style={{ left: `${(x / WIDTH) * 100}%`, top: `${(y / HEIGHT) * 100}%` }}
>
<spoke.icon aria-hidden className="size-5 sm:size-6" />
</a>
);
})}
</div>
</div>
<div className="mt-10 flex justify-center px-4 sm:mt-14">
<Button asChild style={stagger(4, 60, 200)} className={cn(ENTER, 'group')}>
<a href="#">
Browse integrations
<ArrowRight className="size-4 transition-transform duration-150 ease-out group-hover:translate-x-0.5 rtl:rotate-180 rtl:group-hover:-translate-x-0.5" />
</a>
</Button>
</div>
</section>
);
};
export default Integrations04;
