Bar chart whose columns are stacks of blocks, on the ECharts blocks variant
@evilcharts
src/registry/blocks/echarts/b-grid-echarts-bar-chart.tsx
"use client";
import { EChartsBarChart, type ChartConfig } from "@/registry/charts/echarts-bar-chart";
const chartData = [
{ hour: "00:00", sessions: 42 },
{ hour: "01:00", sessions: 28 },
{ hour: "02:00", sessions: 19 },
{ hour: "03:00", sessions: 14 },
{ hour: "04:00", sessions: 12 },
{ hour: "05:00", sessions: 18 },
{ hour: "06:00", sessions: 34 },
{ hour: "07:00", sessions: 66 },
{ hour: "08:00", sessions: 98 },
{ hour: "09:00", sessions: 124 },
{ hour: "10:00", sessions: 147 },
{ hour: "11:00", sessions: 163 },
{ hour: "12:00", sessions: 158 },
{ hour: "13:00", sessions: 171 },
{ hour: "14:00", sessions: 186 },
{ hour: "15:00", sessions: 174 },
{ hour: "16:00", sessions: 152 },
{ hour: "17:00", sessions: 138 },
{ hour: "18:00", sessions: 119 },
{ hour: "19:00", sessions: 96 },
{ hour: "20:00", sessions: 84 },
{ hour: "21:00", sessions: 71 },
{ hour: "22:00", sessions: 58 },
{ hour: "23:00", sessions: 47 },
];
const chartConfig = {
sessions: {
label: "Sessions",
colors: {
light: ["#18181b"],
dark: ["#FFFFFF"],
},
},
} satisfies ChartConfig;
const TOTAL = chartData.reduce((sum, { sessions }) => sum + sessions, 0);
const PEAK = chartData.reduce(
(max, row) => (row.sessions > max.sessions ? row : max),
chartData[0],
);
export function EChartsGridBarChart() {
return (
<div className="flex h-full w-full flex-col p-4">
<div className="flex flex-row justify-between">
<div className="flex flex-row">
<div className="flex flex-col gap-2">
<span className="text-muted-foreground font-mono text-xs">{"[Σ] Total"}</span>
<span className="text-primary font-mono text-3xl tracking-tighter">
{TOTAL.toLocaleString()}
</span>
</div>
<hr className="mx-4 h-full border-l border-dashed" />
<div className="flex flex-col gap-2">
<span className="text-muted-foreground font-mono text-xs">{"[⬆] Peak"}</span>
<span className="text-primary font-mono text-3xl tracking-tighter">{PEAK.hour}</span>
</div>
</div>
<div className="flex flex-col justify-end gap-1">
<span className="text-muted-foreground font-mono text-[10px]">
{"// CELL: "}
<span className="text-primary">1:1</span>
</span>
<span className="text-muted-foreground font-mono text-[10px]">
{"// TYPE: "}
<span className="text-primary">GRID</span>
</span>
</div>
</div>
<hr className="my-4 border-t border-dashed" />
<div className="min-h-0 w-full flex-1">
<EChartsBarChart
data={chartData}
config={chartConfig}
xDataKey="hour"
className="h-full w-full"
barCategoryGap={14}
>
<EChartsBarChart.XAxis dataKey="hour" hideDots />
<EChartsBarChart.Tooltip />
<EChartsBarChart.Bar dataKey="sessions" variant="blocks" />
</EChartsBarChart>
</div>
</div>
);
}
