Split-layout image comparison with a sidebar featuring benefit highlights and icons alongside a draggable before/after slider. Perfect for demonstrating product improvements with detailed feature callouts.
@beste-ui
registry/reveal2/reveal2.tsx
"use client";
import { Check, GripHorizontal, GripVertical, Sparkles, Zap } from "lucide-react";
import { useCallback, useEffect, useRef, useState } from "react";
import { Badge } from "@/components/ui/badge";
import { cn } from "@/lib/utils";
interface Highlight {
id: string;
icon?: React.ReactNode;
title: string;
description?: string;
}
interface Reveal2Props {
badge?: {
label: string;
variant?: "default" | "secondary" | "outline";
};
heading?: string;
description?: string;
highlights?: Highlight[];
beforeImage?: {
src: string;
alt: string;
};
afterImage?: {
src: string;
alt: string;
};
beforeLabel?: string;
afterLabel?: string;
showLabels?: boolean;
orientation?: "horizontal" | "vertical";
initialPosition?: number;
dividerWidth?: number;
className?: string;
}
export const reveal2Demo: Reveal2Props = {
badge: { label: "Compare", variant: "secondary" },
heading: "See the difference",
description:
"Drag the slider to compare the before and after states. Our solution delivers measurable improvements.",
highlights: [
{
id: "highlight-1",
icon: <Check className="size-5" />,
title: "Performance boost",
description: "Up to 3x faster load times with optimized rendering.",
},
{
id: "highlight-2",
icon: <Sparkles className="size-5" />,
title: "Better clarity",
description: "Enhanced visuals with improved contrast and sharpness.",
},
{
id: "highlight-3",
icon: <Zap className="size-5" />,
title: "Reduced noise",
description: "Cleaner output with advanced noise reduction algorithms.",
},
],
beforeImage: {
src: "https://images.unsplash.com/photo-1558370781-d6196949e317?q=80&w=2958&auto=format&fit=crop&sat=-100",
alt: "Before",
},
afterImage: {
src: "https://images.unsplash.com/photo-1558370781-d6196949e317?q=80&w=2958&auto=format&fit=crop",
alt: "After",
},
beforeLabel: "Before",
afterLabel: "After",
showLabels: true,
orientation: "horizontal",
initialPosition: 50,
dividerWidth: 4,
};
export function Reveal2({
badge,
heading,
description,
highlights = [],
beforeImage,
afterImage,
beforeLabel = "Before",
afterLabel = "After",
showLabels = true,
orientation = "horizontal",
initialPosition = 50,
dividerWidth = 4,
className,
}: Reveal2Props) {
const [position, setPosition] = useState(initialPosition);
const [isDragging, setIsDragging] = useState(false);
const containerRef = useRef<HTMLDivElement>(null);
const isHorizontal = orientation === "horizontal";
const handleMove = useCallback(
(clientX: number, clientY: number) => {
if (!containerRef.current) return;
const rect = containerRef.current.getBoundingClientRect();
if (isHorizontal) {
const x = clientX - rect.left;
const percentage = Math.max(0, Math.min(100, (x / rect.width) * 100));
setPosition(percentage);
} else {
const y = clientY - rect.top;
const percentage = Math.max(0, Math.min(100, (y / rect.height) * 100));
setPosition(percentage);
}
},
[isHorizontal]
);
const handleMouseDown = useCallback(
(e: React.MouseEvent) => {
e.preventDefault();
setIsDragging(true);
handleMove(e.clientX, e.clientY);
},
[handleMove]
);
const handleTouchStart = useCallback(
(e: React.TouchEvent) => {
setIsDragging(true);
const touch = e.touches[0];
if (touch) {
handleMove(touch.clientX, touch.clientY);
}
},
[handleMove]
);
useEffect(() => {
const handleMouseMove = (e: MouseEvent) => {
if (isDragging) {
handleMove(e.clientX, e.clientY);
}
};
const handleTouchMove = (e: TouchEvent) => {
if (isDragging) {
const touch = e.touches[0];
if (touch) {
handleMove(touch.clientX, touch.clientY);
}
}
};
const handleEnd = () => {
setIsDragging(false);
};
if (isDragging) {
document.addEventListener("mousemove", handleMouseMove);
document.addEventListener("touchmove", handleTouchMove);
document.addEventListener("mouseup", handleEnd);
document.addEventListener("touchend", handleEnd);
}
return () => {
document.removeEventListener("mousemove", handleMouseMove);
document.removeEventListener("touchmove", handleTouchMove);
document.removeEventListener("mouseup", handleEnd);
document.removeEventListener("touchend", handleEnd);
};
}, [isDragging, handleMove]);
return (
<section className={cn("py-16 md:py-24 w-full", className)}>
<div className="mx-auto max-w-6xl px-4 md:px-6">
<div className="grid gap-6 lg:grid-cols-12 lg:items-center">
{/* Content */}
<div className="flex flex-col gap-4 lg:col-span-5">
{badge && (
<div>
<Badge variant={badge.variant ?? "default"}>{badge.label}</Badge>
</div>
)}
{heading && <h2 className="text-2xl font-semibold md:text-4xl">{heading}</h2>}
{description && (
<p className="max-w-xl text-base md:text-lg text-muted-foreground">{description}</p>
)}
{highlights.length > 0 && (
<div className="mt-2 grid gap-3">
{highlights.slice(0, 6).map((h) => (
<div key={h.id} className="rounded-lg bg-muted p-4">
<div className="flex items-start gap-3">
<span className="text-muted-foreground">
{h.icon || <Check className="size-5" />}
</span>
<div className="min-w-0">
<p className="text-sm font-semibold">{h.title}</p>
{h.description && (
<p className="mt-1 text-sm text-muted-foreground">{h.description}</p>
)}
</div>
</div>
</div>
))}
</div>
)}
</div>
{/* Slider */}
<div className="rounded-lg bg-muted lg:col-span-7 md:mt-4">
<div
ref={containerRef}
role="slider"
aria-label="Before/After comparison slider"
aria-valuemin={0}
aria-valuemax={100}
aria-valuenow={position}
tabIndex={0}
className={cn(
"relative rounded-lg overflow-hidden border select-none",
"aspect-[16/10] cursor-ew-resize",
!isHorizontal && "cursor-ns-resize"
)}
onMouseDown={handleMouseDown}
onTouchStart={handleTouchStart}
>
{/* After Image (Bottom layer - full) */}
<div className="absolute inset-0">
{afterImage?.src ? (
<img
className="absolute inset-0 size-full object-cover"
src={afterImage.src}
alt={afterImage.alt}
/>
) : (
<div className="w-full h-full bg-muted/50 flex items-center justify-center">
<span className="text-muted-foreground text-sm">{afterLabel} image</span>
</div>
)}
</div>
{/* Before Image (Top layer - clipped) */}
<div
className="absolute inset-0"
style={{
clipPath: isHorizontal
? `inset(0 ${100 - position}% 0 0)`
: `inset(0 0 ${100 - position}% 0)`,
}}
>
{beforeImage?.src ? (
<img
className="absolute inset-0 size-full object-cover"
src={beforeImage.src}
alt={beforeImage.alt}
/>
) : (
<div className="w-full h-full bg-muted flex items-center justify-center">
<span className="text-muted-foreground text-sm">{beforeLabel} image</span>
</div>
)}
</div>
{/* Divider Line */}
<div
className={cn(
"absolute bg-white shadow-lg z-10",
isHorizontal
? "top-0 bottom-0 transform -translate-x-1/2"
: "left-0 right-0 transform -translate-y-1/2"
)}
style={{
[isHorizontal ? "left" : "top"]: `${position}%`,
[isHorizontal ? "width" : "height"]: `${dividerWidth}px`,
}}
>
{/* Handle */}
<div
className={cn(
"absolute bg-white rounded-full shadow-xl",
"flex items-center justify-center",
"w-10 h-10 border-3 border-primary",
"left-1/2 top-1/2 -translate-x-1/2 -translate-y-1/2",
isDragging && "scale-110"
)}
>
{isHorizontal ? (
<GripVertical className="w-5 h-5 text-primary" />
) : (
<GripHorizontal className="w-5 h-5 text-primary" />
)}
</div>
</div>
{/* Labels */}
{showLabels && (
<>
<div
className={cn(
"absolute z-20 px-3 py-1.5 rounded-full",
"bg-black/70 text-white text-sm font-medium backdrop-blur-sm",
"top-4 left-4"
)}
>
{beforeLabel}
</div>
<div
className={cn(
"absolute z-20 px-3 py-1.5 rounded-full",
"bg-black/70 text-white text-sm font-medium backdrop-blur-sm",
isHorizontal ? "top-4 right-4" : "bottom-4 left-4"
)}
>
{afterLabel}
</div>
</>
)}
</div>
</div>
</div>
</div>
</section>
);
}
